Revision 2.2b
WebRelay-Quad
Users Manual
TM
remain on and the pulse timer will be reset so the duration of the pulse will be extended. If pulse commands
are issued continuously so that the pulse timer is not allowed to expire, the relay will remain on until after
the last pulse command was sent (to be precise, the relay will go off at the time of the last command plus the
Pulse Duration time). The pulse command can be canceled before the pulse duration time has expired by
issuing any other command. The factory default setting for this is 1.5 seconds.
Xytronix Research & Design, Inc.
page 24
