Chapter 5. Troubleshooting and Repair
5.7

Pressure Sensor Replacement (Series MV80 Only)

1. For local mounted electronics, remove the electronics stack as previously described. For remote mount
electronics, remove all wires and sensor connectors from the remote feed through board in the junction box at
the meter.
2. Loosen the three set screws at the center of the adapter between the meter and the enclosure.
3. Remove the top half of the adapter to expose the pressure transducer.
4. Remove the transducer and replace it with the new one using appropriate thread sealant.
5. Reassemble in reverse order.
5.8

Returning Equipment to the Factory

Before returning any PanaFlow MV flow meter to the factory, you must request a Return Material Authorization (RMA)
number. To obtain an RMA number and the correct shipping address, contact Panametrics Customer Service using
the information on the back cover of this manual.
IMPORTANT: When contacting Customer Service, be sure to have the meter serial number and model code available.
When requesting further troubleshooting guidance, please record the values in the tables provided in
"Troubleshooting the Flow Meter" on page 134 and have this information available.
