UM1668
1.3
Order code
To order the evaluation board based on STM32F439NIH6 MCU and 5.7" TFT LCD, use the
order code STM32439I-EVAL2.
1.4
Delivery recommendations
Some verifications are needed before using the board for the first time to make sure that
nothing was damaged during shipment and that no components are unplugged or lost.
When the board is extracted from its plastic bag, please check that no component remains
in the bag.
The main components to verify are:
1.
The 25 MHz crystal (X2) & 25 MHz crystal (X4) which may have been removed by a
shock from its socket.
2.
The MicroSD Card which may have been ejected from the connector CN17 (right side
of the board).
3.
The dual-interface EEPROM board (ANT7-M24LR-A) which may have been unplugged
from the connector CN3 (top left corner of the board).
4.
The camera module on the camera daughterboard (MB1066) which may have been
unplugged.
Warning:
There is an explosion risk if the battery is replaced by an
incorrect one.
Make sure to dispose of used batteries according to the
instructions.
