3.
Install cage nuts.
Figure1-5 Installing cage nuts
4.
Use the provided M4 mounting bracket screws to secure the mounting brackets to both sides of
the firewall.
Figure1-6 Securing mounting brackets to the firewall
5.
Mount the firewall in the rack. Use M6 rack screws to secure the mounting brackets to the front
rack posts.
1
2
3
10
