Directed DIRECTECHS DS4+ Installation Manual page 20

Wire Information
Function Color
Lincoln Navigator 2011-2014
RX Blue/Gray
TX Violet/Brown
Power Liftgate Gray/Yellow
Headlight Switch Ground Black/White
Parking Lights Blue/Gray
12V Blue/Red
Accessory Brown/Yellow
Accessory 2 Violet/Green
Ignition White/Orange
Keysense Blue/Gray
Start Blue/White
MS CAN High Gray/Orange
MS CAN Low Violet/Orange
HS CAN high White/Blue
HS CAN Low White
Driver Door Trigger Green/Violet
Trunk/Hatch Release Brown
Lock White/Brown
Unlock Blue/Brown
20
Pin Polarity Location
4 Data PATS connector at ignition switch
3 Data PATS connector at ignition switch
7 (-) Power liftgate switch
7 (-) Headlight Switch
5 (-) Headlight Switch
9 (+) Ignition Switch
7 (+) Ignition Switch
5 (+) Ignition Switch
1 (+) Ignition Switch
3 (+) Ignition Switch
10 (+) Ignition Switch
3 Data OBDII Diagnostic Connector
11 Data OBDII Diagnostic Connector
6 Data OBDll diagnostic connector.
14 Data OBDll diagnostic connector.
14 N.C. BCM/SJB in passenger kick
7 (-) BCM/SJB in passenger kick
17 (-) SJB in passenger kick
4 (-) SJB in passenger kick
Connector Information
© 2017-06-20 Directed. All rights reserved.
Color Pins Ref.
Black 4 A
Black 4 A
Black 8 H
Gray 10 C
Gray 10 C
Gray 10 B
Gray 10 B
Gray 10 B
Gray 10 B
Gray 10 B
Gray 10 B
Black 16 D
Black 16 D
Black 16 D
Black 16 D
Gray 26 F
Gray 26 F
Gray 26 F
Gray 26 F
DS4+ FORD6
