Antenna Control Unit (ACU)
ACU Size
ACU Weight
LED Indicator
Ship's Gyrocompass Interface
PC Interface
Modem Interface
Ethernet port
RF Port
Input Power
431 mm x 350 mm x 44.3 mm
5.2 Kg
Six LEDs for POWER, INT/SEARCH, TRACKING, LOCK,
SETUP/TEST, ERROR
NMEA 0183
Front: Ethernet port, USB (PC, DN: Not working)
Back: RS-232C (57600 bps 8, N, 1)
Ethernet port, RS-232/422, I/O Console
Front: RJ-45 Management LAN port (1 ea)
Back: RJ-45 LAN port (1 ea)
Antenna: N-Type (1 ea)
Modem Tx/Rx: F-Type (2 ea)
100 ~ 240 V AC, 50/60 Hz, 1A
