Directed DIRECTECHS DS4+ Installation Manual page 18

Wire Information
Function Color
Ford Flex (SA Key) 2013-2014
RX Violet
TX Yellow
Power Liftgate Gray
Accessory Violet
Ignition White/Orange
Keysense Blue
Start Blue/White
Headlight Switch Ground Black/Blue
Parking Light Gray
MS CAN High Gray/Orange
MS CAN Low Violet/Orange
HS CAN High White/Blue
HS CAN Low White
Driver Door Trigger Green/Violet
Lock Blue
Trunk/Hatch Release Brown
12V Red
Ford Fusion (SA Key) 2011-2012
RX Yellow/Orange
TX Violet/Gray
12V Blue/Red
Accessory Violet/Green
Ignition White/Orange
Keysense Blue/Gray
Start Blue/White
Headlight Switch Ground Black/Violet
Parking Light Gray
MS CAN High Gray/Orange
MS CAN Low Violet/Orange
HS CAN High White/Blue
HS CAN Low White
Driver Door Trigger Green/Violet
Lock Blue/Green
Trunk/Hatch Release Brown/Yellow
Unlock Yellow/Violet
18
Pin Polarity Location
4 Data P.A.T.S. connector at ignition switch.
3 Data P.A.T.S. connector at ignition switch.
6 (-) Power liftgate switch.
6 (+) Ignition switch
1 (+) Ignition switch
5 (+) Ignition switch
7 (+) Ignition switch
3 (-) Headlight switch
2 (-) Headlight switch
3 Data OBDII diagnostic connector.
11 Data OBDII diagnostic connector.
6 Data OBDll diagnostic connector.
14 Data OBDll diagnostic connector.
9 Cut BCM/SJB under driver dash.
6 (-) BCM/SJB under driver dash.
23 (-) BCM/SJB under driver dash.
6 (+) BCM/SJB under driver dash.
4 Data P.A.T.S. connector at ignition switch.
3 Data P.A.T.S. connector at ignition switch.
4 (+) Ignition switch
6 (+) Ignition switch
1 (+) Ignition switch
5 (+) Ignition switch
7 (+) Ignition switch
3 (-) Headlight switch
2 (-) Headlight switch
3 Data OBDII diagnostic connector.
11 Data OBDII diagnostic connector.
6 Data OBDll diagnostic connector.
14 Data OBDll diagnostic connector.
14 Cut BCM/SJB under driver dash.
17 (-) BCM/SJB under driver dash.
20 (-) BCM/SJB under driver dash.
4 (-) BCM/SJB under driver dash.
Connector Information
© 2017-06-20 Directed. All rights reserved.
Color Pins Ref.
Black 4 A
Black 4 A
Black 6 H
Black 7 B
Black 7 B
Black 7 B
Black 7 B
Gray 10 C
Gray 10 C
Black 16 D
Black 16 D
Black 16 D
Black 16 D
Gray 26 H
Gray 26 H
Gray 26 H
White 32 H
Black 4 A
Black 4 A
Black 7 B
Black 7 B
Black 7 B
Black 7 B
Black 7 B
Gray 10 C
Gray 10 C
Black 16 D
Black 16 D
Black 16 D
Black 16 D
Gray 26 H
Gray 26 H
Gray 26 H
Gray 26 H
DS4+ FORD6
