Skip Perforation - Compuprint MDP40T plus User Manual

Setup Parameter
AUTO GAP OFFSET
GET EDGE QUOTE

SKIP PERFORATION

TEAR ADJUST
Values
-0,075 mm, -0.050 mm,
-0.025 mm, +0.000 mm,
+0.025 mm, +0.050
mm, +0.075 mm,
+0.100 mm
0/2", 1/2", 2/2", 3/2",
4/2", 5/2", 6/2", 7/2"
disabled, enabled
-0,85 mm, -0,56 mm, -
0,28 mm, +0,00 mm,
+,28 mm +0,56 mm,
+0,85 mm
Description
Sets the automatic gap offset to one of the given values.
Sets the position in which the left paper edge is checked. If set
to 0, the check is performed at the first line. The other values
correspond to the physical distance from the first line.
If the passage of the paper perforation under the print head is
critical, select enabled to avoid the paper to get torn. The print
head lifts up during the paper passage. If disabled, the print
head keeps in position.
Sets the paper tear-off position by aligning the paper with the
tear-off edge .
35
