MIXVIBES CROSS DJ User Manual page 18

MIXVIBES
SOFTWARE
USB
9V
0.5A POWER
DC IN OFF USB
3 If you wish to use a microphone connect it to the microphone input on the
front panel of your u-mIX control pro.
4 connect the u-mIX control pro with the uSB cable to your computer.
5 Switch the u-mIX control pro on by setting the on/off switch at the rear
panel of the controller to uSB. If you are using Windows and if this is the
first time you have switched the controller on, please wait until the neces-
sary drives are installed.
6
launch croSS DJ.
7 open the File menu and click Preferences. click the Audio tab to
open the audio settings panel. Here you can configure your audio
settings.
8 open the upper list box audio Device and select MixVibes ASIO U-MIX CON-
TROL PRO. you can leave the settings for sample rate and buffer size at
their default values.
open the list box Routing Mode and select Dual Stereo. this routing option
9
is to be used for internal mixing mode and if you use an audio interface with
two stereo outputs.
10 open the list box Output 1. on Windows select U-Mix Control Pro 1/U-Mix
Control Pro 2 and on oS X select output 1/2, if these outputs are not al-
ready selected. this output receives the master out signal.
OUTPUT 3/4 OUTPUT 1/2
R L
R L R L
MIN MAX MIN MAX
TOUCH S E NS OR
LE VE L C.F. CUR VE
MICROPHONE
Connect and Configure your Hardware
SPEAKERS
INPUT 3/4 INPUT 1/2
LN PH LN PH
R L R L
HEADPHONES
L R
18
