H3C SecPath F100-C-A-W Installation Manual page 38

Item
USB port
Fixed Ethernet port
Expansion slot
SIM card slot
4G antenna connector
Wi-Fi antenna connector
Console port
Table1-16 Console port specifications
Item
Connector
Standard compliance
Baud rate
Cable type
Transmission distance
Services
GE copper port
Table1-17 GE copper port specifications
Item
Connector
Standard compliance
Auto-MDI/MDIX
Cable type
Transmission distance
Data rate and duplex mode
NOTE:
The Ethernet ports on NICs are typically media dependent interface (MDI) ports. The ports on hubs
and LAN switches are typically media dependent interface crossover (MDIX) ports.
Description
1 (host mode, type A connector)
8 × GE copper ports
Not supported
•
F100-C-A3-W/F100-C-A5-W: Not supported
•
F100-C-A6-WL: 1 (standard SIM card)
•
F100-C-A3-W/F100-C-A5-W: Not supported
•
F100-C-A6-WL: 2
2
Specification
RJ-45
RS-232
9600 bps (default) to 115200 bps
Common asynchronous serial port cable
≤ 15 m (49.21 ft)
•
Connection to an ASCII terminal
•
Connection to the serial port of a local PC running the terminal
emulation program
•
CLI
Specification
RJ-45
802.3, 802.3u, and 802.3ab
Supported
Category 5 or above twisted pair cable
100 m (328.08 ft)
10/100/100 Mbps autosensing:
•
10 Mbps, half/full-duplex auto-negotiation
•
100 Mbps, half/full-duplex auto-negotiation
•
1000 Mbps, full-duplex auto-negotiation
31
