UM1668
Pin Description Alternative function
18 PI7
20 PI9
22 PI6
24 PD7
26 PD5
28 PD4
30 GND
32 PD1
34 PI3
36 PH15
38 PH14
40 +3.3V
3.11

ETM trace debugging connector CN13

Pin number
1
3
5
7
9
11
13
15
Table 26. Memory connector CN12 (continued)
D29
D30
D28
NE1
NWE
NOE
-
D3
D27
D23
D22
-

Figure 15. ETM trace debugging connector CN13 (top view)

Table 27. ETM trace debugging connector CN13

Description Pin number
+3.3V 2
GND 4
GND 6
KEY 8
GND 10
GND 12
GND 14
GND 16
DocID025151 Rev 2
How to disconnect with function block on
STM32439I-EVAL board
-
-
-
-
-
-
-
-
-
-
-
-
Description
TMS/PA13
TCK/PA14
TDO/PB3
TDI/PA15
RESET#
TraceCLK/PE2
TraceD0/PE3 or SWO/PB3
TraceD1/PE4 or nTRST/PB4
Connectors
37/70
69
