Revision 2.2b
Step 5: Before making any changes to the network settings, write down the current settings so they can
be restored once WebRelay-Quad
IP address," and type in the IP address 192.168.1.50. Type in a subnet mask of 255.255.255.0. Leave the
default gateway field blank. Click OK to apply settings.

2.3.3 Open Configuration Web Page

Once the network is set up, open the configuration setup page by typing the following URL into the browser:
http://192.168.1.2/setup.html (note that if option 1 above was used for initial configuration, replace the IP
address given here with the newly assigned IP address). A password is required to change any parameters.
The default password is 'webrelay' (do not include quotes, password is case sensitive).

2.4 Web-Based Setup

WebRelay-Quad is fully configurable through HTML 4.0 compliant web browsers such as Internet Explorer and
TM
Mozilla Firefox. It's easy to use tab based menu system has been designed to allow the unit to be configured easily.
Note that in this chapter, the default IP address of 192.168.1.2 is used in all examples. If the IP address has been
changed, substitute the new IP address for the address shown in the examples.
Before proceeding, make sure a network connection has been established between the computer and WebRelay-
Quad . This is done by typing the following URL into the web browser: http://192.168.1.2/setup.html. Another
TM
way to check communications is to ping WebRelay-Quad
Each setup page is described below.
Xytronix Research & Design, Inc.
is configured. Next, select the radio button labeled "Use the following
TM
(from the command prompt (type ping 192.168.1.2)).
TM
WebRelay-Quad Users Manual
TM
page 16
