Directed DIRECTECHS DS4+ Installation Manual page 13

Wire Information
Function Color
Ford F150 (SA Key) 2011-2014
RX Violet/Gray
TX Yellow/Orange
12V Green/Red
Accessory Violet/Green
Ignition White/Orange
Keysense Blue/Gray
Start Blue/White
Headlight Switch Ground Black
Parking Light Gray
MS CAN High Gray/Orange
MS CAN Low Violet/Orange
HS CAN High White/Blue
HS CAN Low White
Driver Door Trigger Green/Violet
Lock Blue/Green
Unlock Yellow/Violet
Ford F250 2016
RX Yellow/Orange
TX Violet/Gray
12V Green/Red
Accessory Violet/Green
Ignition White/Orange
Keysense Blue/Gray
Start Blue/White
Headlight Switch Ground Black/Gray
Parking Light Yellow/Orange
MS CAN High Gray/Orange
MS CAN Low Violet/Orange
HS CAN High White/Blue
HS CAN Low White
Driver Door Trigger Green/Violet
Lock Blue/Green
Unlock Yellow/Violet
13
Pin Polarity Location
4 Data P.A.T.S. connector at ignition switch.
3 Data P.A.T.S. connector at ignition switch.
4 (+) Ignition switch
6 (+) Ignition switch
1 (+) Ignition switch
5 (+) Ignition switch
7 (+) Ignition switch
3 (-) Headlight switch
2 (-) Headlight switch
3 Data OBDII diagnostic connector.
11 Data OBDII diagnostic connector.
6 Data OBDll diagnostic connector.
14 Data OBDll diagnostic connector.
9 Cut BCM/SJB in passenger kick panel or at driver kick panel harness. Black
6 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Black
8 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Black
4 Data P.A.T.S. connector at ignition switch.
3 Data P.A.T.S. connector at ignition switch.
4 (+) Ignition switch
6 (+) Ignition switch
1 (+) Ignition switch
5 (+) Ignition switch
7 (+) Ignition switch
3 (-) Headlight switch
2 (-) Headlight switch
3 Data OBDII diagnostic connector.
11 Data OBDII diagnostic connector.
6 Data OBDll diagnostic connector.
14 Data OBDll diagnostic connector.
9 Cut BCM/SJB in passenger kick panel or at driver kick panel harness. Black
6 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Black
8 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Black
Connector Information
© 2017-06-20 Directed. All rights reserved.
Color Pins Ref.
Black 4 A
Black 4 A
Black 7 B
Black 7 B
Black 7 B
Black 7 B
Black 7 B
Gray 10 C
Gray 10 C
Black 16 D
Black 16 D
Black 16 D
Black 16 D
26 F or G
26 F or G
26 F or G
Black 4 A
Black 4 A
Black 7 B
Black 7 B
Black 7 B
Black 7 B
Black 7 B
Gray 10 C
Gray 10 C
Black 16 D
Black 16 D
Black 16 D
Black 16 D
26 F or G
26 F or G
26 F or G
DS4+ FORD6
