TLP Pro 720C • Setup Guide
Overview
The Extron TLP Pro 720C is a 7 inch Cable Cubby touchpanel with a flip-up, 800x480 LCD touchscreen with 18-bit color depth.
It is ideal for any AV application requiring a full-size, Cable Cubby touchpanel with a customizable interface. This guide provides
instructions for experienced installers to mount and install a TLP Pro 720C touchpanel. For more complete instructions, see the
TLP Pro 720C User Guide, at www.extron.com.
Setup Checklist
Get Ready
… Download and install the latest version of the following software (available from www.extron.com):
… GUI Designer — For designing layouts for Extron TouchLink
… Global Configurator
processor and touchpanel.
Toolbelt — Provides device discovery, device information, firmware updates, and configuration of network settings,
…
system utilities, and user management for TouchLink Pro devices.
Global Scripter
…
NOTE:
All four software programs are available from www.extron.com.
Obtain the following network information from your network administrator:
…
DHCP status (on or off). If DHCP is off, you will also require
…
… IP address
Username — This can be either admin or user.
…
Passwords — The factory configured passwords for all accounts on this device have been set to the device serial
…
number. Passwords are case sensitive.
NOTE:
If the device is reset to default settings, the password will be the default password configuration. The default
password is extron (for either admin or user).
… Make a note of the touchpanel MAC address.
… Make sure you are familiar with all the included parts and have all the
Included Parts
Table Clamps
TLP Pro 720C
NOTES:
*
Inside the US, the TLP Pro 720C can be purchased with or without an AC
power module. Outside the US, see
module for your country.
†
Active or Passive AAPs must be purchased separately (see
com).
Included Parts
Figure 1.
®
Professional or Global Configurator Plus — For setting up and configuring the control
® — Provides an integrated development environment for Extron control systems programming.
… Subnet mask
AC Power Module*
Zip Ties Extron
Removal Tool
www.extron.com
®
Pro touchpanels and third party touch interfaces.
… Gateway
Tools Required for Installation
Blank AAPs Pass-thru AAPs
1 Pos 2 Pos 3 Pos
AAP Shelf Bracket Kits
(2 brackets/kit)
#4−40 Screws
and Nuts
to find an AC power
www.extron.
(see page 2).
AC Power Module* 1
Pass-through AAPs 3
†
Blank AAPs 6
1-position bracket kit 0
2-position bracket kit 3
3-position bracket kit 1
0
3
6
1
4
1
1
