Interfaces
Figure 2–4. Samtec Connector's Header
.78 REF
.571
(29 EQ Spaces @ .0197)
.150 REF
02
01
.036 REF
2–10
Cyclone III FPGA Starter Board
Table 2–8
lists HSMC A connector board reference and manufacturing
information.
Table 2–8. HSMC A Connector Manufacturing Information
Board Reference
J1
The HSMC uses the Samtec connector's header provided on the board.
Figure 2–4
shows the outline of the Samtec header.
2.413
((90 POS / 30 x .7875) + .050)
.626 REF
DP Bank
Table 2–9
lists the HSMC Port A interface pins. Signal names and
directions are relative to the Cyclone III FPGA. (The HSMC is operating
as the host.)

General User Interfaces

To allow you to fully leverage the I/O capabilities of the Cyclone III
device, the following are available on the board (remaining I/Os are
connected to additional board resources):
Push buttons: System and user reset, and user-defined push buttons
LEDs: Board-specific and user-defined LEDs
Some of the board's buttons and LEDs have a specific board function
while others are user-defined and are provided to control FPGA designs.
Reference Manual
Description
Manufacturer
High speed
Samtec
Mezzanine card
connector
.006 REF
Manufacturer
Part Number
ASP-12953-01
.245 REF
.285 REF
Altera Corporation
October 2007
