4. Relay Description:
This text is used to describe the function of the relay on the control page. This text will not appear if the
'Display Relay Status' is set to No, the 'On/Off Buttons' is set to 0, and the 'Pulse Button' is set to No.
This field can be up to 20 characters in length.
5. Display Relay Status:
When this option is set to Yes, the relay status will be displayed on the control page. If it is set to No, the
relay status will not be displayed.
6. Status ON Color:
When the 'Display Relay Status' option is set to Yes, this field specifies the color that will be displayed
when the relay is on (coil energized).
7. Status ON Text:
When the 'Display Relay Status' option is set to Yes, this field specifies the text that will be displayed when
the relay is on (coil energized).
8. Status OFF Color:
When the 'Display Relay Status' option is set to Yes, this field specifies the color that will be displayed
when the relay is off (coil not energized).
9. Status OFF Text:
When the 'Display Relay Status' option is set to Yes, this field specifies the text that will be displayed when
the relay is off (coil not energized).
10. ON/OFF Buttons:
This option allows the user to specify 0, 1, or 2 buttons to turn the relay on or off. Zero buttons disables the
users ability to turn the relay on and off (a pulse button may still be included... see below). One button may
be used to toggle the relay on and off. Two buttons gives the user one button to turn the relay on and another
button to turn the relay off.
11. Button 1 Label:
When 1 or 2 buttons is selected in the 'ON/OFF Buttons' option, this field specifies the text that will be
displayed in pushbutton number 1.
12. Button 2 Label:
When 2 buttons is selected in the 'ON/OFF Buttons' option, this field specifies the text that will be
displayed in pushbutton number 2.
13. Pulse Button:
This option allows the user to include a pulse button to control the relay. If the pulse button is included, the
relay will pulse for the time specified in the 'Pulse Duration' field in the 'Relay/Input' page each time the
button is pressed.
14. Pulse Button Label:
When the 'Pulse Button' option is set to Yes, the text entered here will appear in the pulse button on the
control page.
15. Pulse Duration:
TM
When WebRelay-Quad receives a command (from over the network or through an input change) to pulse
the relay, this is the time in seconds that the relay will pulse on. This time can be set from 0.1 seconds to
86,400 seconds (1 day). Note that each time WebRelay-Quad receives a pulse command, the relay will be
TM
turned on (if not on already) and the pulse timer will be reset. If WebRelay-Quad receives a pulse
TM
command and and a second pulse command comes in before the pulse timer has expired, the relay will
