Directed DIRECTECHS DS4+ Installation Manual page 11

Wire Information
Function Color
Ford Escape 2008-2012
RX Violet/Gray
TX Yellow/Orange
Headlight Switch Ground Black/Blue
Parking Lights Blue/Gray
12V Blue/Red
Accessory Violet/Green
Ignition White/Orange
Keysense Blue/Gray
Start Blue/White
MS CAN High Gray/Orange
MS CAN Low Violet/Orange
HS CAN High White/Blue
HS CAN Low White
Driver Door Trigger Green/Violet
Trunk/Hatch Release Brown
Lock Blue/Green
Unlock Yellow/Violet
Ford Escape Hybrid 2008-2012
RX Violet/Gray
TX Yellow/Orange
Headlight Switch Ground Black/Blue
Parking Lights Blue/Gray
12V Blue/Red
Accessory Violet/Green
Ignition White/Orange
Keysense Blue/Gray
Start Blue/White
MS CAN High Gray/Orange
MS CAN Low Violet/Orange
HS CAN High White/Blue
HS CAN Low White
Driver Door Trigger Green/Violet
Trunk/Hatch Release Brown
Lock Blue/Green
Unlock Yellow/Violet
11
Pin Polarity Location
4 Data PATS connector at ignition switch
3 Data PATS connector at ignition switch
7 (-) Headlight Switch
5 (-) Headlight Switch
4 (+) Ignition Switch
6 (+) Ignition Switch
1 (+) Ignition Switch
5 (+) Ignition Switch
7 (+) Ignition Switch
3 Data OBDII Diagnostic Connector
11 Data OBDII Diagnostic Connector
6 Data OBDII Diagnostic Connector
14 Data OBDII Diagnostic Connector
14 Cut BCM/SJB in passenger side center console
7 (-) BCM/SJB in passenger side center console
17 (-) SJB in passenger side center console
4 (-) SJB in passenger side center console
4 Data PATS connector at ignition switch
3 Data PATS connector at ignition switch
7 (-) Headlight Switch
5 (-) Headlight Switch
4 (+) Ignition Switch
6 (+) Ignition Switch
1 (+) Ignition Switch
5 (+) Ignition Switch
7 (+) Ignition Switch
3 Data OBDII Diagnostic Connector
11 Data OBDII Diagnostic Connector
6 Data OBDII Diagnostic Connector
14 Data OBDII Diagnostic Connector
14 Cut BCM/SJB in passenger side center console
7 (-) BCM/SJB in passenger side center console
17 (-) SJB in passenger side center console
4 (-) SJB in passenger side center console
Connector Information
© 2017-06-20 Directed. All rights reserved.
Color Pins Ref.
Black 4 A
Black 4 A
Gray 10 C
Gray 10 C
Gray 7 B
Gray 7 B
Gray 7 B
Gray 7 B
Gray 7 B
Black 16 D
Black 16 D
Black 16 D
Black 16 D
Gray 26 E
Gray 26 E
Gray 26 E
Gray 26 E
Black 4 A
Black 4 A
Gray 10 C
Gray 10 C
Gray 7 B
Gray 7 B
Gray 7 B
Gray 7 B
Gray 7 B
Black 16 D
Black 16 D
Black 16 D
Black 16 D
Gray 26 E
Gray 26 E
Gray 26 E
Gray 26 E
DS4+ FORD6
