WebRelay-Quad
Basic Setup Steps
1. Power the module and connect via ethernet to a computer.
2. Set IP address on computer to the same network as module.
(Ex: 192.168.1.50)
3. To configure module, open web browser and enter:
http://192.168.1.2/setup.html
.
4
In General Settings under WiFi, enter the WiFi settings.
5. Assign the module a permanent IP address or enable DHCP.
6. Restart the module for the settings to take effect.
Factory Default Settings
IP Address: 192.168.1.2
Subnet Mask: 255.255.255.0
Control Page Web Address: http://192.168.1.2
Control Password: (no password set)
Setup Page Web Address: http://192.168.1.2/setup.html
Setup Username: admin
Setup Password: webrelay (all lower case)
See users manual for setup instructions:
www.ControlByWeb.com/support/
(X-WR-444W)
Note: restore computer settings after setup.
| Quick-Start Guide
Rev 1.0
Advertisement
Related Manuals for ControlByWeb WebRelay-Quad
Summary of Contents for ControlByWeb WebRelay-Quad
- Page 1 WebRelay-Quad | Quick-Start Guide (X-WR-444W) Basic Setup Steps 1. Power the module and connect via ethernet to a computer. 2. Set IP address on computer to the same network as module. (Ex: 192.168.1.50) Note: restore computer settings after setup. 3. To configure module, open web browser and enter: http://192.168.1.2/setup.html...
