Appendix B: Specifications

Power Requirements:
Model X-WR-4R1-5
Voltage: 5VDC ± 5%
Current: See table below for typical values
No Relays On
All 4 Relays On
Model X-WR-4R1-I
Voltage: 9~28VDC
Current: See table below for typical values
9V No Relays On
9V All 4 Relays On
12V No Relays On
12V All 4 Relays On
24V No Relays On
24V All 4 Relays On
Model X-WR-4R1-E
POE Class 1 (0.44 to 3.84 Watt). Optionally can be powered with external 5VDC power supply.
I/O: 4 Relays
Relay Contacts:
Contact Form: SPDT (Form C) (Direct access to dry contacts)
Contact Material: Ag (Au clad)
Max Voltage: 28V
Max Current: 1A
Min Load: 1mA @ 5VDC
Relay Control Options: ON/OFF or Pulsed
Pulse Timer Duration: 100ms to 86400 Seconds (1 day)
Accuracy of pulse timer: 99.99%
Network: 10/100Base-T Ethernet
Network Setup: static IP address assignment, TCP port selectable
Connectors:
Power/Relay Contacts: 14-position, removable terminal strip, 3.81mm terminal spacing
(Replacement part number, Phoenix Contact 1803691 )
Network: 8-pin RJ-45 socket
Xytronix Research & Design, Inc.
10Mbps Network
130mA
335mA
10Mbps Network
98mA
225mA
75mA
170mA
40mA
88mA
WebRelay-Quad Users Manual
TM
100Mbps Network
255mA
477mA
100Mbps Network
186mA
320mA
140mA
240mA
73mA
123mA
