Directed DIRECTECHS DS4+ Installation Manual page 12

Wire Information
Function Color
Ford Expedition 2015-2016
RX Blue/Gray
TX Violet/Brown
Power Liftgate Gray/Yellow
Headlight Switch Ground Black/White
Parking Light Gray
12V Green/Red
Accessory Violet/Green
Ignition White/Orange
Keysense Blue/Gray
Start Blue/White
MS CAN High Gray/Orange
MS CAN Low Violet/Orange
HS CAN High White/Blue
HS CAN Low White
Driver Door Trigger Green/Violet
Lock White/Brown
Unlock Blue/Brown
Trunk/Hatch Release Brown
Ford Expedition (SA Key) 2011-2014
RX Blue/Gray
TX Violet/Brown
Power Liftgate Gray/Yellow
Headlight Switch Ground Black/White
Parking Light Blue/Gray
12V Blue/Red
Accessory Brown/Yellow
Ignition White/Orange
Keysense Blue/Gray
Start Blue/White
MS CAN High Gray/Orange
MS CAN Low Violet/Orange
HS CAN High White/Blue
HS CAN Low White
Driver Door Trigger Green/Violet
Lock White/Brown
Unlock Blue/Brown
Trunk/Hatch Release Brown
12
Pin Polarity Location
4 Data P.A.T.S. connector at ignition switch.
3 Data P.A.T.S. connector at ignition switch.
7 (-) Power liftgate switch.
7 (-) Headlight switch
2 (-) Headlight switch
4 (+) Ignition switch
7 (+) Ignition switch
1 (+) Ignition switch
5 (+) Ignition switch
7 (+) Ignition switch
3 Data OBDII diagnostic connector.
11 Data OBDII diagnostic connector.
6 Data OBDll diagnostic connector.
14 Data OBDll diagnostic connector.
9 Cut BCM/SJB in passenger kick panel.
6 (-) BCM/SJB in passenger kick panel.
8 (-) BCM/SJB in passenger kick panel.
23 (-) BCM/SJB in passenger kick panel.
4 Data P.A.T.S. connector at ignition switch.
3 Data P.A.T.S. connector at ignition switch.
7 (-) Power liftgate switch.
7 (-) Headlight switch
5 (-) Headlight switch
8 (+) Ignition switch
7 (+) Ignition switch
1 (+) Ignition switch
3 (+) Ignition switch
10 (+) Ignition switch
3 Data OBDII diagnostic connector.
11 Data OBDII diagnostic connector.
6 Data OBDll diagnostic connector.
14 Data OBDll diagnostic connector.
14 Cut BCM/SJB in passenger kick panel.
17 (-) BCM/SJB in passenger kick panel.
4 (-) BCM/SJB in passenger kick panel.
20 (-) BCM/SJB in passenger kick panel.
Connector Information
© 2017-06-20 Directed. All rights reserved.
Color Pins Ref.
Black 4 A
Black 4 A
Black 8 H
Gray 10 C
Gray 10 C
Gray 7 B
Gray 7 B
Gray 7 B
Gray 7 B
Gray 7 B
Black 16 D
Black 16 D
Black 16 D
Black 16 D
Gray 26 F
Gray 26 F
Gray 26 F
Gray 26 F
Black 4 A
Black 4 A
Black 8 H
Gray 10 C
Gray 10 C
Gray 10 B
Gray 10 B
Gray 10 B
Gray 10 B
Gray 10 B
Black 16 D
Black 16 D
Black 16 D
Black 16 D
Gray 26 F
Gray 26 F
Gray 26 F
Gray 26 F
DS4+ FORD6
