Installation accessories

Table1-5 Installation accessories
Mounting bracket
Cage nut (user supplied)
Console cable

Pre-installation checklist

Table1-6 Pre-installation checklist
Item
Installation
site
M4 mounting bracket
screw
Grounding cable
Power cord
Requirements
•
Ventilation
•
•
Ambient
•
temperature
Ambient humidity 5% RH to 95% RH, noncondensing
•
Cleanness
•
•
•
•
ESD prevention
•
•
•
EMI prevention
M6 rack screw (user
supplied)
Power cord retainer clip
F100-C-A6-WL 4G
antenna
There is a minimum clearance of 100 mm (3.94 in)
around the inlet and outlet air vents for heat
dissipation of the firewall chassis.
A good ventilation system is available at the
installation site.
Operating: 0°C to 45°C (32°F to 113°F)
Storage: –40°C to +70°C (–40°F to +158°F)
Dust concentration ≤ 3 × 10
No dust on desk within three days
The equipment, workbench, and rack are reliably
grounded.
The equipment room is dust-proof.
The humidity and temperature are at an acceptable
level.
Wear an ESD wrist strap and make sure it makes
good skin contact and is reliably grounded when
installing removable components.
Take effective measures to protect the power system
from the power grid system.
Separate the protection ground of the firewall from
the grounding device or lightning protection
grounding device as far as possible.
