MIXVIBES CROSS DJ User Manual page 20

MIXVIBES
SOFTWARE
USB
9V
0.5A POWER
DC IN OFF USB
MICROPHONE
5 connect the u-mIX control pro with the uSB cable to your computer.
6 Switch the u-mIX control pro on by setting the on/off switch at the rear
panel of the controller to uSB. If you are using Windows and if this is the
first time you have switched the controller on, please wait until the neces-
sary drives are installed.
7
launch croSS DJ.
8 open the File menu and click Preferences. click the Audio tab to
open the audio settings panel. Here you can configure your audio
settings.
9 open the upper list box audio Device and select MixVibes ASIO U-MIX CON-
TROL PRO. you can leave the settings for sample rate and buffer size at
their default values.
open the list box Routing Mode and select External Mixer. take a look at
10
the diagram in the lower part of the dialog box. you can see that the croSS
mIXer connects DIrect a, i.e. the output of player a, to output 1 of your
soundcard. DIrect B is connected to output 2.
OUTPUT 3/4 OUTPUT 1/2
R L
R L R L
MIN MAX MIN MAX
TOUCH S E NS OR
LE VE L C.F. CUR VE
MIXER
Connect and Configure your Hardware
INPUT 3/4 INPUT 1/2
LN PH LN PH
R L R L
SPEAKERS HEADPHONES
L R
20
