UG-016
Qty Reference Designator
15 J101, J102, J103, J104, J201, J202, J203, J204, J401, J402, J403, J303,
J503, J504, J505
1 J305
1 J404
1 J501
1 J502
2 J301, TP501
1 J304
1 P601
2 P604, P605
3 P602, P603, P606
14 L401, L402, L602, L603, L604, L605, L606, L607, L608, L609, L610, L611,
L612, L613
1 L601
1 L614
1 OSC501
15 R101, R115, R130, R145, R201, R215, R230, R245, R319, R425, R498,
R499, R504, R531, R532
28 R102, R116, R131, R146, R202 R216, R231, R246, R503, R505, R506,
R507, R508, R509, R510, R511, R519, R526, R527, R451, R453, R455,
R456, R457, R458, R460, R462, R535
8 R107, R121, R136, R151, R207, R221, R236, R251
10 R301, R302, R305, R441, R442, R443, R405, R417, R449, R450
20 R303, R304, R306, R403, R415, R444, R445, R446, R466, R467, R501,
R502, R514, R515, R516, R538, R539, R602, R615
6 R407, R409, R410, R419, R421, R422
6 R307, R308, R309, R310, R321, R517
5 R427, R429, R520, R521, R528
2 R428, R430
3 R440, R522, R523
2 R431, R432
2 R534, R536
4 R401, R404, R413, R416
1 R447
1 R433
1 R434
1 R437
1 R439
1 R518
Description
SMA, end launch, coax
Header, 4 pin double row,
male, 100 mil, straight
Header, 5 pin double row,
male, 100 mil, straight
Header, 3 pin single row,
male, 100 mil, straight
Header, 3 pin double row,
male, 100 mil, straight
Header, 2 pin double row,
male, 100 mil, straight
Header, 2 pin single row,
male, 100 mil, straight
Power supply connector
Connector, 60 pin RA
Terminal block, 4-pin, ST
Inductor, ferrite bead,
50 Ω 3 A 1206
EMI filter LC block choke
coil
Inductor, 4.7 μH,
shielded power
Clock oscillator, ACMOS/
LSTTL compatible
Resistor, 49.9 Ω, 0402,
1/16 W, 1%
Resistor, 0 Ω, 0402,
1/16 W, 1%
Resistor, 348 Ω, 0402,
1/16 W, 1%
Resistor, 1.00 kΩ, 0402,
1/16 W, 1%
Resistor, 10.0 kΩ, 0402,
1/16 W, 1%
Resistor, 20.0 kΩ, 0402,
1/16 W, 5%
Resistor, 5.1 kΩ, 0402,
1/16 W, 5%
Resistor, 200 Ω, 0402,
1/16 W, 1%
Resistor, 221 Ω, 0402,
1/16 W, 1%
Resistor, 100 Ω, 0402,
1/16 W, 1%
Resistor, 24 Ω, 0402,
1/16 W, 1%
Resistor, 24.9 Ω, 0402,
1/16 W, 1%
Resistor, 2.00 kΩ, 0402,
1/16 W, 1%
Resistor, 27 Ω, 0402,
1/16 W, 1%
Resistor, 33 kΩ, 0402,
1/16 W, 5%
Resistor, 10.5 kΩ, 0402,
1/16 W, 1%
Resistor, 8.66 kΩ, 0402,
1/16 W, 1%
Potentiometer, 10 kΩ sq
cermet top
Resistor, 4.12 kΩ, 0402,
1/16 W, 1%
Rev. 0 | Page 24 of 28
Evaluation Board User Guide
Manufacturer Part Number
Samtec SMA-J-P-H-ST-EM1
Samtec TSW-104-07-G-D
Samtec TSW-105-07-G-D
Samtec TSW-103-07-G-S
Samtec TSW-103-07-G-D
Samtec TSW-102-07-G-D
Samtec TSW-102-07-G-S
Switchcraft RAPC722X
Tyco 6469169-1
Weiland Z5.531.3425.0
Muarata BLM31PG500SN1L
Murata BNX016-01
Coilcraft LPS5015-472MLB
Valpey Fisher VFAC3H-L-40MHz
Panasonic ERJ-2RKF49R9X
Panasonic ERJ-2GE0R00X
Panasonic ERJ-2RKF3480X
Panasonic ERJ-2RKF1001X
Panasonic ERJ-2RKF1002X
Panasonic ERJ-2GEJ203X
Panasonic ERJ-2GEJ512X
Panasonic ERJ-2RKF2000X
Panasonic ERJ-2RKF2210X
Panasonic ERJ-2GEJ101X
Panasonic ERJ-2RKF24R0X
Panasonic ERJ-2RKF24R9X
Panasonic ERJ-2RKF2001X
Panasonic ERJ-2RKF27R0X
Panasonic ERJ-2GEJ333X
Panasonic ERJ-2RKF1052X
Panasonic ERJ-2RKF8661X
Copal CT94EW103
Panasonic ERJ-2RKF4121X
