ControlByWeb WebRelay-Quad X-WR-4R1-5 User Manual page 36

Revision 2.2b
LED Indicators: 7
-Power on
-Relay coils (1-4) engaged
-Network linked
-Network activity
Physical:
Operating Temperature: -20° to 70°C ( -4°-158°F)
Size: 1.41in (35.7mm) wide X 3.88in (98.5mm) tall X 3.1 in(78.0mm) deep
Weight: 4.5oz (128 grams)
Enclosure Material: Lexan 940 (UL94 V0 flame rated)
Password Settings:
Password protection on setup page: Yes
Password protection on control page: Optional
Password Encoding: Base 64
Max password length: 10 characters
Regulatory Compliance:
Electromagnetic Compliance:
IEC CISPR 22, CISPR 24
FCC 47CFR15 (-I and -5 Models class B, POE Model Class A)
EU EN55024, EN55022
Product Safety:
IEC 60950-1 / EN 60950-1
Xytronix Research & Design, Inc.
WebRelay-Quad Users Manual
TM
page 35
