Command Blocks (continued)

Resume Move

PROFINET
Word
0
1
2
3
4
5
6
7
8
9
Unused words are ignored by the SMD23E2 and SMD24E2 and can be any value, including parameter values
from the previous command. This is typically the case when resuming a move, the words are listed as
"Unused" to highlight that the target position of a held move cannot be changed when the move is resumed.

Immediate Stop

PROFINET
Word
0
1
2
3
4
5
6
7
8
9
Unused words are ignored by the SMD23E2 and SMD24E2 and can be any value, including parameter values
from the previous command.
74
D F
ATA ORMAT
Function
Command Word 0
Command Word 1
Unused
Unused
Programmed Speed: Upper Word
Programmed Speed: Lower Word
Acceleration
Deceleration
Motor Current
Acceleration Jerk
Table R6.5 Resume Move Command Block
Function
Command Word 0
Command Word 1
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Table R6.6 Immediate Stop Command Block
SMD23E2 and SMD24E2 User's Manual
Units
See Note Below
See Note Below
Combined value between
Steps/Second the Configured Starting
Speed and 2,999,999
Steps/sec/ms
Steps/sec/ms
0 to 34. Ignored if bit 1 of
0.1 amps
Command Word 1 is not set.
Units
See Note Below
See Note Below
See Note Below
See Note Below
See Note Below
See Note Below
See Note Below
See Note Below
