Evaluation Board User Guide
Qty Reference Designator
3 R540, R541, R601
1 R603
1 R614
1 R616
1 R617
12 L403, L404, L405, L406, L407, L408, L409, L410, L411, L412, L413, L414
2 T301, T501
2 U403, U408
1 U304
4 U401, U402, U406, U407
2 U404, U409
2 U405, U410
1 U411
1 U501
1 U601
1 U602
2 U603, U604
1 U605
1 U608
1 U412
1 U413
1 U606
1 U607
1 U302
1 U301
10 MP101, MP102, MP103, MP104, MP105, MP106, MP107, MP108,
MP109, MP110
4 MP111, MP112, MP113, MP114
Do Not Install
20 C305, C306, C511, C512, C513, C514, C528, C529, C464, C465, C466,
C467, C468, C469, C470, C471, C472, C473, C474, C475
3 C524, C525, C526
Description
Resistor, 249 Ω, 0402,
1/16 W, 1%
Resistor, 1.91 kΩ, 0402,
1/16 W, 1%
Resistor, 64.9 kΩ, 0402
Resistor, 0.047 Ω, 0805,
1/4 W, 2%
Resistor, 16.9 kΩ, 0402
Resistor, 0 Ω, 0603
1/10 W, 5%
Transformer, RF, 1:1
IC, amp, low PWR, noise,
distortion, SO8
IC, voltage REF, precision
series, SOT23_6
IC, amp, low noise high
speed, SO8
IC, ADC, 18-bit, 1 MSPS
PuLSAR 7.0 mW, RM10
IC, VREF, prec micropwr,
low dropout, SO8
IC, ADC driver, ultra-low
distortion diff, LFCSP16
IC, clock gen, 14-output,
2.8 GHZ VCO, QFN64
IC, regulator 3.3 V, low
dropout CMOS, SO8
IC, regulator 3.0 V, low
dropout CMOS, SO8
IC, regulator 1.8 V, low
dropout CMOS, SO8
IC, regulator 0.8 V to
5.0 V, low dropout
CMOS, SO8
IC-ADI high ACC. 500 mA
anycap low drop 2.5 V reg
IC, buffer, tinylogic UHS
dual, SC70
IC, buffer, tinylogic UHS
dual, SC70
IC, regulator, 500 mA
neg LDO
IC-ADI current-mode
step-down dc-to-dc
controller
IC-ADI ultrafast SIGe ECL
clock/data buffers
IC
Part of assembly
Part of assembly
Capacitor, 0.1 μF, 0402,
X5R, ceramic, 10 V
Capacitor, 100 pF, 0402,
50 V, ceramic, X7R
Rev. 0 | Page 25 of 28
Manufacturer Part Number
Panasonic ERJ-2RKF2490X
Panasonic ERJ-2RKF1911X
Panasonic ERJ-2RKF6492X
Susumu RL1220T-R047
Panasonic ERJ-2RKF1692X
Panasonic ERJ-3GEY0R00V
Minicircuits ADT1-1WT+
ADI ADA4841-2YRZ
ADI ADR130BUJZ
ADI AD8021ARZ
ADI AD7982BRMZ
ADI ADR434ARZ
ADI ADA4938-1ACPZ-R7
ADI AD9516-0BCPZ
ADI ADP1706ARDZ-3.3-R7
ADI ADP1706ARDZ-3.0-R7
ADI ADP1706ARDZ-1.8-R7
ADI ADP1708ARDZ-R7
ADI ADP3335ACPZ-2.5R7
FAIRCHILD NC7WZ07P6X
FAIRCHILD NC7WZ16P6X
Linear LT1175CST-5#PBF
Technology
ADI ADP1864AUJZ-R7
ADI ADCLK905
ADI AD9276BSVZ
Place into J404 100 mil jumpers
(Pin 1-2, 3-4, 5-6,
7-8,9-10), J301
(Pin 1-2, 3-4), J304
(Pin 1-2), J502
(Pins 3-4), J501
(Pins 2-3)
Insert/Snap into 14 mm height, dual
the large holes locking standoffs for
from the bottom circuit board support
side of board
Panasonic ECJ-0EB1A104K
Panasonic ECJ-0EB1H101K
