2.6.7.2
Optional External 4-20 mA Input Wiring (cont.)
Refer to Figure 53 below to wire the external 4-20 mA input into the flow meter using power from the 24 VDC output of
an AC powered meter.
2.6.7.3

Optional External 4-20 mA Input and RTD Wiring

Loop Power
High Power
PanaFlow™ MV80, MV82 & MV84 User's Manual
Option 1
1
2
AC units only.
Meter provided DC power.
+ 24 VDC OUT
– 24 VDC OUT
Figure 53: External 4-20 mA Input Wiring - AC Powered Meter
Figure 54: External 4-20 mA Input and RTD Wiring - Loop Power
Option 2
3
4
5
1
2
Ext. 4-20 mA
Input Device
Chapter 2. Installation
3
4
5
49
