Appendix A Stm32439I-Eval I/O Assignment; Table 35. Stm32439I-Eval I/O Assignment - STMicroelectronics STM32439I-EVAL User Manual

UM1668
Appendix A
Pin number Pin name
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
A13
A14
A15
B1
B2
B3
B4
B5
B6
B7
B8
B9
B10
B11
STM32439I-EVAL I/O assignment

Table 35. STM32439I-EVAL I/O assignment

STM32439I-EVAL standard
A20/
PE4
TRACED1
A19/
PE3
TRACED0
PE2 TRACECLK
PG14 MII_TXD1
PE1 NBL1
PE0 NBL0
PB8 MII_TXD3
PB5 ULPI_D7
PB4 JTRST
JTDO-SWO/
PB3
I2S3_CK
PD7 NE1
SDCARD_CK/
PC12
SPI3_MOSI
PA15 JTDI
PA14 JTCK-SWCLK
PA13 JTMS-SWDIO
A21/
PE5
TRACED2
A22/
PE6 SAI1_SD_A/
TRACED3
PG13 MII_TXD0
PB9 I2C1_SDA
PB7
PB6 I2C1_SCL
PG15 SDNCAS
PG11 MII_TX_EN
PJ13 LCD_B1
PJ12 LCD_B0
NWAIT/
PD6
I2S3_SD
DocID025151 Rev 2
STM32439I-EVAL I/O assignment
Motor control
variant
-
-
-
-
-
-
DISSIPATIVE_BRAKE D6
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
NTC_BYPASS_IO
-
-
-
Camera
variant
-
-
-
-
-
-
-
-
-
-
D9
-
-
-
-
D7
-
-
VSYNC
-
-
-
-
-
D10
61/70
69
