1.5 Home-Screen Overview

The screen information displayed as below.
No.
1
2
3
Name Description
•
•
•
•
Temperature Used to measure the temperature of DUT.
measure
terminals
System Bus Used for communication between instruments in
parallel operation, multichannel operation and
synchronized operation features.
AC power input Used to connect AC power to start instrument,
terminals supports 110 V or 220 V.
Name Description
Output Voltage Displays the present output voltage value.
Output Current Displays the present output current value.
Voltage Setting Displays the present voltage setting value.You can
value change these value by pressing the [V-set] key on
the front panel.
Copyright © Itech Electronic Co., Ltd.
USB/LAN
GPIB
RS-232/CAN
Analog interface/RS-485
