Pin Description Alternative function
41 PB12
43 PB13
45 PJ9
47 PG7
49 D5V
51 PG6
53 PJ7
55 PJ10
57 PJ8
59 GND
2 PI11
4 PB5
6 PH1
8 PF7
10 GND
12 PF9
14 PA1
16 PC1
18 PA3
20 PA6
22 PA7
24 PA5
26 PB1
28 PH4
30 GND
32 PI14
34 PJ4
36 PB11
38 PB15
40 PH7
Table 20. Daughterboard extension connector CN6 (continued)
ULPI_D5/
USB_FS2_ID
ULPI_D6/
USB_FS2_VBUS
LCD_G2
LED2
-
LED1
LCD_G0
LCD_G3
LCD_G1
-
ULPI_DIR
ULPI_D7
OSC_OUT
SAI1_MCLK_B
-
SAI1_FS_B
MII_RX_CLK/
MC_ENB
MII_MDC/
MC_CurrentA
ULPI_D0
MC_EmergencySTOP/
PAR_PCLK
MII_RX_DV/
MC_UL
ULPI_CK
ULPI_D2/
MC_WL
ULPI_NXT
-
LCD_CLK
LCD_R5
ULPI_D4
USB_FS2_DP
MII_RXD3
DocID025151 Rev 2
How to disconnect with function block on
STM32439I-EVAL board
Remove R108, R260, Disconnect CN15
Remove R112, R264, Disconnect CN15
-
Remove R191
-
Remove R192
-
-
-
-
-
-
Remove C23, X2, Close SB6
-
-
-
Remove R210, R214
Remove R218, R222
-
Remove R16, Disconnect CN5
Remove R225, R227
Remove R126
Remove R104, R234
-
-
-
-
-
Remove R300, Disconnect CN15
Remove R46
Connectors
