Directed DIRECTECHS DS4+ Installation Manual page 23

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Function Color
Ford Explorer (SA Key) 2011-2015
RX Violet/Red or Violet
TX Yellow/Orange or Yellow
Power Liftgate Gray/Yellow
12V Green/Red
Accessory Violet/Green
Ignition White/Orange
Keysense Blue/Gray
Start Blue/White
Parking Light Yellow/Blue
MS CAN High Gray/Orange
MS CAN Low Violet/Orange
HS CAN High White/Blue
HS CAN Low White
Driver Door Trigger Green/Violet
Lock Blue/Green
Trunk/Hatch Release Brown
Unlock Yellow/Violet
23
Wire Information
Pin
4
3
7
4
6
1
5
7
6
3
11
6
14
9
6
23
8
Polarity Location
Data P.A.T.S. connector at ignition switch.
Data P.A.T.S. connector at ignition switch.
(-) Power liftgate switch.
(+) Ignition switch
(+) Ignition switch
(+) Ignition switch
(+) Ignition switch
(+) Ignition switch
(+) BCM/SJB under driver dash.
Data OBDII diagnostic connector.
Data OBDII diagnostic connector.
Data OBDII diagnostic connector.
Data OBDII diagnostic connector.
Cut BCM/SJB in driver kick panel.
(-) BCM/SJB in driver kick panel.
(-) BCM/SJB in driver kick panel.
(-) BCM/SJB in driver kick panel.
Connector Information
Color
Black
Black
Black
Black
Black
Black
Black
Black
Gray
Black
Black
Black
Black
Black
Black
Black
Black
© 2017-06-20 Directed. All rights reserved.
Pins Ref.
4 A
4 A
8 E
7 B
7 B
7 B
7 B
7 B
10 C
16 D
16 D
16 D
16 D
26 F
26 F
26 F
26 F
DS4+ FORD6
