3.5.13 The Diagnostics Menu (cont.)
Run Mode
Simulate Vortex
Frequency (Hz)
*Simulate Temperature
*Simulate Pressure
*Highest Recorded
Velocity
*Highest Recorded
Temperature
*Highest Recorded
Pressure
*Highest Electronics
Temperature
*Lowest Electronics
Temperature
PanaFlow™ MV80, MV82 & MV84 User's Manual
ENTER
Password
ENTER
Diagnostics
Menu
Sim Vor Freq
xxx
Sim Temp 1,2
xxx
Sim Pressure
xxx
Highest Velocity
xxx
Highest Temp 1,2
xxx
Highest Pressure
xxx
Highest Int Temp
xx
Lowest Int Temp
xx
System LOG
xx Files (ENTER)
Clear Sys LOG?
YES or NO
Figure 107: The Diagnostics Menu
Use
keys to access menus
For a V model in any fluid, enter nominal operating temperature
and pressure as simulated values in the diagnostics menu.
For a VT model in any fluid except steam,enter nominal
operating pressure as simulated values in the diagnostics menu.
* The unit of measure of the displayed value is the
same as the unit configured for the flowmeter.
Momentarily displayed
SysLog File # xx
Press EXIT to return
Chapter 3. Operating Instructions
Use Left and Right
arrows to access
System Log File
all system log files
Time
Date
to System LOG
