Programming Blocks

The following blocks are used to program an Assembled Move. Both of the move types, Blend Move, and
Dwell Move, are programmed exactly the same way. The bit configuration used when starting the move
determines which type of Assembled Move is run.

First Block

PROFINET
Word
0
1
2
3
4
5
6
7
8
9
Unused words are ignored by the SMD23E2 and SMD24E2 and can be any value, including parameter values
from the previous command.
Once the first block is transmitted, the SMD23E2 or SMD24E2 responds by setting bits 8 and 9 in Status Word 0.
(See Status Word 0 Format
Blocks.

Segment Block

PROFINET
Word
0
1
2
3
4
5
6
7
8
9
Note that each Segment Block starts with bits 11 and 12 in Command Word 0 set to "1" (16#1800). When the
unit sees bit 12 of Command Word 0 set, it will accept the block and reset bit 9 in Status Word 0. When your pro-
gram sees this bit reset, it must respond by resetting bit 12 of Command Word 0. The SMD23E2 or SMD24E2
will respond to this by setting bit 9 in Status Word 0 and the next Segment Block can be written to the unit. You
can write a maximum of sixteen Segment Blocks for each Assembled Move.
