Intellian v45C Installation & Operation User Manual page 85

No. Item
Modem
4
Connection
Beam Selector
5
Newtec Modem
6
Monitor
Description
Enter the connection information of the modem (IDIRECT OPENAMIP,
COMTECH ROAM, SATLINK VACP, NEWTEC AMIP).
• Modem IP: Enter the modem IP address.
• Port: Enter the connection port.
• ID: Enter the connection ID.
• Password: Enter the connection password.
• Auto Connect: By enabling the auto connect, the connection information is
saved and the modem is connected automatically when the system reboots.
• Last Update Date: Displays the last update date and time.
• Connect: Displays last updated data and time of the modem data.
• Rx SNR: Displays the Rx SNR data.
This menu can be edited when IDIRECT Open AMIP Modem option is selected in the
Select Modem menu.
Selects the target satellite that you want to track.
• Beam List: Choose the target satellite in the list.
• Apply: Click the Apply button to apply the selected beam to the system, it
will switch to the beam desired.
• Lock: Within condition given for test or commissioning, if the user wishes to
stay on a selected beam, the user can lock the beam by clicking the Lock
button. This will lead modem stays with the user-selected beam.
• Reboot: If you do not want to lock the beam, click the Reboot button.
• Refresh: Click the Refresh button to load the latest satellite list.
This menu can be edited when NEWTEC AMIP option is selected in the Select Modem
menu.
Sets the Newtec Modem options.
• dBm: Displays the signal level from the Newtec Modem.
• Es/NO: Displays the Es/NO value from the Newtec Modem.
• Ntc_s Request Delay Time (ms): Set the delay time of the system for
receiving the signal level (dBm) and Es/NO value from the Newtec Modem.
Click the Apply button to apply the settings to the system. Then perform the
"8.8.3 iARM Save & Reboot" on page 69.
85
Using AptusNX
