ControlByWeb WebRelay X-WR-441W Quick Start Manual

Single relay & input module

Advertisement

Quick Links

WebRelay
Basic Setup Steps
1. Power the module and connect via ethernet to a computer.
2. Set IP address on computer to the same network as module.
(Ex: 192.168.1.50)
3. To configure module, open web browser and enter:
http://192.168.1.2/setup.html
.
4
In General Settings under WiFi, enter the WiFi settings.
5. Assign the module a permanent IP address or enable DHCP.
6. Restart the module for the settings to take effect.
Factory Default Settings
IP Address: 192.168.1.2
Subnet Mask: 255.255.255.0
Control Page Web Address: http://192.168.1.2
Control Password: (no password set)
Setup Page Web Address: http://192.168.1.2/setup.html
Setup Username: admin
Setup Password: webrelay (all lower case)
See users manual for setup instructions:
www.ControlByWeb.com/support/
(X-WR-441W)
Note: restore computer settings after setup.
| Quick-Start Guide
Rev 1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the WebRelay X-WR-441W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ControlByWeb WebRelay X-WR-441W

  • Page 1 Factory Default Settings IP Address: 192.168.1.2 Subnet Mask: 255.255.255.0 Control Page Web Address: http://192.168.1.2 Control Password: (no password set) Setup Page Web Address: http://192.168.1.2/setup.html Setup Username: admin Setup Password: webrelay (all lower case) See users manual for setup instructions: www.ControlByWeb.com/support/ Rev 1.0...
  • Page 2 WebRelay | Pinout Diagram (X-WR-441W) Relay Contact Common Relay Contact Normally Open Relay Contact Normally Closed V IN+: Power Supply Input (9-28VDC) Power Supply V IN-: Power Supply Input (Ground) INPUT-: Optically-Isolated Input (-) INPUT+: Optically-Isolated Input (+) +5V OUT: 5VDC Output 50mA Max 1681 West 2960 South, Nibley, UT 84321, USA...
