M3422 - ITech IT-M3400 Series User Manual

11.2 IT-M3422
Parameter
Rated value( 0 ℃-40
℃)
CC
CV
Internal Resistance
(CV Priority mode)
CP
CR mode(CC Priority
mode)
Read-back current
Read-back Voltage
Read-back Power
Temperature
Coefficient
Output Voltage
Output Current
Output Power
Min. operating voltage
Range
Setup Resolution
Accuracy
Range
Setup Resolution
Accuracy
Range
Setup Resolution
Accuracy
Range
Setup Resolution
Accuracy
Range
Resolution
Accuracy
Output Read-back
Range
Resolution
Accuracy
Range
Resolution
Accuracy
Range
Resolution
Accuracy
Temperature Coefficient
Voltage Temperature
Coefficient
Copyright © Itech Electronic Co., Ltd.
IT-M3422 V1.2
0-60V
-30A~30A
-400W~400W
6V at -30A
-30A~30A
10mA
≤0.1%+0.1%FS
0-60V
<0.1% Umax
0-1000mΩ
0.1mΩ
2%*Rmax
-400W~400W
0.1W
<1.0% Pmax
0.6-1000Ω
Min.0.1Ω
Rmin：(Vreal-Vmax*0.1%)/Rset -Imax*0.2%
Rmax：(Vreal+Vmax*0.1%)/Rset +Imax*0.2%
-30A~30A
≤0.1%+0.1%FS
0-60V
<0.1% Umax
-400W~400W
0.1W
<1% Pmax
100ppm/℃
Technical Specification
1mV
1mA
1mV
