Basic Move Types (continued)

Absolute Move

Absolute Moves move from the Current Position (A)
to a given position (B). (The SMD23E2 or SMD24E2
calculates the direction and number of steps needed to
move to the given position and moves that number of
steps.) A trapezoidal profile is shown to the right, but
Absolute Moves can also generate triangular profiles.
The command's Target Position can be in the range of
±8,388,607 counts. The move will be clockwise if the
Target Position is greater than the Current Position and
counter-clockwise if the Target Position is less than
the Current Position.
1) The Home Position of the machine must be set before running an Absolute Move. See the
2) The Motor Position must be valid before you can use an Absolute Move. The Motor Posi-
3) Absolute Moves allow you to move your machine without having to calculate relative posi-
Controlled Stop Conditions

The move completes without error.

You toggle the Hold_Move control bit in the Network Output Data. Note that your holding position will
most likely not be the final position you commanded. You can resume a held Absolute Move by using
the Resume_Move bit or the move can be aborted by starting another move. The use of the Hold_Move
and Resume_Move bits is explained in the
Immediate Stop Conditions

The Immediate Stop bit makes a 0

An inactive-to-active transition on an input configured as an E-Stop Input.

A CW or CWW Limit Switch is reached. If the limit that is reached is the same as the direction of
travel, for example, hitting the CW limit while running a CW move, a Reset Errors command must be
issued before moves are allowed in that direction again. If the limit that is reached is opposite the direc-
tion of travel, a Reset Errors command does not have to be issued.
