Evaluation Board User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 1.
Qty Reference Designator
103 C101, C102, C106, C110, C111, C115, C120, C121, C125, C130, C131,
C136, C201, C202, C206, C210, C211, C215, C220, C221, C225, C230,
C231, C236, C302, C303, C304, C307, C308, C309, C310, C311, C312,
C313, C314, C315, C316, C317, C318, C319, C320, C326, C327, C328,
C329, C330, C404, C413, C415, C418, C419, C420, C421, C422, C423,
C424, C431, C437, C439, C442, C443, C444, C445, C446, C447, C448,
C450, C451, C453, C454, C455, C456, C457, C458, C459, C462, C463,
C501, C502, C503, C504, C505, C506, C507, C510, C518, C519, C520,
C521, C522, C523, C527, C530, C531, C532, C533, C534, C615, C617,
C619, C621, C627, C629
4 C624, C625, C634, C635
1 C509
1 C636
2 C449, C452
5 C401, C407, C425, C430, C630
6 C408, C409, C410, C432, C433, C434
4 C411, C412, C435, C436
1 C515
1 C631
4 C403, C405, C427, C428
4 C603, C606, C609, C612
1 C516
1 C301
10 C602, C604, C605, C607, C608, C610, C611, C613, C622, C623
10 C414, C416, C438, C440, C614, C616, C618, C620, C626, C628
1 C632
1 C633
6 C402, C406, C426, C429, C460, C461
1 C601
5 CR301, CR302, CR303, CR304, CR601
10 D101, D102, D103, D104, D201, D202, D203, D204, D301, D501
5 D601, D602, D603, D604, D605
1 D606
1 D607
1 F601
Description
Capacitor, 0.1 μF, 0402,
X5R, ceramic, 10 V
Capacitor, 1 μF, 0402,
6.3 V, ceramic, X5R
Capacitor, 0.22 μF, 0402,
6.3 V, ceramic
Capacitor, 100 pF, 0402,
50 V, Ceramic
Capacitor, 1000 pF, 0402,
50 V, ceramic, X7R
Capacitor, 1500 pF, 0402,
25 V, ceramic, X7R
Capacitor, 150 pF, 0402,
25 V, ceramic, X7R
Capacitor, 2700 pF, 0402,
25 V, ceramic, X7R
Capacitor, 3900 pF, 0402,
25 V ceramic, X7R
Capacitor, 33 pF, 0402,
25 V ceramic, X7R
Capacitor, 5 pF, 0603, 50 V,
ceramic, NPO
Capacitor, 10000 pF,
0402, 16 V, ceramic, X7R
Capacitor, 22000 pF,
0402, 25 V, ceramic, Y5V
Capacitor, 1 μF, 0603,
16 V, ceramic, X5R
Capacitor, 4.7 μF, 0603,
6.3 V, ceramic, X5R
Capacitor, 10 μF, 0603,
6.3 V, ceramic, X5R
Capacitor, 4.7 μF, 0805,
6.3 V, ceramic X5R
Capacitor, 47 μF, 0805,
6.3 V, Ceramic, X5R
Capacitor, 22 μF, 0805,
6.3 V, ceramic, X5R
Capacitor, 10 μF, 6032-28,
tantalum, SMT, 16 V, 10%
LED, 0603, green
Diode Schottky GP LN
20 V SOT-23 200 mA SS
Diode, silicon rectifier,
SMBJ, 2 A, 50 V
MOSFET P-CH 30 V 3.1 A
SOT-23
Diode, Schottky, 2 A, 20 V
Polyswitch 1.10 A reset
fuse SMD
Rev. 0 | Page 23 of 28
Manufacturer Part Number
Panasonic ECJ-0EB1A104K
Panasonic ECJ-0EB0J105M
Panasonic ECJ-0EB0J224K
Murata GRM1555C1H101JD01B
Panasonic ECJ-0EB1H102K
Panasonic ECJ-0EB1E152K
Panasonic ECJ-0EB1H151K
Panasonic ECJ-0EB1E272K
Panasonic ECJ-0EB1E392K
Panasonic ECJ-0EC1H330J
Yageo CC0603CRNP09BN5R0
Panasonic ECJ-0EB1C103K
Panasonic ECJ-0EF1E223Z
Panasonic ECJ-BVB1C105M
Panasonic ECJ-1VB0J475M
Panasonic ECJ-1VB0J106M
Murata GRM21BR61E475KA12L
Taiyo Yuden JMK212BJ476MG-T
Panasonic ECJ-2FB0J226M
Kemet T491C106K016AT
Panasonic LNJ314G8TRA
Fairchild MMBD4148SE
Microcommerical S2A-TP
Vishay SI2343DS-TI-E3
Diodes Inc DFLS220L-7
Tyco/Raychem NANOSMDC110F-2
UG-016
