Print Direction; Park Mode - Compuprint MDP40T plus User Manual

Setup Parameter Values

PRINT DIRECTION

unidir., bidir.,
sw control
EJECT ON FF disabled, enabled
CUT SHEET EJECT on front, on rear

PARK MODE

immediate
manual imm.
after tear
Description
Selects the printing direction of the print head: unidirectional
( unidir .), bidirectional ( bidir .) or selected via software ( sw
control ).
Performs a form feed according to the selected page format
( disabled ) or ejects a cut sheet loaded into the printer ( enabled ).
Selects whether the cut sheet loaded into the printer is ejected
towards the front or the rear of the printer.
When pressing the PARK key or receiving a park command, the
printer immediately parks the paper.
When pressing the PARK key, the printer automatically parks the
paper. When receiving a park command via software:
1. If the current page is not empty (there is printing data or paper
movement commands have been issued), a form feed is
performed.
2. The paper is moved to the tear-off position.
3. The P1, P2, P3 and P4 leds blink.
When the ON LINE key is pressed the printer parks the paper.
When pressing the PARK key or receiving a park command via
software:
1. If the current page is not empty (there is printing data or paper
movement commands have been issued), a form feed is
performed.
2. The paper is moved to the tear-off position.
3. The P1, P2, P3 and P4 leds blink.
4. When the ON LINE key is pressed the printer parks the paper
41
