Compuprint MDP40T plus User Manual page 46

Setup Parameter Values
TEAR MODE auto 1s, auto 2s,
auto 3s, auto 4s,
auto 5s, manual,
no tear/reverse
MANUAL LOADING enabled, disabled
ALIGN MODE fast, normal
GAP MODE auto, fix
AUTO EMPHASIZED no autoEM, 0.25
mm, 0.35 mm, 0.45
mm, 0.55 mm
Description
Selects the way the tear mode is performed. Selecting auto 1s,
auto 2s, auto 3s, auto 4s, or auto 5s , the printer moves
the paper in the tear-off position and back to the printing position after
the corresponding number of seconds. Selecting manual, the tear-off
is performed manually, pressing the ON LINE key. Selecting no
tear/ reverse , the printer does not perform the tear-off function
(this is useful, when printing on labels).
Selects the manual loading mode. Setting it to enabled the printer
loads any kind of document according to the described procedures.
Select disabled , when a more precise paper alignment is
necessary. With this selection it is not possible to load documents with
a width of less than 90 mm.
Selects the paper alignment mode. Selecting fast the printer
performs less checks on the alignment, whereas, if you need a
particularly precise alignment of the documents, select normal .
Selects, whether the print gap is sensed for each inserted sheet
( auto ) or only for the first sheet after the printer power on ( fix ). The
print gap is sensed separately for the cut sheet and the fanfold paper.
Selects the emphasized print mode when the loaded paper is thicker
than the selected value.
42
