2.2 Connection

CAUTION: MAKE SURE POWER IS SHUT OFF BEFORE WIRING!
Two removable terminal connectors are provided for simple wiring to WebRelay-Quad
procedure is as follows;
1. Make sure power is turned off.
2. Remove terminal connectors from WebRelay-Quad
3. Reconnect terminal connectors.
4. Apply power.
It is recommended that the load (device to be controlled) not be connected to WebRelay-Quad
WebRelay-Quad has been configured and tested. By doing this, wiring and configuration mistakes will not cause
TM
the load device to turn on unexpectedly.
IMPORTANT: MAKE SURE WIRES ARE PROPERLY ATTACHED TO THE TERMINALS!
Strand(s) of wire are loose
Xytronix Research & Design, Inc.
WebRelay-Quad
and make wiring connections to the terminals.
TM
Bad Connector Example.
Wires are stripped too far back
Good Connector Example.
Wires are stripped correct
amount and there are no loose
strands that can cause shorts
Users Manual
TM
. The correct wiring
TM
until after
TM
page 10
