Mechanical dimensions
Appendix B
Symbol Size (mm)
A1 68.58
A2 48.62
a 1.27
D 4.5
d 3.5
E1 55
E2 68
- -
68/70
Mechanical dimensions

Figure 42. Mechanical dimensions

Table 36. Mechanical dimensions

Symbol
E3
E4
e
H
Lx1
Lx2
Ly1
Ly2
DocID025151 Rev 2
Size (mm) Symbol
114.18 Mx
122 My
116.5 P1
25 P2
21.36 Q1
32.64 Q2
5 X
6.4 Y
UM1668
Size (mm)
20.1
24.43
16.94
55.37
46.77
9.98
157
172.72
