Intellian v45C Installation & Operation User Manual page 79

No. Item
Thresholds
3
Setting
Search
4
Parameter
Conical Range
5
Rate Sensor Bias
6
LNB Pol Sensor
Calibration
7
(Skew)
Antenna Mode
8
Description
Sets current detect level threshold and tracking level threshold.
• Detect Level: sets the current detect level threshold.
• Tracking Level: sets the current tracking level threshold.
• Tx Enable: sets the Tx enable threshold.
Click the Apply button to apply the settings to the system.
Sets the time-out.
• Wait Time (sec): sets the time-out for automatic initiation of a search after the
signal level drops below the pre-defined threshold value.
Click the Apply button to apply the settings to the system.
Sets the conical range. The conical range is the relative force of the motors
controlling azimuth and elevation. Click the Apply button to apply the settings to
the system.
This function must be used by experienced engineers only.
The rate values of the azimuth, elevation, and cross-level axes were calibrated
to the optimal condition at the factory prior to shipment. An additional rate
adjustment is not required.
If replacing the sensor part, the rate sensor calibration should be performed by
experienced engineers.
Calibrates the LNB pol angle when the control board, the skew motor or belt is
replaced.
• Sat Skew Offset: Displays the skew offset value.
• Mechanical Offset: Displays the skew offset value.
The indicator right of the value box shows the skew offset status.
- Blue: Mechanical skew offset value is less than ±10 degrees.
- Red: Mechanical skew offset value is greater than ±10 degrees.
• Consolidated Offset: Displays the consolidated offset value.
• Pol Sensor Calibration: Calibrates the skew motor and checks the skew
range.
• Mechanical Skew Offset Reset: To reset the mechanical skew offset value
to 0, click on the Mechanical Skew Offset Reset button. The mechanical
skew offset is pre-set with a factory default value (0, 1 or 2) depending on the
assembly condition. You may need to reset the mechanical skew offset when
the satellite skew offset is unknown (consolidated skew offset = satellite skew
offset + mechanical skew offset). Mechanical skew offset is set automatically
by moving the Pol Angle left or right in the search or tracking mode.
NOTE: Each satellite has its own skew offset. Intellian recommends you to
contact your service provider or satellite operator to get the satellite skew offset
value. To set the satellite offset value, go to SETUP menu
Information Skew Offset.
Sets the motor to idle mode to check the antenna's balance.
• Set Idle Mode: Enter Setup Mode to modify settings. Releases the elevation
and cross-level motor.
• Reboot: Reboots the system.
79
Using AptusNX
