MIXVIBES CROSS DJ User Manual page 40

Some of the controls do not have an on/off state, like the FX On/Off control
you saw earlier. they are used only to trigger an action, like setting the in-
put focus as activate next player does. for these controls the presets Trig-
ger Button and Trigger Note are available. If you use the preset Trigger
Button you can activated the Auto-Repeat option as shown in the previous
image. for the Trigger Note preset this option is not available.
this ends the introduction into how to map your own controls.
Importing a Mapping
If you have found a mIDI preset for your controller on the mixVibes forum or if you
received one from another croSS DJ user, perform the following steps to import
the mapping.
1 open the File menu and click Preferences. open the MIDI tab on
the Preferences dialog.
2
Select your mIDI device by clicking on its tab.
3 click the Import Controller Mapping button in the lower part of the
Controller list.
4 Browse to the folder with the mapping file (file extensions .map-
pings, .mappings.xml), select the file you want to import and click Open.
5 assign the imported mapping to the mIDI device by clicking the picture of
the mapping in list Controller.
Connect and Configure your Hardware
