Page 1 QuickScan™ QD2590 PRODUCT REFERENCE GUIDE General Purpose Corded Area Imager Bar Code Reader...
Page 2 QuickScan is a trademark of Datalogic S.p.A. and/or its affiliates, registered in the U.S. The Bluetooth word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks by Datalogic S.p.A. and/or its affiliates is under license. All other trademarks and brands are property of their respective owners.
Page 3: Table Of Contents
Interface Selection ......................11 Configuring the Interface ....................11 Customizing Configuration Settings ................. 15 Using the Programming Bar Codes ....................15 Datalogic Aladdin™ Utility ........................15 Interface Settings ..........................15 Configuring Other Features ......................16 Software Version Transmission .......................16 Resetting the Product Configuration to Defaults ................16 Restore Custom Default Configuration ..................16...
Page 4 RS-232 INTERFACE .......................21 RS-232 STANDARD SETTINGS ......................22 Baud Rate ..........................22 Data Bits ............................ 23 Stop Bits ............................ 23 Parity ............................24 Handshaking Control ........................ 25 RS-232/USB-COM INTERFACES ..................26 RS-232/USB-COM SETTINGS ......................27 Intercharacter Delay ......................... 27 Beep On ASCII BEL ........................28 Beep On Not on File ........................28 ACK NAK Options ........................
Page 5 Stand Mode/Object Detection Sensitivity .................84 Stand Mode/Object Detection Illumination Off Time ...............85 Corded Stand Mode ........................85 Dock Detection Beep .........................86 LED AND BEEPER INDICATORS .......................87 Power On Alert ..........................87 Good Read Beep Type .......................87 Good Read Beep Frequency .....................88 Good Read Beep Length ......................89 Good Read Beeper Volume / Vibration ..................90 Silent Mode ..........................91 RGB Good Read Enable ......................91...
Page 6 GS1 DATABAR™ OMNIDIRECTIONAL ....................119 GS1 DataBar Omnidirectional Enable/Disable ..............119 GS1 DataBar Omnidirectional to GS1-128 Emulation ............119 GS1 DATABAR™ EXPANDED ......................120 GS1 DataBar Expanded Enable/Disable .................120 GS1 DataBar Expanded to GS1-128 Emulation ..............120 GS1 DataBar Expanded Length Control .................121 GS1 DataBar Expanded Set Length 1 ..................121 GS1 DataBar Expanded Set Length 2 ..................122 GS1 DATABAR™...
Page 7 Compressed 2 of 5 Set Length 2 ....................153 DATALOGIC 2 OF 5 ..........................154 Datalogic 2 of 5 Enable/Disable ....................154 Datalogic 2 of 5 Check Character Calculation ................154 Datalogic 2 of 5 Check Character Transmission ..............155 Datalogic 2 of 5 Length Control ....................155 Datalogic 2 of 5 Set Length 1 ....................156...
Page 8 CODE 11 ............................173 Code 11 Enable/Disable ......................173 Code 11 Check Character Calculation ..................173 Code 11 Check Character Transmission ................174 Code 11 Length Control ......................174 Code 11 Set Length 1 ......................175 Code 11 Set Length 2 ......................175 CODE 93 ............................176 Code 93 Enable/Disable ......................176 Code 93 Check Character Calculation ..................176 Code 93 Check Character Transmission ................177 Code 93 Length Control ......................177...
Page 9 MAXICODE ............................202 Maxicode Enable / Disable ......................202 Maxicode Primary Message Transmission ................202 Maxicode Length Control ......................203 Maxicode Set Length 1 ......................203 Maxicode Set Length 2 ......................204 PDF417 ............................205 PDF417 Enable / Disable ......................205 PDF417 Length Control ......................205 PDF417 Set Length 1 ......................206 PDF417 Set Length 2 ......................206 MICRO PDF417 ..........................207 Micro PDF417 Enable / Disable ....................207...
Page 10 Data Format ......................... 235 Data Editing .............................235 Please Keep In Mind.......................235 Global Prefix/Suffix .........................236 Example: Setting a Prefix .......................236 Global AIM ID ...........................237 Label ID ............................238 Label ID: Pre-loaded Sets .......................238 Label ID: Set Individually Per Symbology ................240 Character Conversion ........................242 Scanning Features ......................
Page 11: Preface
Programming can alternatively be performed using the Datalogic Aladdin™ Configura- tion application, which is available from the Datalogic website listed on the back cover of this manual. This multi-platform utility program allows device configuration using a PC.
Page 12: Manual Conventions
TECHNICAL SUPPORT Support Through the Website Datalogic provides several services as well as technical support through its website. Log on to (www.datalogic.com). For quick access, from the home page click on the search icon , and type in the name of the product you’re looking for.
Page 13: Chapter 1. Introduction
Green Spot confirms the good read, being perfectly centered on the barcode and between the two triangles. Very responsive at the pull of the trigger, the QuickScan QD2590 provides a superior robustness for its class of products, thanks to an accurate design and quality of parts, right there where the product is mostly stressed.
Page 14: Programming The Reader
Aladdin also facilitates image capturing. In addition, Aladdin makes it easy to upgrade the handheld’s firmware, to attain the benefits of new reader features. Reference the Datalogic Aladdin™ Online Help for more details. Aladdin is available for download free of charge on the Datalogic website.
Page 15: Chapter 2. Setup
CHAPTER 2 SETUP UNPACKING Check carefully to ensure the reader and any cables or accessories ordered are present and undamaged. If any damage occurred during shipment, contact " Technical Support" on page xii SETTING UP THE QUICKSCAN™ QD2590 READER Follow the steps provided in this section to connect and get your reader up and commu- nicating with its host: 1.
Page 16: Connect Host Interface
SETUP CONNECT HOST INTERFACE The reader kit you ordered to match your interface should provide a compatible cable for your installation. If this is not so, contact " Technical Support" on page xii The reader can communicate using the interfaces illustrated below. For corded versions, connect the reader cable by inserting the cable into the handle as shown in the following Figure.
Page 17: Usb Connection
CONNECT HOST INTERFACE USB Connection Connect the reader to a USB port on the terminal/PC using the correct USB cable for the interface type you ordered. USB: Select to communicate either by USB OEM, USB COM STD, or USB Keyboard inter- face types by scanning the appropriate interface type bar codes available in this manual.
Page 18: Stand Installation
SETUP STAND INSTALLATION Hands-Free Stand/Holder An accessory is available which holds the reader (except those with integrated stand) at a convenient angle, allowing hands free scanning of items. It can also be used as a holder. The holder “cup” can be positioned in any of the angles shown in the figure below.
Page 19: Setting Up The Quickscan™ Qd2590 Reader
SETTING UP THE QUICKSCAN™ QD2590 READER SETTING UP THE QUICKSCAN™ QD2590 READER Follow the steps below to connect and get your reader up and communicating with its host. 1. Select the Interface Type on page 11 PRODUCT REFERENCE GUIDE...
Page 20: Reader And Leds Description
SETUP READER AND LEDS DESCRIPTION provides information about the data transmission. LED on the gun Figure 5 - QuickScan™ QD2590 LEDs 1. Cable Release Hole 3. Scan Window 2. LED 4. Trigger QUICKSCAN™ QD2590...
Page 21: Using The Quickscan™ Qd2590
USING THE QUICKSCAN™ QD2590 USING THE QUICKSCAN™ QD2590 The QuickScan™ QD2590 normally functions by capturing and decoding codes. The aim- ing system is activated on trigger pull and indicates the center of the field of view which should be positioned over the bar code: Aiming System Relative Size and Location of Aiming System Pattern on 2D Matrix Symbol Relative Size and Location of Aiming System Pattern on Linear bar code...
Page 22 SETUP Relative Size and Location of Green Spot QUICKSCAN™ QD2590...
Page 23: Interface Selection
• RS232 OPOS • Keyboard WedgeIBM46XX port 9b (a specific cable is required) • Datalogic Magellan s' specific interface Scanner CONFIGURING THE INTERFACE Scan the programming bar code from the following section which selects the appropri- ate interface type to match the system the reader will be connected to. Next, proceed to the corresponding chapter in this manual (also listed in the table) to configure any desired settings and features associated with that interface.
Page 24 Select RS-232 OPOS USB-COM USB-COM (simulates RS-232 standard interface) $P,HA47,P Select USB-COM-STD USB-Composite (combines USB-KBD emulation and USB-COM $P,HA4D,P Select USB-Composite a. USB-COM driver needs to be installed for these interfaces to work. Please download it from www.datalogic.com QUICKSCAN™ QD2590...
Page 25 Select USB HID POS USB Toshiba TEC $P,HA41,P Select USB Toshiba TEC Datalogic Magellan Scanners' specific interface, USB AUX $P,HA40,P Select Datalogic Magellan Scanners' USB AUX Datalogic Magellan RS232 AUX port $P,HA43,P Magellan RS232 AUX port USB-OEM USB-OEM (can be used for OPOS/UPOS/JavaPOS)
Page 26 SETUP KEYBOARD AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95 w/Standard Key Encoding $P,HA29,P Select KBD-AT Keyboard Wedge for IBM AT PS2 with standard key encoding but without external keyboard $P,HA11,P Select KBD-AT-NK AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95 w/Alternate Key $P,HA26,P Select KBD-AT-ALT...
Page 27: Customizing Configuration Settings
Datalogic Aladdin™ is a multi-platform utility program providing a quick and user- friendly configuration method via the RS-232/USB-COM interface. The Aladdin utility is available on the Datalogic website. Aladdin allows you to program the reader by select- ing configuration commands through a user-friendly graphical interface running on a PC.
Page 28: Configuring Other Features
SETUP Configuring Other Features If your installation requires different programming than the standard factory default settings, the following sections of this manual allow configuration of non-interface-spe- cific settings you might require: Configuration Using Bar Codes: General Features includes programming for scanning, beeper and LED indicators and other such universal settings.
Page 29: Restore Factory Configuration
CUSTOMIZING CONFIGURATION SETTINGS Restore Factory Configuration If you want to restore the Factory Configuration for your reader, scan either the Restore USA Factory Configuration bar code or the Restore EU Factory Configuration bar code below. Both labels restore the reader configuration to the factory settings, including the interface type.
Page 30: Chapter 3. Configuration With Bar Codes
CHAPTER 3 CONFIGURATION WITH BAR CODES This and following sections provide programming bar codes to configure your reader by changing the default settings. For details about additional methods of programming, see " Customizing Configuration Settings" on page 15 NOTE: You must first enable your PowerScan to read bar codes in order to use this section.
Page 31: Symbology-Specific Parameters
CONFIGURATION PARAMETERS Symbology-specific parameters: define 1D Symbologies, starting on page 103 2D Symbologies, starting on page 189 options for all symbologies and provides the programming bar codes necessary for con- figuring these features. NOTE: You must first enable your reader to read bar codes in order to use this section.
Page 32: Global Interface Features
ENTER/EXIT PROGRAMMING MODE GLOBAL INTERFACE FEATURES The following interface features are configurable by all interface types. To set features specific to your interface, turn to that section of this manual. Host Commands — Obey/Ignore This option specifies whether the reader will obey or ignore host commands. When set to ignore, the reader will ignore all host commands except those necessary for: •...
Page 33: Interface
CONFIGURATION | RS-232 INTERFACE Use the programming bar codes in this chapter if modifications to the standard RS-232 interface settings are necessary to meet your system’s requirements. Additional settings which apply to both the RS-232 and USB interfaces are available in RS-232/USB-COM Settings, starting on page 27 SECTION CONTENTS...
Page 34: Rs-232 Standard Settings
ENTER/EXIT PROGRAMMING MODE RS-232 INTERFACE RS-232 STANDARD SETTINGS Baud Rate Baud rate is the number of bits of data transmitted per second. Set the reader's baud rate to match the baud rate setting of the host device. With an improper baud rate set- ting, data may not reach the host correctly.
Page 35: Data Bits
RS-232 STANDARD SETTINGS ENTER/EXIT PROGRAMMING MODE Data Bits This parameter allows the reader to interface with devices requiring a 7-bit or 8-bit ASCII protocol for sending and receiving data. $CR2DA00 7 Data Bits $CR2DA01  8 Data Bits NOTE: Handheld and base station models support the 8-bit ASCII protocol. The 7-bit ASCII protocol support is subject to specific firmware release.
Page 36: Parity
ENTER/EXIT PROGRAMMING MODE RS-232 INTERFACE Parity This feature specifies parity required for sending and receiving data. A parity check bit is the most significant bit of each ASCII coded character. Select the parity type according to host device requirements. • Select None when no parity bit is required.
Page 37: Handshaking Control
RS-232 STANDARD SETTINGS ENTER/EXIT PROGRAMMING MODE Handshaking Control The data interface consists of an RS-232 port designed to operate either with or without the hardware handshaking lines, Request to Send (RTS), and Clear to Send (CTS). Hand- shaking Control includes the following options: •...
Page 38: Rs-232/Usb-Com Interfaces
CONFIGURATION | RS-232/USB-COM INTERFACES SECTION CONTENTS • Intercharacter Delay • ACK NAK Timeout Value • Beep On ASCII BEL • ACK NAK Retry Count • Beep On Not on File • ACK NAK Error Handling • ACK NAK Options • Indicate Transmission Failure •...
Page 39: Rs-232/Usb-Com Settings
RS-232/USB-COM SETTINGS ENTER/EXIT PROGRAMMING MODE RS-232/USB-COM SETTINGS Intercharacter Delay This parameter specifies the intercharacter delay between the end of one character and the beginning of the next. The delay can be set within a range of zero (0) to 990 millisec- onds in 10ms increments.
Page 40: Beep On Ascii Bel
ENTER/EXIT PROGRAMMING MODE RS-232/USB-COM INTERFACES Beep On ASCII BEL When this parameter is enabled, the reader issues a beep when a <BEL> character is detected on the RS-232 serial line. <BEL> is issued to gain a user's attention to an illegal entry or other important event.
Page 41: Ack Nak Options
RS-232/USB-COM SETTINGS ENTER/EXIT PROGRAMMING MODE ACK NAK Options This enables/disables the ability of the reader to support the RS-232 ACK/NAK protocol. When configured, the reader and/or host sends an “ACK” when it receives data prop- erly, and sends “NAK” when the data is in error. Options are: •...
Page 42: Ack Character
ENTER/EXIT PROGRAMMING MODE RS-232/USB-COM INTERFACES ACK Character This setting specifies an ASCII character or hex value to be used as the ACK character. ASCII characters or any hex value from 0 to 0xFF can be selected. See " ACK Character" on for more detailed programming instructions.
Page 43: Ack Nak Timeout Value
RS-232/USB-COM SETTINGS ENTER/EXIT PROGRAMMING MODE ACK NAK Timeout Value This option specifies the amount of time the reader waits for an ACK character from the host following label transmission. The selectable timeout range is 200 milliseconds to 15,000ms (15 seconds) in 200ms increments. A selection of 0 disables the timeout. See "...
Page 44: Ack Nak Error Handling
ENTER/EXIT PROGRAMMING MODE RS-232/USB-COM INTERFACES ACK NAK Error Handling This feature specifies the method the reader uses to handle receive errors detected while waiting for an ACK character from the host. Options are: • Ignore errors detected • Process error as valid ACK character •...
Page 45: Disable Character
RS-232/USB-COM SETTINGS ENTER/EXIT PROGRAMMING MODE Disable Character Specifies the value of the RS-232 host command used to disable the reader. ASCII characters or any hex value from 0 to 0xFF can be selected. See " Disable Character" for more detailed programming instructions. on page 230 Setting to previously defined characters such as XON, XOFF, or host com- mands conflicts with normal operation of these characters.
Page 46: Keyboard Interface
CONFIGURATION | KEYBOARD INTERFACE SECTION CONTENTS OUNTRY starting on page 35 • Setting Country Mode THER EYBOARD ARAMETERS starting on page 50 • Encoding Type • Keyboard Send Control Characters • ALT Output Type • Wedge Quiet Interval • Caps Lock State •...
Page 47: Country Mode
SETUP ON PC TO USE ALT UNIVERSAL COUNTRY MODE This feature specifies the country/language supported by the keyboard. The Country Mode setting is ignored if the interface uses alternate key encoding. SETUP ON PC TO USE ALT UNIVERSAL 1. Open Registry Edit 2.
Page 48: Setting Country Mode
ENTER/EXIT PROGRAMMING MODE KEYBOARD INTERFACE Setting Country Mode $CKBCO00  United States $CKBCO01 French International (Belgian French) $CKBCO02 United Kingdom $CKBCO03 Danish $CKBCO04 French (France) $CKBCO05 German $CKBCO06 Italian QUICKSCAN™ QD2590...
Page 49 COUNTRY MODE ENTER/EXIT PROGRAMMING MODE Setting Country Mode (continued) $CKBCO07 Norwegian $CKBCO08 Portuguese (Portugal) $CKBCO09 Spanish $CKBCO0A Swedish $CKBCO0B Swiss French $CKBCO0C Japanese ASCII $CKBCO0D Hungarian PRODUCT REFERENCE GUIDE...
Page 50 ENTER/EXIT PROGRAMMING MODE KEYBOARD INTERFACE Setting Country Mode (continued) $CKBCO0E Czech $CKBCO0F SlovaK $CKBCO10 Romanian $CKBCO11 Croatian $CKBCO12 Polish_214 $CKBCO13 French Canadian Win7 $CKBCO14 Lithuanian QUICKSCAN™ QD2590...
Page 51 COUNTRY MODE ENTER/EXIT PROGRAMMING MODE Setting Country Mode (continued) $CKBCO17 Vietnamese $CKBCO18 Russian $CKBCO19 Arabic 101 $CKBCO1A Chinese ASCII $CKBCO1B Thai-Kedmanee $CKBCO1C Albanian $CKBCO1D Arabic 102 PRODUCT REFERENCE GUIDE...
Page 52 ENTER/EXIT PROGRAMMING MODE KEYBOARD INTERFACE Setting Country Mode (continued) $CKBCO1E Arabic 102 AZERTY $CKBCO1F Azeri Cyrillic $CKBCO20 Azeri Latin $CKBCO21 Belarusian $CKBCO22 Bosnian Cyrillic $CKBCO23 Bosnian Latin $CKBCO24 Bulgarian Cyrillic QUICKSCAN™ QD2590...
Page 53 COUNTRY MODE ENTER/EXIT PROGRAMMING MODE Setting Country Mode (continued) $CKBCO25 Bulgarian Latin $CKBCO26 Canadian French (Legacy) $CKBCO27 Canadian Multilingual $CKBCO28 Chinese (Simplified) $CKBCO29 Chinese (Traditional) $CKBCO2A Czech Programmers $CKBCO2B Czech QWERTY PRODUCT REFERENCE GUIDE...
Page 54 ENTER/EXIT PROGRAMMING MODE KEYBOARD INTERFACE Setting Country Mode (continued) $CKBCO2C Dutch Netherland $CKBCO2D Estonian $CKBCO2E Faeroese $CKBCO2F Finnish $CKBCO30 French (Canada) 2000/XP $CKBCO31 French (Canada) 95/98 $CKBCO32 Galician QUICKSCAN™ QD2590...
Page 55 COUNTRY MODE ENTER/EXIT PROGRAMMING MODE Setting Country Mode (continued) $CKBCO33 Greek $CKBCO34 Greek Latin $CKBCO35 Greek Polytonic $CKBCO36 Greek220 $CKBCO37 Greek220 Latin $CKBCO38 Greek319 $CKBCO39 Greek319 Latin PRODUCT REFERENCE GUIDE...
Page 56 ENTER/EXIT PROGRAMMING MODE KEYBOARD INTERFACE Setting Country Mode (continued) $CKBCO3A Hebrew Israel $CKBCO3B Hungarian_101KEY $CKBCO3C Icelandic $CKBCO3D Irish $CKBCO3E Italian_142 $CKBCO3F Japanese (Shift-JIS) $CKBCO40 Kazakh QUICKSCAN™ QD2590...
Page 57 COUNTRY MODE ENTER/EXIT PROGRAMMING MODE Setting Country Mode (continued) $CKBCO41 Korean (Hangul) $CKBCO42 Korean ASCII $CKBCO43 Kyrgyz Cyrillic $CKBCO44 Latin America $CKBCO45 Latvian $CKBCO46 Latvian QWERTY $CKBCO47 Lithuanian_IBM PRODUCT REFERENCE GUIDE...
Page 58 ENTER/EXIT PROGRAMMING MODE KEYBOARD INTERFACE Setting Country Mode (continued) $CKBCO48 Macedonian -FYROM $CKBCO49 Maltese_47KEY $CKBCO4A Mongolian-Cyrillic $CKBCO4B Polish Programmer $CKBCO4C Portuguese Brazil $CKBCO4D Portuguese Brazilian ABNT $CKBCO4E Portuguese Brazilian ABNT2 QUICKSCAN™ QD2590...
Page 59 COUNTRY MODE ENTER/EXIT PROGRAMMING MODE Setting Country Mode (continued) $CKBCO4F Romanian Legacy $CKBCO50 Romanian Programmer $CKBCO51 Romanian Standard $CKBCO52 Russian Typewriter $CKBCO53 Serbian Cyrillic $CKBCO54 Serbian Latin $CKBCO55 Slovak QWERTY PRODUCT REFERENCE GUIDE...
Page 60 ENTER/EXIT PROGRAMMING MODE KEYBOARD INTERFACE Setting Country Mode (continued) $CKBCO56 Slovenian $CKBCO57 Spanish Variation $CKBCO58 Swiss German $CKBCO59 Tatar $CKBCO5A Turkish F $CKBCO5B Turkish Q $CKBCO5C Ukrainian QUICKSCAN™ QD2590...
Page 61 COUNTRY MODE ENTER/EXIT PROGRAMMING MODE Setting Country Mode (continued) $CKBCO5D US Dvorak $CKBCO5E US Dvorak Left Hand $CKBCO5F US Dvorak Right Hand $CKBCO60 US English (Mac) $CKBCO61 US English (North American) $CKBCO62 US International $CKBCO63 Uzbek Cyrillic PRODUCT REFERENCE GUIDE...
Page 62: Other Keyboard Parameters
ENTER/EXIT PROGRAMMING MODE KEYBOARD INTERFACE OTHER KEYBOARD PARAMETERS Encoding Type $CENCO00  Encoding Type = Don’t Use Encoding $CENCO03 Encoding Type = UTF_8 $CENCO04 Encoding Type = Windows 874 $CENCO05 Encoding Type = Windows 932 $CENCO06 Encoding Type = Windows 936 $CENCO07 Encoding Type = Windows 949 $CENCO08...
Page 63 OTHER KEYBOARD PARAMETERS ENTER/EXIT PROGRAMMING MODE Encoding Type (continued) $CENCO09 Encoding Type = Windows 1250 $CENCO0A Encoding Type = Windows 1251 $CENCO0B Encoding Type = Windows 1252 $CENCO0C Encoding Type = Windows 1253 $CENCO0D Encoding Type = Windows 1254 $CENCO0E Encoding Type = Windows 1255 $CENCO0F Encoding Type = Windows 1256...
Page 64 ENTER/EXIT PROGRAMMING MODE KEYBOARD INTERFACE Encoding Type (continued) $CENCO10 Encoding Type = Windows 1257 $CENCO11 Encoding Type = Windows 1258 $CENCO12 Encoding Type = Windows 20866 $CENCO31 Encoding Type = Windows 54936 $CENCO13 Encoding Type = ISO 8859-1 $CENCO14 Encoding Type = ISO 8859-2 $CENCO15 Encoding Type = ISO 8859-3 QUICKSCAN™...
Page 65 OTHER KEYBOARD PARAMETERS ENTER/EXIT PROGRAMMING MODE Encoding Type (continued) $CENCO16 Encoding Type = ISO 8859-4 $CENCO17 Encoding Type = ISO 8859-5 $CENCO18 Encoding Type = ISO 8859-6 $CENCO19 Encoding Type = ISO 8859-7 $CENCO1A Encoding Type = ISO 8859-8 $CENCO1B Encoding Type = ISO 8859-9 $CENCO1C Encoding Type = ISO 8859-10...
Page 66 ENTER/EXIT PROGRAMMING MODE KEYBOARD INTERFACE Encoding Type (continued) $CENCO1D Encoding Type = ISO 8859-11 $CENCO1E Encoding Type = ISO 8859-13 $CENCO1F Encoding Type = ISO 8859-14 $CENCO20 Encoding Type = ISO 8859-15 $CENCO21 Encoding Type = ISO 8859-16 $CENCO22 Encoding Type = MS-DOS 437 $CENCO23 Encoding Type = MS-DOS 737 QUICKSCAN™...
Page 67 OTHER KEYBOARD PARAMETERS ENTER/EXIT PROGRAMMING MODE Encoding Type (continued) $CENCO24 Encoding Type = MS-DOS 775 $CENCO25 Encoding Type = MS-DOS 850 $CENCO26 Encoding Type = MS-DOS 852 $CENCO27 Encoding Type = MS-DOS 855 $CENCO28 Encoding Type = MS-DOS 857 $CENCO29 Encoding Type = MS-DOS 860 $CENCO2A Encoding Type = MS-DOS 861...
Page 68 ENTER/EXIT PROGRAMMING MODE KEYBOARD INTERFACE Encoding Type (continued) $CENCO2B Encoding Type = MS-DOS 862 $CENCO2C Encoding Type = MS-DOS 863 $CENCO2D Encoding Type = MS-DOS 865 $CENCO2E Encoding Type = MS-DOS 866 $CENCO2F Encoding Type = MS-DOS 869 $CENCO30 Encoding Type = Mac CP10000 QUICKSCAN™...
Page 69: Alt Output Type
OTHER KEYBOARD PARAMETERS ENTER/EXIT PROGRAMMING MODE ALT Output Type This option specifies the encode type of ALT Mode when the reader sends Output Key- board Data in Alt Mode. (Be aware that the reader may switch automatically between ALT mode & Normal Keyboard Scancode, to correctly display some characters that are not present in the current Keyboard Country).
Page 70: Caps Lock State
ENTER/EXIT PROGRAMMING MODE KEYBOARD INTERFACE Caps Lock State This option specifies the format in which the reader sends character data. This applies to Keyboard Wedge interfaces. This does not apply when an alternate key encoding key- board is selected. This does not apply to USB Keyboard. $CKBCL00 ...
Page 71: Keyboard Numeric Keypad
OTHER KEYBOARD PARAMETERS ENTER/EXIT PROGRAMMING MODE Keyboard Numeric Keypad This feature specifies if numeric characters will be sent using the standard keys or the numeric keypad. $CKBKP00  Keyboard Numeric Keypad = Standard Keys $CKBKP01 Keyboard Numeric Keypad = Numeric Keypad Keyboard Send Control Characters This feature is used by the Keyboard Wedge and USB Keyboard interfaces.
Page 72: Wedge Quiet Interval
ENTER/EXIT PROGRAMMING MODE KEYBOARD INTERFACE Wedge Quiet Interval This option specifies the amount of time to look for keyboard activity before the reader breaks the keyboard connection in order to transmit data to host. The selectable range for this feature is from 0 to 990ms in 10ms increments. See " Wedge Quiet Interval"...
Page 73: Intercode Delay
OTHER KEYBOARD PARAMETERS ENTER/EXIT PROGRAMMING MODE Intercode Delay Specifies the delay between labels transmitted to the host for this interface. The select- able range for this feature is from 0 to 99 seconds. See " Intercode Delay" on page 234 more detailed programming instructions To configure this feature, scan the ENTER/EXIT PRO- GRAMMING MODE bar code above, then the bar...
Page 74: Usb Keyboard Speed
ENTER/EXIT PROGRAMMING MODE KEYBOARD INTERFACE USB Keyboard Speed This option specifies the USB poll rate for a USB Keyboard. NOTE: This feature applies ONLY to the USB Keyboard interface. $CKBSP01  USB Keyboard Speed = 1ms $CKBSP02 USB Keyboard Speed = 2ms $CKBSP03 USB Keyboard Speed = 3ms $CKBSP05...
Page 75: Usb-Oem Interface
CONFIGURATION | USB-OEM INTERFACE SECTION CONTENTS • USB-OEM Device Usage PRODUCT REFERENCE GUIDE...
Page 76: Usb-Oem Device Usage
ENTER/EXIT PROGRAMMING MODE USB-OEM INTERFACE USB-OEM Device Usage The USB-OEM protocol allows for the reader to be identified as one of two different types of bar code reader. Depending on what other reader you may already have con- nected to a USB-OEM POS, you may need to change this setting to enable all devices to communicate.
Page 77: Ibm 46Xx Interface
CONFIGURATION | IBM 46XX INTERFACE SECTION CONTENTS • IBM 46xx Interface Options PRODUCT REFERENCE GUIDE...
Page 78: Ibm 46Xx Interface Options
ENTER/EXIT PROGRAMMING MODE IBM 46XX INTERFACE IBM 46xx Interface Options This setting provides for an interface specific control mechanism. Options are: • Obey — Obey Scanner Configuration Host Commands • Ignore — Ignore Scanner Configuration Host Commands $CIFO101  Interface Options = Obey Scanner Configuration Host Commands $CIFO102 Interface Options = Ignore Scanner Configuration...
Page 79: Data Format
CONFIGURATION | DATA FORMAT SECTION CONTENTS LOBAL ETTINGS starting on page 68 • Global Prefix/Suffix • Global AIM ID • Case Conversion • GS1-128 AIM ID • Character Conversion ABEL starting on page 71 • • Label ID Symbology Selection Label ID: Set Individually Per Symbology •...
Page 80: Global Settings
ENTER/EXIT PROGRAMMING MODE DATA FORMAT GLOBAL SETTINGS Global Prefix/Suffix Up to 20 ASCII characters may be added as a prefix (in a position before the bar code data) and/or as a suffix (in a position following the bar code data). See in “Ref- page 236 erences”...
Page 81: Case Conversion
GLOBAL SETTINGS ENTER/EXIT PROGRAMMING MODE Case Conversion This feature allows conversion of the case of all alphabetic characters to upper or lower case. NOTE: Case conversion affects ONLY scanned bar code data, and does not affect Label ID, Prefix, Suffix, or other appended data. $CLFCA00 ...
Page 82: Global Aim Id
ENTER/EXIT PROGRAMMING MODE DATA FORMAT Global AIM ID NOTE: This feature enables/disables addition of AIM IDs for all symbology types. AIM label identifiers (as opposed to custom characters you select yourself as with label identifiers) can be included with scanned bar code data. See for more detailed pro- gramming instructions.
Page 83: Label Id
LABEL ID ENTER/EXIT PROGRAMMING MODE LABEL ID A Label ID is a customizable code of up to three ASCII characters (each can be one of hex 0x01-0xFF), used to identify a bar code (symbology) type. It can be appended previous to or following the transmitted bar code data depending upon how this option is enabled.
Page 84: Label Id: Set Individually Per Symbology
ENTER/EXIT PROGRAMMING MODE DATA FORMAT Label ID: Set Individually Per Symbology This feature configures a Label ID individually for a single symbology. NOTE: This setting requires the scanning of bar codes from multiple sec- tions. See " Label ID: Set Individually Per Symbology" on page 240 for more detailed programming instructions.
Page 85: Label Id Symbology Selection
LABEL ID ENTER/EXIT PROGRAMMING MODE Label ID Symbology Selection This option selects the symbology for which a Label ID is to be configured. See " Label ID: for full instructions. Set Individually Per Symbology" on page 240 Make a mistake? Scan the CANCEL bar code to abort and not save the entry string.
Page 86 ENTER/EXIT PROGRAMMING MODE DATA FORMAT Label ID Symbology Selection (continued) $C32ID Set EAN-13/P2 Label ID Character(s) $C35ID Set EAN-13/P5 Label ID Character(s) $CISID Set ISBN Label ID Character(s) $CINID Set ISSN Label ID Character(s) $C8BID Set EAN-8 Label ID Character(s) $C82ID Set EAN-8 Label ID Character(s) $C85ID...
Page 87 LABEL ID ENTER/EXIT PROGRAMMING MODE Label ID Symbology Selection (continued) $CXBID Set GS1 DataBar Expanded Label ID Character(s) $CLBID Set GS1 DataBar Limited Label ID Character(s) $CC3ID Set Code 39 Label ID Character(s) $CP3ID Set Code 32 Label ID Character(s) $CCCID Set Code 39 CIP HR Label ID Character(s) $CC8ID...
Page 88 Label ID Symbology Selection (continued) $CHRID Set Interleaved 2 of 5 CIP HR Label ID Character(s) $CD2ID Datalogic 2 of 5 Label ID Character(s) $CS2ID Standard 2 of 5 Label ID Character(s) $CU2ID Industrial 2 of 5 Label ID Character(s)
Page 89 LABEL ID ENTER/EXIT PROGRAMMING MODE Label ID Symbology Selection (continued) $CC1ID Code 11 Label ID Character(s) $CMSID MSI Label ID Character(s) $CPLID Plessey Label ID Character(s) $CALID Anker Plessey Label ID Character(s) $CCMID Set Matrix 2 of 5 Label ID Character(s) PRODUCT REFERENCE GUIDE...
Page 90: Reading Parameters
CONFIGURATION | READING PARAMETERS SECTION CONTENTS CANNING EATURES starting on page 79 • Scan Mode • Stand Mode/Object Detection Sensitivity • Scanning Active Time • Stand Mode/Object Detection Illumination Off Time • Flash On Time • Corded Stand Mode • Flash Off Time •...
Page 91: Scanning Features
SCANNING FEATURES ENTER/EXIT PROGRAMMING MODE SCANNING FEATURES Scan Mode Selects the reader’s scan operating mode. See page 243 in “References” for descriptions. $CSNRM00  Scan Mode = Trigger Single $CSNRM01 Scan Mode = Trigger Hold Multiple $CSNRM02 Scan Mode = Trigger Pulse Multiple $CSNRM03 Scan Mode = Flashing $CSNRM04...
Page 92: Scanning Active Time
ENTER/EXIT PROGRAMMING MODE READING PARAMETERS Scanning Active Time This setting specifies the amount of time that the reader stays in scan ON state once the state is entered. The range for this setting is from 1 to 255 seconds in 1-second incre- ments.
Page 93: Flash Off Time
SCANNING FEATURES ENTER/EXIT PROGRAMMING MODE Flash Off Time This feature specifies the OFF time for the indicator LED while in Flash Mode. The select- able range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond incre- ments. See in “References”...
Page 94 ENTER/EXIT PROGRAMMING MODE READING PARAMETERS Double Read Timeout (continued) $CSNDR32 Double Read Timeout = 0.5 Second $CSNDR3C  Double Read Timeout = 0.6 Second $CSNDR46 Double Read Timeout = 0.7 Second $CSNDR50 Double Read Timeout = 0.8 Second $CSNDR5A Double Read Timeout = 0.9 Second $CSNDR64 Double Read Timeout = 1 Second QUICKSCAN™...
Page 95: Stand /Base Detection Behavior
SCANNING FEATURES ENTER/EXIT PROGRAMMING MODE Stand /Base Detection Behavior Specifies the behavior of the reader when stationary in a stand. There are two condi- tions which cause the reader to switch to Stand Mode/Object Detection: • The reader is configured to switch to Stand Mode/Object Detection when station- ary.
Page 96: Stand Mode/Object Detection Indication (Stand Mode Flash)
ENTER/EXIT PROGRAMMING MODE READING PARAMETERS Stand Mode/Object Detection Indication (Stand Mode Flash) This operation is useful for indicating when the reader is in Stand Mode. If enabled, the blue indicator will blink when Stand Mode scanning is active. $CSMFL00  Stand Mode/Object Detection Indication = Disable $CSMFL01 Stand Mode/Object Detection Indication = Enable...
Page 97: Stand Mode/Object Detection Illumination Off Time
SCANNING FEATURES ENTER/EXIT PROGRAMMING MODE Stand Mode/Object Detection Illumination Off Time Specifies the amount of time reader illumination stays off after pulling the trigger when in Stand Mode/Object Detection. The configurable range is 01 to 32 by 01 in increments of 500ms (500ms to 16 seconds).
Page 98: Dock Detection Beep
ENTER/EXIT PROGRAMMING MODE READING PARAMETERS Dock Detection Beep If enabled, when the Handheld reader is placed in a dock (base station or corded stand), it will beep. $CDDBE00  Dock Detection Beep = Disable $CDDBE01 Dock Detection Beep = Enable QUICKSCAN™...
Page 99: Led And Beeper Indicators
LED AND BEEPER INDICATORS ENTER/EXIT PROGRAMMING MODE LED AND BEEPER INDICATORS Power On Alert Disables or enables the indication (from the Beeper) that the reader is receiving power. $CBPPU00 Power On Alert = Disable (No Audible Indication) $CBPPU01  Power On Alert = Power-up Beep Good Read Beep Type Specifies whether the good read beep has a mono or bitonal beep sound.
Page 100: Good Read Beep Frequency
ENTER/EXIT PROGRAMMING MODE READING PARAMETERS Good Read Beep Frequency Adjusts the good read beep to sound at a selectable low, medium or high frequency, selectable from the list below. (Controls the beeper’s pitch/tone.) $CBPFR00 Good Read Beep Frequency = Low $CBPFR01 Good Read Beep Frequency = Medium $CBPFR02...
Page 101: Good Read Beep Length
LED AND BEEPER INDICATORS ENTER/EXIT PROGRAMMING MODE Good Read Beep Length $CBPLE06 Good Read Beep Length = 60 msec $CBPLE08  Good Read Beep Length = 80 msec $CBPLE0A Good Read Beep Length = 100 msec $CBPLE0C Good Read Beep Length = 120 msec $CBPLE0E Good Read Beep Length = 140 msec $CBPLE10...
Page 102: Good Read Beeper Volume / Vibration
ENTER/EXIT PROGRAMMING MODE READING PARAMETERS Good Read Beeper Volume / Vibration Selects the beeper volume (loudness) upon a good read beep. There are three select- able volume levels. In addition to three selectable volume levels, the user can also activate a vibration feed- back for good read.
Page 103: Silent Mode
LED AND BEEPER INDICATORS ENTER/EXIT PROGRAMMING MODE Silent Mode If needed, audible indications can be disabled by scanning the labels below. Please note that some important audible notifications are not muted in silent mode and other notifications are replaced by vibration or visual indications. All changes in audible notifications are summarized here: •...
Page 104: Rgb Good Read Color
ENTER/EXIT PROGRAMMING MODE READING PARAMETERS RGB Good Read Color Selects the good read LED color. $CRBCL00 RGB Good Read Color = RED $CRBCL01  RGB Good Read Color = GREEN $CRBCL02 RGB Good Read Color = BLUE QUICKSCAN™ QD2590...
Page 105: Good Read Led Duration
LED AND BEEPER INDICATORS ENTER/EXIT PROGRAMMING MODE Good Read LED Duration This feature specifies the amount of time that the Good Read LED remains on following a good read. The good read LED on time can be set within a range of 100 milliseconds to 25,500 milliseconds (0.1 to 25.5 seconds) in 100ms increments.
Page 106: Good Read: When To Indicate
ENTER/EXIT PROGRAMMING MODE READING PARAMETERS Good Read: When to Indicate This feature specifies when the reader will provide indication (beep and/or flash its green LED) upon successfully reading a bar code. $CBPIN00  Indicate Good Read = After Decode $CBPIN01 Indicate Good Read = After Transmit $CBPIN02 Indicate Good Read =...
Page 107: Green Spot Duration
LED AND BEEPER INDICATORS ENTER/EXIT PROGRAMMING MODE Green Spot Duration Specifies the duration of the good read pointer beam after a good read. $CLSSP00 Green Spot Duration = Disable (Green Spot is Off) $CLSSP01  Green Spot Duration = Short (300 msec) $CLSSP02 Green Spot Duration = Medium (500 msec) $CLSSP03...
Page 108: Illuminator Intensity
ENTER/EXIT PROGRAMMING MODE READING PARAMETERS Illuminator Intensity With the following settings the illumination intensity can modified if needed. $CLADI00 Set Illumination Intensity Level = Low $CLADI01 Set Illumination Intensity Level = Mid-Low $CLADI02 Set Illumination Intensity Level = Mid $CLADI03 Set Illumination Intensity Level = Mid-High $CLADI04 ...
Page 109: Camera Control
CAMERA CONTROL ENTER/EXIT PROGRAMMING MODE CAMERA CONTROL Aiming Pointer Enables/disables the aiming pointer for all symbologies. $CTAAP00 Aiming Pointer = Disable $CTAAP01  Aiming Pointer = Enable $CTAAP02 Aiming Pointer = Green Spot Aiming Duration Timer Specifies the frame of time the aiming pointer remains on after decoding a label, when in trigger single mode.The range for this setting is from 1 to 255 seconds in 1-second increments.
Page 110: Pick Mode
Pick Mode = Enable Mobile Phone Mode This mode is useful for scanning bar codes displayed on a mobile phone. Other options for this feature can be configured using the Datalogic Aladdin application. $CSNPE00 Mobile Phone Mode = Disable $CSNPE01 ...
Page 111: Mobile Phone Saturation Rate
CAMERA CONTROL ENTER/EXIT PROGRAMMING MODE Mobile Phone Saturation Rate This specifies the minimum number of saturated pixels (every 1000 pixels) in the image in order to activate the Mobile Phone mode. $CSNPS00  Mobile Phone Saturation Rate = 00 $CSNPS01 Mobile Phone Saturation Rate = 01 $CSNPS02 Mobile Phone Saturation Rate = 02...
Page 112: Decode Negative Image
Decode Negative Image = Disable $CIPVR01 Decode Negative Image = Enable Image Capture For information and a list of options for Image Capture, use the Datalogic Aladdin con- figuration application, available for free download from the Datalogic Scanning website. QUICKSCAN™ QD2590...
Page 113: Multiple Label Reading
MULTIPLE LABEL READING ENTER/EXIT PROGRAMMING MODE MULTIPLE LABEL READING In standard (default) mode, when the reader’s aiming system is activated (by a trigger pull, motion or other method depending on the mode), it then acquires and processes each image in the area in front of it (the Volume). In this case, the reader stops process- ing the image once it decodes a label.
Page 114: Multiple Labels Ordering By Code Length
ENTER/EXIT PROGRAMMING MODE READING PARAMETERS Multiple Labels Ordering by Code Length Specifies the transmission ordering by code length, when Multiple Labels per Frame is enabled. $CSNMT00  Multiple Labels Ordering = Disable $CSNMT01 Multiple Labels Ordering = Transmit Increasing Length Order $CSNMT02 Multiple Labels Ordering = Transmit Decreasing Length Order...
Page 115: 1D Symbologies
CONFIGURATION | 1D SYMBOLOGIES SECTION CONTENTS ISABLE YMBOLOGIES starting on page 104 5 (I 2 OUPON ONTROL NTERLEAVED • starting on page 104 • starting on page 138 UPC-A 5, F NTERLEAVED EBRABAN • starting on page 105 • ODELS starting on page UPC-E 5 CIP HR...
Page 116: Disable All Symbologies
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES DISABLE ALL SYMBOLOGIES Scan this label to disable all symbologies. Disable All Symbologies COUPON CONTROL Coupon Control This feature is used to control the method of processing coupon labels. Options are: • Allow all — allow all coupon bar codes to be decoded •...
Page 117: Upc-A
UPC-A ENTER/EXIT PROGRAMMING MODE UPC-A The following options apply to the UPC-A symbology. UPC-A Enable/Disable When disabled, the reader will not read UPC-A bar codes. $CABEN00 UPC-A = Disable $CABEN01  UPC-A = Enable UPC-A Check Character Transmission Enable this option to transmit the check character along with UPC-A bar code data. $CABCT00 UPC-A Check Character Transmission = Don’t Send $CABCT01...
Page 118: Expand Upc-A To Ean-13
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES Expand UPC-A to EAN-13 Expands UPC-A data to the EAN-13 data format. Selecting this feature also changes the symbology ID to match those required for EAN-13. $CAB3B00  UPC-A to EAN-13 = Don’t Expand $CAB3B01 UPC-A to EAN-13 = Expand UPC-A Number System Character Transmission This feature enables/disables transmission of the UPC-A number system character.
Page 119: Upc-E
UPC-E ENTER/EXIT PROGRAMMING MODE UPC-E The following options apply to the UPC-E symbology. UPC-E Enable/Disable When disabled, the reader will not read UPC-E bar codes. $CEBEN00 UPC-E = Disable $CEBEN01  UPC-E = Enable UPC-E Check Character Transmission Enable this option to transmit the check character along with UPC-E bar code data. $CEBCT00 UPC-E Check Character Transmission = Don’t Send $CEBCT01...
Page 120: Expand Upc-E To Ean-13
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES Expand UPC-E to EAN-13 Expands UPC-E data to the EAN-13 data format. Selecting this feature also changes the symbology ID to match those required for EAN-13. $CEB3B00  UPC-E to EAN-13 = Don’t Expand $CEB3B01 UPC-E to EAN-13 = Expand Expand UPC-E to UPC-A Expands UPC-E data to the UPC-A data format.
Page 121: Gtin Formatting
UPC-E ENTER/EXIT PROGRAMMING MODE GTIN Formatting This feature enables/disables the ability to convert UPC-E, UPC-A, EAN-8, and EAN-13 labels into the GTIN 14-character format. $CGBEN00  GTIN Formatting = Disable $CGBEN01 GTIN Formatting = Enable PRODUCT REFERENCE GUIDE...
Page 122: 110
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES EAN-13 The following options apply to the EAN-13 symbology. EAN-13 Enable/Disable When disabled, the reader will not read EAN-13 bar codes. $C3BEN00 EAN-13 = Disable $C3BEN01  = Enable EAN-13 EAN-13 Check Character Transmission Enable this option to transmit the check character along with EAN-13 bar code data. $C3BCT00 EAN-13 Check Character Transmission = Don’t Send $C3BCT01...
Page 123: Ean-13 Flag 1 Character
EAN-13 ENTER/EXIT PROGRAMMING MODE EAN-13 Flag 1 Character Enables/disables transmission of an EAN/JAN-13 Flag1 character. The Flag 1 character is the first character of the label $C3BF100 EAN-13 Flag 1 Char = Don’t transmit $C3BF101  EAN-13 Flag 1 Char = Transmit EAN-13 to ISBN Conversion This option enables/disables conversion of EAN-13/JAN-13 Bookland labels starting with 978 to ISBN labels.
Page 124: Ean-13 To Issn Conversion
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES EAN-13 to ISSN Conversion Enables/disables conversion of EAN/JAN-13 Bookland labels starting with 977 to ISSN labels. $C3BIN00  ISSN = Disable $C3BIN01 ISSN = Enable QUICKSCAN™ QD2590...
Page 125: 113
EAN-8 ENTER/EXIT PROGRAMMING MODE EAN-8 The following options apply to the EAN-8 symbology. EAN-8 Enable/Disable When disabled, the reader will not read EAN-8 bar codes. $C8BEN00 EAN-8 = Disable $C8BEN01  = Enable EAN-8 EAN-8 Check Character Transmission Enable this option to transmit the check character along with EAN-8 bar code data. $C8BCT00 EAN-8 Check Character Transmission = Don’t Send $C8BCT01...
Page 126: Expand Ean-8 To Ean-13
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES Expand EAN-8 to EAN-13 Enable this option to expand EAN-8/JAN-8 labels to EAN-13/JAN-13. $C8B3B00  EAN-8 to EAN-13 = Don’t Expand $C8B3B01 EAN-8 to EAN-13 = Expand QUICKSCAN™ QD2590...
Page 127: Upc/Ean Global Settings
UPC/EAN GLOBAL SETTINGS ENTER/EXIT PROGRAMMING MODE UPC/EAN GLOBAL SETTINGS This section provides configuration settings for UPC-A, UPC-E, EAN 13 and EAN 8 sym- bologies, and affects all of these unless otherwise marked for each feature description. UPC/EAN Price Weight Check This feature enables/disables calculation and verification of price/weight check digits.
Page 128: Upc/Ean Quiet Zones
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES UPC/EAN Quiet Zones This feature specifies the number of quiet zones for UPC/EAN labels. Quiet zones are blank areas at the ends of a bar code, typically 10 times the width of the narrowest bar or space in the label.
Page 129: Optional Add-Ons
UPC/EAN GLOBAL SETTINGS ENTER/EXIT PROGRAMMING MODE Optional Add-ons The reader can be enabled to optionally read the following add-ons (supplementals): • • NOTE: If a UPC/EAN base label and a an add-on are both decoded, the reader will transmit the base label and add-on. If a UPC/EAN base label is decoded without an add-on, the base label will be transmitted without an add-on.
Page 130: Optional Add-On Timer
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES Optional Add-On Timer This option sets the time the reader will look for an add-on when an add-on fragment has been seen and optional add-ons are enabled. $CADOT01 Optional Add-on Timer = 10ms $CADOT02 Optional Add-on Timer = 20ms $CADOT03 Optional Add-on Timer = 30ms $CADOT05...
Page 131: Gs1 Databar™ Omnidirectional
GS1 DATABAR™ OMNIDIRECTIONAL ENTER/EXIT PROGRAMMING MODE GS1 DATABAR™ OMNIDIRECTIONAL The following options apply to the GS1 DataBar Omnidirectional (formerly RSS-14) sym- bology. GS1 DataBar Omnidirectional Enable/Disable When disabled, the reader will not read GS1 DataBar Omnidirectional bar codes. $C4BEN00  GS1 DataBar Omnidirectional = Disable $C4BEN01 GS1 DataBar Omnidirectional = Enable...
Page 132: Gs1 Databar™ Expanded
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES GS1 DATABAR™ EXPANDED The following options apply to the GS1 DataBar Expanded (formerly RSS Expanded) sym- bology. GS1 DataBar Expanded Enable/Disable When disabled, the reader will not read GS1 DataBar Expanded bar codes. $CXBEN00  GS1 DataBar Expanded = Disable $CXBEN01 GS1 DataBar Expanded = Enable...
Page 133: Gs1 Databar Expanded Length Control
GS1 DATABAR™ EXPANDED ENTER/EXIT PROGRAMMING MODE GS1 DataBar Expanded Length Control This feature specifies either variable length decoding or fixed length decoding for the GS1 DataBar Expanded symbology. For variable-length decoding, a minimum length may be set. Variable Length: For fixed-length decoding, two different lengths may be set. Fixed Length: $CXBLC00 ...
Page 134: Gs1 Databar Expanded Set Length 2
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES GS1 DataBar Expanded Set Length 2 This feature specifies one of the bar code lengths for " GS1 DataBar Expanded Length . Length 2 is the maximum label length if in Variable Length Mode, Control" on page 121 or the second fixed length if in Fixed Length Mode.
Page 135: Gs1 Databar™ Limited
GS1 DATABAR™ LIMITED ENTER/EXIT PROGRAMMING MODE GS1 DATABAR™ LIMITED The following options apply to the GS1 DataBar Limited (formerly RSS Limited) symbol- ogy. GS1 DataBar Limited Enable/Disable When disabled, the reader will not read GS1 DataBar Limited bar codes. $CLBEN00 ...
Page 136: Code 39
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES CODE 39 The following options apply to the Code 39 symbology. Code 39 Enable/Disable When disabled, the reader will not read Code 39 bar codes. $CC3EN00 Code 39 = Disable $CC3EN01  Code 39 = Enable Code 39 Check Character Calculation Enable this option to enable/disable calculation and verification of an optional Code 39 check character.
Page 137: Code 39 Check Character Transmission
CODE 39 ENTER/EXIT PROGRAMMING MODE $CC3CC08 Code 39 Check Character Calculation = Enable Daimler Chrysler Check Code 39 Check Character Transmission Enable this option to transmit the check character along with Code 39 bar code data. $CC3CT00 Code 39 Check Character Transmission = Don’t Send $CC3CT01 ...
Page 138: Code 39 Full Ascii
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES Code 39 Full ASCII In Code 39 decoding, this enables/disables the translation of Code 39 characters to Code 39 full-ASCII characters. $CC3FA00  Code 39 Full ASCII = Disable $CC3FA01 Code 39 Full ASCII = Enable Code 39 Quiet Zones This feature specifies the number of quiet zones for Code 39 labels.
Page 139: Code 39 Length Control
CODE 39 ENTER/EXIT PROGRAMMING MODE Code 39 Length Control This feature specifies either variable length decoding or fixed length decoding for the Code 39 symbology. For variable-length decoding, a minimum length may be set. Variable Length: For fixed-length decoding, two different lengths may be set. Fixed Length: $CC3LC00 ...
Page 140: Code 39 Set Length 2
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES Code 39 Set Length 2 This feature specifies one of the bar code lengths for " Code 39 Length Control" on page . Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
Page 141: Trioptic Code
TRIOPTIC CODE ENTER/EXIT PROGRAMMING MODE TRIOPTIC CODE The following options apply to the trioptic symbology. Trioptic Code Enable/Disable When disabled, the reader will not read Trioptic Code bar codes. $CCTEN00  Trioptic Code = Disable $CCTEN01 Trioptic Code = Enable CODE 39 DANISH PPT The following options apply to the Code 39 Danish PPT symbology.
Page 142: Code 39 Pzn
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES CODE 39 PZN The following options apply to the Code 39 PZN symbology. Code 39 PZN Enable/Disable When disabled, the reader will not read Code 39 PZN bar codes. $CPZEN00  Code 39 PZN = Disable $CPZEN01 Code 39 PZN = Enable CODE 39 LA POSTE...
Page 143: Code 32 (Italian Pharmaceutical)
CODE 32 (ITALIAN PHARMACEUTICAL) ENTER/EXIT PROGRAMMING MODE CODE 32 (ITALIAN PHARMACEUTICAL) The following options apply to the Code 32 symbology. Code 32 Enable/Disable When disabled, the reader will not read Code 32 bar codes. $CP3EN00  Code 32 = Disable $CP3EN01 Code 32 = Enable Code 32 Feature Setting Exceptions...
Page 144: Code 32 Start/Stop Character Transmission
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES Code 32 Start/Stop Character Transmission Enable this option to enable/disable transmission of Code 32 start and stop characters. $CP3SS00  Code 32 Start/Stop Character Transmission = Don’t Transmit $CP3SS01 Code 32 Start/Stop Character Transmission = Transmit CODE 39 CIP HR (FRENCH PHARMACEUTICAL) The following options apply to the Code 39 CIP HR symbology.
Page 145: Code 128
CODE 128 ENTER/EXIT PROGRAMMING MODE CODE 128 The following options apply to the Code 128 symbology. Code 128 Enable/Disable Enables/Disables ability of the reader to decode Code 128 labels. $CC8EN00 Code 128 = Disable $CC8EN01  Code 128 = Enable Expand Code 128 to Code 39 This feature enables/disables expansion of Code 128 labels to Code 39 labels.
Page 146: Code 128 Check Character Transmission
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES Code 128 Check Character Transmission Enable this option to transmit the check character along with Code 128 bar code data. $CC8CT00  Code 128 Check Character Transmission = Don’t Send $CC8CT01 Code 128 Check Character Transmission = Send Code 128 Function Character Transmission Enables/disables transmission of Code128 function characters 1, 2, 3, and 4.
Page 147: Code 128 Quiet Zones
CODE 128 ENTER/EXIT PROGRAMMING MODE Code 128 Quiet Zones This feature specifies the number of quiet zones for Code 128 labels. Quiet zones are blank areas at the ends of a bar code and are typically 10 times the width of the narrow- est bar or space in the label.
Page 148: Code 128 Set Length 1
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES Code 128 Set Length 1 This feature specifies one of the bar code lengths for " Code 128 Length Control" on page . Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
Page 149: Gs1-128
GS1-128 ENTER/EXIT PROGRAMMING MODE GS1-128 The following options apply to the GS1-128 symbology. (Also known as USS-128, GTIN- 128, UCC-128.) GS1-128 Enable This option enables/disables the ability of the reader to translate GS1-128 labels to the GS1-128 data format. Options are: •...
Page 150: Interleaved 2 Of 5 (I 2 Of 5)
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES INTERLEAVED 2 OF 5 (I 2 OF 5) The following options apply to the I 2 of 5 symbology. CAUTION: When reading this symbology, the settings for I 2 of 5 Length Control AND I 2 of 5 Check Character Calculation MUST be enabled to increase decoding safety.
Page 151: I 2 Of 5 Check Character Calculation
INTERLEAVED 2 OF 5 (I 2 OF 5) ENTER/EXIT PROGRAMMING MODE I 2 of 5 Check Character Calculation This option enables/disables calculation and verification of an optional I 2 of 5 check character. $CI2CC00  I 2 of 5 Check Character Calculation = Disable $CI2CC01 I 2 of 5 Check Character Calculation = Calculate Std Check (Modulo 10 no AR)
Page 152: I 2 Of 5 Check Character Transmission
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES I 2 of 5 Check Character Calculation (continued) $CI2CC10 I 2 of 5 Check Character Calculation = Calculate Bosch Check $CI2CC20 I 2 of 5 Check Character Calculation = Calculate Italian Post Check I 2 of 5 Check Character Transmission Enable this option to transmit the check character along with I 2 of 5 bar code data.
Page 153: I 2 Of 5 Length Control
INTERLEAVED 2 OF 5 (I 2 OF 5) ENTER/EXIT PROGRAMMING MODE I 2 of 5 Length Control This feature specifies either variable length decoding or fixed length decoding for the I 2 of 5 symbology. For variable-length decoding, a minimum length may be set. Variable Length: For fixed-length decoding, two different lengths may be set.
Page 154: I 2 Of 5 Set Length 2
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES I 2 of 5 Set Length 2 This feature specifies one of the bar code lengths for " I 2 of 5 Length Control" on page . Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
Page 155: Interleaved 2 Of 5, Febraban
INTERLEAVED 2 OF 5, FEBRABAN (DESK MODELS ONLY) ENTER/EXIT PROGRAMMING MODE INTERLEAVED 2 OF 5, FEBRABAN (DESK MODELS ONLY) Interleaved 2 of 5, Febraban format Enable / Disable NOTE: Interleaved 2 of 5 shall be enabled before enabling Febraban variant. Enables/Disables ability of reader to decode Interleaved 2 of 5, Febraban format.
Page 156: Interleaved 2 Of 5 Cip Hr
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES INTERLEAVED 2 OF 5 CIP HR The following options apply to the Interleaved 2 of 5 CIP HR symbology. Interleaved 2 of 5 CIP HR Enable/Disable Enables/Disables ability of the reader to decode Interleaved 2 of 5 CIP HR labels. $CCHEN00 ...
Page 157: Matrix 2 Of 5
MATRIX 2 OF 5 ENTER/EXIT PROGRAMMING MODE MATRIX 2 OF 5 The following options apply to the Matrix 2 of 5 symbology. Matrix 2 of 5 Enable/Disable When disabled, the reader will not read Matrix 2 of 5 bar codes. $CM2EN00 ...
Page 158: Matrix 2 Of 5 Check Character Transmission
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES Matrix 2 of 5 Check Character Transmission This feature enables/disables transmission of an optional Matrix 2 of 5 check character. $CM2CT00 Matrix 2 of 5 Check Character Transmission = Don’t Send $CM2CT01  Matrix 2 of 5 Check Character Transmission = Send Matrix 2 of 5 Length Control This feature specifies either variable length decoding or fixed length decoding for the...
Page 159: Matrix 2 Of 5 Set Length 1
MATRIX 2 OF 5 ENTER/EXIT PROGRAMMING MODE Matrix 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for " Standard 2 of 5 Length Control" on . Length 1 is the minimum label length if in Variable Length Mode, or the first page 149 fixed length if in Fixed Length Mode.
Page 160: Standard 2 Of 5
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES STANDARD 2 OF 5 The following options apply to the Standard 2 of 5 symbology. Standard 2 of 5 Enable/Disable When disabled, the reader will not read Standard 2 of 5 bar codes. $CS2EN00  Standard 2 of 5 = Disable $CS2EN01 Standard 2 of 5 = Enable...
Page 161: Standard 2 Of 5 Check Character Transmission
STANDARD 2 OF 5 ENTER/EXIT PROGRAMMING MODE Standard 2 of 5 Check Character Transmission This feature enables/disables transmission of an optional Standard 2 of 5 check charac- ter. $CS2CT00 Standard 2 of 5 Check Character Transmission = Don’t Send $CS2CT01 ...
Page 162: Standard 2 Of 5 Set Length 1
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES Standard 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for " Standard 2 of 5 Length Control" on . Length 1 is the minimum label length if in Variable Length Mode, or the first page 149 fixed length if in Fixed Length Mode.
Page 163: Compressed 2 Of 5
COMPRESSED 2 OF 5 ENTER/EXIT PROGRAMMING MODE COMPRESSED 2 OF 5 The following options apply to the Compressed 2 of 5 symbology. Compressed 2 of 5 Enable/Disable When disabled, the reader will not read Compressed 2 of 5 bar codes. $CC2EN00 ...
Page 164: Compressed 2 Of 5 Check Character Transmission
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES Compressed 2 of 5 Check Character Transmission This feature enables/disables transmission of an optional Compressed 2 of 5 check char- acter. $CC2CT00 Compressed 2 of 5 Check Character Transmission = Don’t Send $CC2CT01  Compressed 2 of 5 Check Character Transmission = Send Compressed 2 of 5 Length Control This feature specifies either variable length decoding or fixed length decoding for the...
Page 165: Compressed 2 Of 5 Set Length 1
COMPRESSED 2 OF 5 ENTER/EXIT PROGRAMMING MODE Compressed 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for " Compressed 2 of 5 Length Control" . Length 1 is the minimum label length if in Variable Length Mode, or the on page 152 first fixed length if in Fixed Length Mode.
Page 166: Datalogic 2 Of 5
DATALOGIC 2 OF 5 The following options apply to the Datalogic 2 of 5 symbology. Datalogic 2 of 5 Enable/Disable When disabled, the reader will not read Datalogic 2 of 5 bar codes. $CD2EN00  Datalogic 2 of 5 = Disable...
Page 167: Datalogic 2 Of 5 Check Character Transmission
DATALOGIC 2 OF 5 ENTER/EXIT PROGRAMMING MODE Datalogic 2 of 5 Check Character Transmission Enable this option to transmit the check character along with Datalogic 2 of 5 bar code data. $CD2CT00 Datalogic 2 of 5 Check Character Transmission = Don’t Send $CD2CT01 ...
Page 168: Datalogic 2 Of 5 Set Length 1
Alphanu- meric characters in Appendix D, Keypad represent- Select Datalogic 2 of 5 Set Length 2 Setting ing your desired character(s). End by scanning the $CD2L2 ENTER/EXIT bar code again. Make a mistake? Scan the CANCEL bar code to abort and not save the entry string.
Page 169: Industrial 2 Of 5
INDUSTRIAL 2 OF 5 ENTER/EXIT PROGRAMMING MODE INDUSTRIAL 2 OF 5 The following options apply to the Industrial 2 of 5 symbology. Industrial 2 of 5 Enable/Disable When disabled, the reader will not read Industrial 2 of 5 bar codes. $CU2EN00 ...
Page 170: Industrial 2 Of 5 Check Character Transmission
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES Industrial 2 of 5 Check Character Transmission Enables/disables transmission of an Industrial 2 of 5 check character. $CU2CT00 Industrial 2 of 5 Check Character Transmission = Don’t Send $CU2CT01  Industrial 2 of 5 Check Character Transmission = Send Industrial 2 of 5 Length Control This feature specifies either variable length decoding or fixed length decoding for the...
Page 171: Industrial 2 Of 5 Set Length 1
INDUSTRIAL 2 OF 5 ENTER/EXIT PROGRAMMING MODE Industrial 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for " Industrial 2 of 5 Length Control" on . Length 1 is the minimum label length if in Variable Length Mode, or the first page 158 fixed length if in Fixed Length Mode.
Page 172: Iata
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES IATA The following options apply to the IATA symbology. IATA Enable/Disable Enables/Disables the ability of the reader to decode IATA labels. $CIAEN00  IATA = Disable $CIAEN01 IATA = Enable IATA Check Character Transmission Enables/Disables calculation and verification of an optional IATA check character. $CIACT00 IATA Check Character Transmission = Don’t Send...
Page 173: Follett 2 Of 5
FOLLETT 2 OF 5 ENTER/EXIT PROGRAMMING MODE FOLLETT 2 OF 5 The following options apply to the Follett 2 of 5 symbology. Follett 2 of 5 Enable/Disable Enables/Disables ability of reader to decode Follett 2 of 5 labels. $CF2EN00  Follett 2 of 5 = Disable $CF2EN01 Follett 2 of 5 = Enable...
Page 174: Codabar
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES CODABAR The following options apply to the Codabar symbology. Codabar Enable/Disable When disabled, the reader will not read Codabar bar codes. $CCBEN00  Codabar = Disable $CCBEN01 Codabar = Enable Codabar Check Character Calculation This option enables/disables calculation and verification of an optional Codabar check character.
Page 175: Codabar Check Character Transmission
CODABAR ENTER/EXIT PROGRAMMING MODE Codabar Check Character Transmission Enable this option to transmit the check character along with Codabar bar code data. NOTE: This feature is valid only when Codabar Check Character Calculation is enabled. $CCBCT00 Codabar Check Character Transmission = Don’t Send $CCBCT01 ...
Page 176: Codabar Start/Stop Character Set
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES Codabar Start/Stop Character Set This option specifies the format of transmitted Codabar start/stop characters. $CCBSC00 Codabar Check Character Set = ABCD/TN*E $CCBSC01 Codabar Check Character Set = ABCD/ABCD $CCBSC02 Codabar Check Character Set = abcd/tn*e $CCBSC03 ...
Page 177: Codabar Quiet Zones
CODABAR ENTER/EXIT PROGRAMMING MODE Codabar Quiet Zones This feature specifies the number of quiet zones for Codabar labels. Quiet zones are blank areas at the ends of a bar code and are typically 10 times the width of the narrow- est bar or space in the label.
Page 178: Codabar Length Control
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES Codabar Length Control This feature specifies either variable length decoding or fixed length decoding for the Codabar symbology. For variable-length decoding, a minimum length may be set. Variable Length: For fixed-length decoding, two different lengths may be set. Fixed Length: $CCBLC00 ...
Page 179: Codabar Set Length 2
CODABAR ENTER/EXIT PROGRAMMING MODE Codabar Set Length 2 This feature specifies one of the bar code lengths for " Codabar Length Control" on page . Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
Page 180: Abc Codabar
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES ABC CODABAR The following options apply to the ABC Codabar symbology. ABC Codabar Enable/Disable Enables/Disables ability of reader to decode ABC Codabar labels. $CCBAB00  ABC Codabar = Disable $CCBAB01 ABC Codabar = Enable ABC Codabar Concatenation Mode Specifies the concatenation mode between Static and Dynamic.
Page 181: Abc Codabar Dynamic Concatenation Timeout
ABC CODABAR ENTER/EXIT PROGRAMMING MODE ABC Codabar Dynamic Concatenation Timeout This parameter specifies the timeout in 10-millisecond ticks used by the ABC Codabar Dynamic Concatenation Mode. The timeout can be set within a range of 05 to 255 in 10ms increments. A setting of zero specifies no delay. To configure this feature, scan the ENTER/EXIT PRO- GRAMMING MODE bar code above, then the bar code at left followed by the digits from the Alphanu-...
Page 182: Isbt 128
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES ISBT 128 The following options apply to the ISBT 128 symbology. ISBT 128 Concatenation Enables/disables ISBT 128 concatenation of 2 labels. $CI8CE00  ISBT 128 Concatenation = Disable $CI8CE01 ISBT 128 Concatenation = Enable ISBT 128 Concatenation Mode Specifies the concatenation mode between Static and Dynamic.
Page 183: Isbt 128 Dynamic Concatenation Timeout
ISBT 128 ENTER/EXIT PROGRAMMING MODE ISBT 128 Dynamic Concatenation Timeout Specifies the timeout used by the ISBT 128 Dynamic Concatenation Mode. $CI8DT05 ISBT 128 Dynamic Concatenation Timeout = 50 msec $CI8DT0A ISBT 128 Dynamic Concatenation Timeout = 100 msec $CI8DT14 ...
Page 184: Isbt 128 Force Concatenation
ISBT 128 Force Contatenation = Disable $CI8FC01 ISBT 128 Force Concatenation = Enable ISBT 128 Advanced Concatenation Options NOTE: Use the Datalogic Aladdin configuration application or Contact Cus- tomer Support to set up pairs of label types for concatenation. QUICKSCAN™ QD2590...
Page 185: Code 11
CODE 11 ENTER/EXIT PROGRAMMING MODE CODE 11 The following options apply to the Code 11 symbology. Code 11 Enable/Disable When disabled, the reader will not read Code 11 bar codes. $CC1EN00  Code 11 = Disable $CC1EN01 Code 11 = Enable Code 11 Check Character Calculation This option enables/disables calculation and verification of optional Code 11 check character.
Page 186: Code 11 Check Character Transmission
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES Code 11 Check Character Transmission This feature enables/disables transmission of an optional Code 11 check character. $CC1CT00 Code 11 Check Character Transmission = Don’t Send $CC1CT01  Code 11 Check Character Transmission = Send Code 11 Length Control This feature specifies either variable length decoding or fixed length decoding for the Code 11 symbology.
Page 187: Code 11 Set Length 1
CODE 11 ENTER/EXIT PROGRAMMING MODE Code 11 Set Length 1 This feature specifies one of the bar code lengths for " Code 11 Length Control" on page . Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
Page 188: Code 93
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES CODE 93 The following options apply to the Code 93 symbology. Code 93 Enable/Disable Enables/Disables ability of reader to decode Code 93 labels. $CC9EN00  Code 93 = Disable $CC9EN01 Code 93 = Enable Code 93 Check Character Calculation This option enables/disables calculation and verification of optional Code 93 check character.
Page 189: Code 93 Check Character Transmission
CODE 93 ENTER/EXIT PROGRAMMING MODE Code 93 Check Character Transmission This feature enables/disables transmission of an optional Code 93 check character. $CC9CT00  Code 93 Check Character Transmission = Don’t Send $CC9CT01 Code 93 Check Character Transmission = Send Code 93 Length Control This feature specifies either variable length decoding or fixed length decoding for the Code 93 symbology.
Page 190: Code 93 Set Length 1
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES Code 93 Set Length 1 This feature specifies one of the bar code lengths for " Code 93 Length Control" on page . Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
Page 191: Code 93 Quiet Zones
CODE 93 ENTER/EXIT PROGRAMMING MODE Code 93 Quiet Zones This feature specifies the number of quiet zones for Code 93 labels. Quiet zones are blank areas at the ends of a bar code and are typically 10 times the width of the narrow- est bar or space in the label.
Page 192: Msi
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES The following options apply to the MSI symbology. MSI Enable/Disable Enables/Disables ability of reader to decode MSI labels. $CMSEN00  MSI = Disable $CMSEN01 MSI = Enable MSI Check Character Calculation Enables/Disables calculation and verification of an optional MSI check character. $CMSCC00 MSI Check Character Calculation = Disable $CMSCC01...
Page 193: Msi Check Character Transmission
ENTER/EXIT PROGRAMMING MODE MSI Check Character Transmission Enables/disables transmission of an MSI check character. $CMSCT00 MSI Check Character Transmission = Don’t Send $CMSCT01  MSI Check Character Transmission = Send MSI Length Control This feature specifies either variable length decoding or fixed length decoding for the MSI symbology.
Page 194: Msi Set Length 1
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES MSI Set Length 1 This feature specifies one of the bar code lengths for " MSI Length Control" on page 181 Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
Page 195: Plessey
PLESSEY ENTER/EXIT PROGRAMMING MODE PLESSEY The following options apply to the Plessey symbology. Plessey Enable/Disable Enables/Disables ability of reader to decode Plessey labels. $CPLEN00  Plessey = Disable $CPLEN01 Plessey = Enable Plessey Check Character Calculation Enables/Disables calculation and verification of a Plessey check character. $CPLCC00 Plessey Check Character Calculation = Disable $CPLCC01...
Page 196: Plessey Check Character Transmission
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES Plessey Check Character Transmission Enables/disables transmission of a Plessey check character. $CPLCT00 Plessey Check Character Transmission = Don’t Send $CPLCT01  Plessey Check Character Transmission = Send Plessey Length Control This feature specifies either variable length decoding or fixed length decoding for the Plessey symbology.
Page 197: Plessey Set Length 1
PLESSEY ENTER/EXIT PROGRAMMING MODE Plessey Set Length 1 This feature specifies one of the bar code lengths for " Plessey Length Control" on page . Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
Page 198: Bc412
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES BC412 The following options apply to the BC412 symbology. BC412 Enable/Disable Enables/Disables ability of reader to decode BC412 labels. $CBCEN00  BC412 = Disable $CBCEN01 BC412 = Enable BC412 Check Character Calculation Enable this option to enable/disable calculation and verification of an optional BC412 check character.
Page 199: Bc412 Length Control
BC412 ENTER/EXIT PROGRAMMING MODE BC412 Length Control This feature specifies either variable length decoding or fixed length decoding for the BC412 symbology. For variable-length decoding, a minimum length may be set. Variable Length: For fixed-length decoding, two different lengths may be set. Fixed Length: $CBCLC00 ...
Page 200: Bc412 Set Length 1
ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES BC412 Set Length 1 This feature specifies one of the bar code lengths for " BC412 Length Control" on page . Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
Page 201: Symbologies
CONFIGURATION | SYMBOLOGIES SECTION CONTENTS • GLOBAL FEATURES starting on page 190 PDF417 ZTEC • starting on page 193 • starting on page 205 PDF417 HINA ENSIBLE ICRO • starting on page • starting on page 207 QR C ATRIX •...
Page 202: Global Features
2D GLOBAL FEATURES The following features are common to all, or in some cases, most of the available 2D symbologies. Default settings are indicated at each feature/option with a green arrow. Also reference Appendix B, Standard Defaults for a listing of the most widely used set of standard factory settings.
Page 203: 2D Maximum Decoding Time
2D GLOBAL FEATURES ENTER/EXIT PROGRAMMING MODE 2D Maximum Decoding Time This feature specifies the maximum amount of time the software will spend attempting to decode a 2D label. The selectable range is 10 milliseconds to 2.55 milliseconds. $CDETM0A 2D Maximum Decoding Time = 100 msec $CDETM14 2D Maximum Decoding Time = 200 msec $CDETM23...
Page 204: 2D Structured Append
ENTER/EXIT PROGRAMMING MODE 2D SYMBOLOGIES 2D Structured Append Enables/disables ability of reader to append multiple 2D Codes labels in a structured format. The structured append property is globally applied to the following symbolo- gies, if these are enabled: • Data Matrix •...
Page 205: Aztec Code
AZTEC CODE ENTER/EXIT PROGRAMMING MODE AZTEC CODE Aztec Code Enable / Disable Enables/disables the ability of the reader to decode Aztec Code labels. $CAZEN00 Aztec Code = Disable $CAZEN01  Aztec Code = Enable Aztec Code Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology.
Page 206: Aztec Code Set Length 1
ENTER/EXIT PROGRAMMING MODE 2D SYMBOLOGIES Aztec Code Set Length 1 Specifies one of the bar code lengths for " Aztec Code Length Control" on page 193 Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
Page 207: China Sensible Code
CHINA SENSIBLE CODE ENTER/EXIT PROGRAMMING MODE CHINA SENSIBLE CODE China Sensible Code Enable / Disable Enables/disables the ability of the reader to decode China Sensible Code labels. $CCSEN00  China Sensible Code = Disable $CCSEN01 China Sensible Code = Enable China Sensible Code Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology.
Page 208: China Sensible Code Set Length 1
ENTER/EXIT PROGRAMMING MODE 2D SYMBOLOGIES China Sensible Code Set Length 1 Specifies one of the bar code lengths for " China Sensible Code Length Control" on page . Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
Page 209: Data Matrix
DATA MATRIX ENTER/EXIT PROGRAMMING MODE DATA MATRIX Data Matrix Enable / Disable Enables/disables ability of reader to decode Data Matrix labels. $CDMEN00 Data Matrix = Disable $CDMEN01  Data Matrix = Enable Data Matrix Square/Rectangular Style Specifies the options available when reading Data Matrix with different form factors. Choices are: •...
Page 210: Data Matrix Length Control
ENTER/EXIT PROGRAMMING MODE 2D SYMBOLOGIES Data Matrix Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set. $CDMLC00 ...
Page 211: Data Matrix Set Length 2
DATA MATRIX ENTER/EXIT PROGRAMMING MODE Data Matrix Set Length 2 This feature specifies one of the bar code lengths for " Data Matrix Length Control" on . Length 2 is the maximum label length if in Variable Length Mode, or the sec- page 198 ond fixed length if in Fixed Length Mode.
Page 212: Gs1 Dotcode
ENTER/EXIT PROGRAMMING MODE 2D SYMBOLOGIES GS1 DOTCODE The following options apply for the DotCode barcode decoding DotCode Enable This options enables/disables the ability of the reader to decode DotCode barcodes. $CDCEN01 DotCode = Enable $CDCEN00  DotCode = Disable DotCode High Resolution Enable This options improves the decoding performance for very small module size barcodes, e.g.
Page 213: Dotcode Position-Based Decoding
DotCode Position-based Decoding = Enable $CDCCP00  DotCode Position-based Decoding = Disable Additional Options To improve performances the following additional settings are available using Aladdin configuration utility, downloadable from www.datalogic.com. • Dot Size • Fixed Length or Variable Length •...
Page 214: Maxicode
ENTER/EXIT PROGRAMMING MODE 2D SYMBOLOGIES MAXICODE Maxicode Enable / Disable Enables/disables ability of reader to decode Maxicode labels. $CMXEN00  Maxicode = Disable $CMXEN01 Maxicode = Enable Maxicode Primary Message Transmission Enables/disables the transmission of only the Primary Message when the Secondary Message is not readable.
Page 215: Maxicode Length Control
MAXICODE ENTER/EXIT PROGRAMMING MODE Maxicode Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set. $CMXLC00 ...
Page 216: Maxicode Set Length 2
ENTER/EXIT PROGRAMMING MODE 2D SYMBOLOGIES Maxicode Set Length 2 This feature specifies one of the bar code lengths for " Maxicode Length Control" on page . Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
Page 217: Pdf417
PDF417 ENTER/EXIT PROGRAMMING MODE PDF417 PDF417 Enable / Disable Enables/disables the ability of the reader to decode PDF417 labels. $CP4EN00 PDF417 = Disable $CP4EN01  PDF417 = Enable PDF417 Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology.
Page 218: Pdf417 Set Length 1
ENTER/EXIT PROGRAMMING MODE 2D SYMBOLOGIES PDF417 Set Length 1 Specifies one of the bar code lengths for " . Length 1 PDF417 Length Control" on page 205 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
Page 219: Micro Pdf417
MICRO PDF417 ENTER/EXIT PROGRAMMING MODE MICRO PDF417 Micro PDF417 Enable / Disable Enables/disables the ability of the reader to decode Micro PDF417 labels. $CMIEN00 Micro PDF417 = Disable $CMIEN01  Micro PDF417 = Enable Micro PDF417 Code 128 GS1-128 Emulation Specifies which AIM ID to use for Micro PDF labels when doing Code 128 or GS1-128 emulation.
Page 220: Micro Pdf417 Length Control
ENTER/EXIT PROGRAMMING MODE 2D SYMBOLOGIES Micro PDF417 Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set. $CMILC00 ...
Page 221: Micro Pdf417 Set Length 2
MICRO PDF417 ENTER/EXIT PROGRAMMING MODE Micro PDF417 Set Length 2 This feature specifies one of the bar code lengths for " Micro PDF417 Length Control" on . Length 2 is the maximum label length if in Variable Length Mode, or the sec- page 208 ond fixed length if in Fixed Length includes the bar code’s data characters only.
Page 222: Qr Code
ENTER/EXIT PROGRAMMING MODE 2D SYMBOLOGIES QR CODE QR Code Enable / Disable Enables/disables the ability of the reader to decode QR Code labels. $CQREN00 QR Code = Disable $CQREN01  QR Code = Enable QR Code Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology.
Page 223: Qr Code Set Length 1
QR CODE ENTER/EXIT PROGRAMMING MODE QR Code Set Length 1 This feature specifies one of the bar code lengths for " QR Code Length Control" on page . Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
Page 224: Micro Qr Code
ENTER/EXIT PROGRAMMING MODE 2D SYMBOLOGIES MICRO QR CODE Micro QR Code Enable / Disable Enables/disables the ability of the reader to decode Micro QR Code labels. $CMQEN00 Micro QR Code = Disable $CMQEN01  Micro QR Code = Enable Micro QR Code Length Control This feature specifies either variable length decoding or fixed length decoding for this symbology.
Page 225: Micro Qr Code Set Length 1
MICRO QR CODE ENTER/EXIT PROGRAMMING MODE Micro QR Code Set Length 1 This feature specifies one of the bar code lengths for " Micro QR Code Length Control" on . Length 1 is the minimum label length if in Variable Length Mode, or the first page 212 fixed length if in Fixed Length Mode.
Page 226: Ucc Composite
ENTER/EXIT PROGRAMMING MODE 2D SYMBOLOGIES UCC COMPOSITE UCC Optional Composite Timer Specifies the amount of time the system will wait for the stacked part of a UCC Compos- ite label before transmitting the linear label without an add-on $CCMOT00  UCC Optional Composite Timer = Timer Disabled $CCMOT07 UCC Optional Composite Timer = 70 msec...
Page 227: Postal Code Selection
UCC COMPOSITE ENTER/EXIT PROGRAMMING MODE Postal Code Selection Enables/disables the ability of the reader to decode labels of a specific postal symbol- ogy. • Disable All Postal Codes • Australia Post • Postnet • Japan Post • Planet • • Royal Mail •...
Page 228: Postnet Bb Control
ENTER/EXIT PROGRAMMING MODE 2D SYMBOLOGIES Postal Code Selection (continued) $CPOEN07 Postal Code Selection = Enable IMB $CPOEN08 Postal Code Selection = Enable Sweden Post $CPOEN09 Postal Code Selection = Enable Portugal Post Postnet BB Control Controls the ability of the reader to decode B and B' fields of Postnet labels. $CPOBB00 ...
Page 229: Ocr Decoding
CONFIGURATION | OCR DECODING The QX25 bar code family is equipped with an Optical Character Recognition feature. This section describes how to configure the Datalogic bar code reader to enable OCR decoding. The QX25 models support the following OCR font types: •...
Page 230: Ocr Decoding Predefined Templates
ENTER/EXIT PROGRAMMING MODE OCR DECODING OCR Decoding Predefined Templates The following selections are exclusive, enabling one template automatically disables the others. $COCEN00000000  OCR Predefined Template = Disable OCR Function $COCEN00000001 OCR Predefined Template = EU Identity Card OCR $COCEN00000002 OCR Predefined Template = IATA Passport OCR $COCEN00000004 OCR Predefined Template = Italian Post OCR Payment...
Page 231: Motion Features
CONFIGURATION | MOTION FEATURES SECTION CONTENTS OTION EATURES starting on page 219 • Motionless Timeout • High Motion Immunity • Motion Sensitivity • Motion Aiming Control • DOF Enhancement Use this chapter to configure motion settings for the handheld. Reference Appendix B, for a listing of standard factory settings. PRODUCT REFERENCE GUIDE...
Page 232: Motionless Timeout
ENTER/EXIT PROGRAMMING MODE MOTION FEATURES Motionless Timeout The period of time that must expire without detecting any motion, before the reader is assumed to be in a motionless condition. The selectable setting is from 500 to 25,500 milliseconds in 100 millisecond increments. This option relates to such features as Aimer On and Stand Mode/Object Detection scanning with respect to motion.
Page 233: High Motion Immunity
ENTER/EXIT PROGRAMMING MODE High Motion Immunity When set to triggerless scanning mode (e.g. Flashing, Always On, Stand Mode/Object Detection, etc.) the reading capabilities can be modified according to two main goals: • increased performance for rapidly moving barcodes - Enable High Motion Immunity: •increased performance for distant barcodes - Disable High Motion Immunity: Depending on specific environmental conditions, application requirements, or expected performance, choose the best solution.
Page 234: Dof Enhancement
ENTER/EXIT PROGRAMMING MODE MOTION FEATURES DOF Enhancement When DOF Enhancement is enabled improves the reading performances. $CSNDE00  Enhance product DOF = Disable $CSNDE01 Enhance product DOF = Enable QUICKSCAN™ QD2590...
Page 235: Chapter 4. References
CHAPTER 4 REFERENCES This section contains explanations and examples of selected bar code features. See Con- for the actual bar code labels used to con- figuration with Bar Codes, starting on page 18 figure the reader. SECTION CONTENTS RS-232 P ARAMETERS on page 224 •...
Page 236: Rs-232 Parameters
REFERENCES RS-232 PARAMETERS RS-232 ONLY Baud Rate Baud rate is the number of bits of data transmitted per second. Set the reader's baud rate to match the baud rate setting of the host device. With an improper baud rate set- ting, data may not reach the host correctly.
Page 237: Rs-232/Usb Com Parameters
RS-232/USB COM PARAMETERS RS-232/USB COM PARAMETERS Intercharacter Delay This parameter specifies the intercharacter delay between the end of one character and the beginning of the next. The delay can be set within a range of zero (0) to 990 millisec- onds in 10ms increments.
Page 238: Ack Nak Options
REFERENCES ACK NAK Options This enables/disables the ability of the reader to support the RS-232 ACK/NAK protocol. When configured, the reader and/or host sends an “ACK” when it receives data prop- erly, and sends “NAK” when the data is in error. Options are: •...
Page 239: Nak Character
RS-232/USB COM PARAMETERS NAK Character This setting specifies an ASCII character or hex value to be used as the NAK character. ASCII characters or any hex value from 0 to 0xFF can be selected. NOTE: Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters.
Page 240: Ack Nak Timeout Value
REFERENCES ACK NAK Timeout Value This option specifies the amount of time the reader waits for an ACK character from the host following label transmission. The selectable timeout range is 200 milliseconds to 15,000ms (15 seconds) in 200ms increments. A selection of 0 disables the timeout. To set this value: 1.
Page 241: Ack Nak Retry Count
RS-232/USB COM PARAMETERS ACK NAK Retry Count This feature specifies the number of times the reader retries a label transmission due to a retry condition. The selectable range is from 1 to 254 retries. A selection of 0 disables the count, and a selection of 255 specifies unlimited retries. To set this feature: 1.
Page 242: Disable Character
REFERENCES Disable Character Specifies the value of the RS-232 host command used to disable the reader. ASCII characters or any hex value from 0 to 0xFF can be selected. NOTE: Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters.
Page 243: Enable Character
RS-232/USB COM PARAMETERS Enable Character Specifies the value of the RS-232 host command used to enable the reader. ASCII characters or any hex value from 0 to 0xFF can be selected. NOTE: Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters.
Page 244: Keyboard Interface
REFERENCES KEYBOARD INTERFACE Wedge Quiet Interval Specifies the amount of time the reader looks for keyboard activity before it breaks the keyboard connection in order to transmit data to host. The range is from 0 to 990ms in 10ms increments. NOTE: This feature applies ONLY to the Keyboard Wedge interface.
Page 245 KEYBOARD INTERFACE NOTE: This feature applies ONLY to the Keyboard Wedge interface. To set the delay: 1. Determine the desired setting in milliseconds. 2. Divide the desired setting by 10 (setting is in 10ms increments). Pad the result with leading zeroes to yield two digits. For example: 0 = 00, 5 = 05, 20 = 20, etc. 3.
Page 246: Intercode Delay
REFERENCES Intercode Delay Specifies the delay between labels transmitted to the host for this interface. The select- able range for this feature is from 0 to 99 seconds. Follow these instructions to set this feature: 1. Determine the desired setting. 2.
Page 247: Data Format
ID code will be transmitted before the scanned bar code data. 00 - 20 Characters (ASCII) NOTE: Additional advanced editing is available. See the Advanced format- ting features in the Datalogic Aladdin configuration software, or contact " Technical Support" on page xii for more information. Please Keep In Mind...
Page 248: Global Prefix/Suffix
REFERENCES Global Prefix/Suffix Up to 20 ASCII characters may be added as a prefix (in a position before the bar code data) and/or as a suffix (in a position following the bar code data) as indicated. Figure 7 Prefix and Suffix Positions OR...
Page 249: Global Aim Id
DATA FORMAT Global AIM ID NOTE: This feature enables/disables addition of AIM IDs for all symbology types. AIM label identifiers (as opposed to custom characters you select yourself as with label identifiers) can be included with scanned bar code data. AIM label identifiers consist of three characters as follows: •...
Page 250: Label Id
Code 93 & 260000 550000 Code 11 434500 620000 Code 128 230000 540000 Code 32 410000 580000 Code 39 2A0000 560000 Datalogic 2of5 730000 730000 EAN13 460000 420000 EAN13 P2 460000 4C0000 EAN13 P5 460000 4D0000 EAN8 464600 410000 EAN8 P2...
Page 251 DATA FORMAT SYMBOLOGY USA LABEL ID SET EU LABEL ID SET ISSN 6E0000 6E0000 400000 5A0000 730000 500000 UPCA 410000 430000 UPCA P2 410000 460000 UPCA P5 410000 470000 UPCE 450000 440000 UPCE P2 450000 480000 UPCE P5 450000 490000 OCR-A 6F0000 246F00...
Page 252: Label Id: Set Individually Per Symbology
REFERENCES Label ID: Set Individually Per Symbology To configure a Label ID individually for a single symbology: 1. Scan the ENTER/EXIT bar code. 2. Select Label ID position as either BEFORE (Enable as Prefix) or AFTER (Enable as suffix) by scanning the appropriate bar code in the section " Label ID Control"...
Page 253 DATA FORMAT Label ID: Set Individually Per Symbology — continued Table 13 Label ID Examples STEP ACTION EXAMPLES Scan the ENTER/EXIT bar code (Reader enters Programming Mode) Determine placement of the Label ID characters BEFORE or AFTER with regard to Enable as Prefix Enable as Suffix Enable as Prefix...
Page 254: Character Conversion
REFERENCES Character Conversion Character conversion is an eight byte configuration item. The eight bytes are 4 character pairs represented in hexadecimal ASCII values. The first character in the pair is the char- acter that will be converted. The second character in the pair is the character to convert to.
Page 255: Scanning Features
SCANNING FEATURES SCANNING FEATURES Scan Mode Selects the scan operating mode for the reader. Selections are: Trigger Single: When the trigger is pulled, scanning is activated until one of the follow- ing occurs: • Stand Mode/Object Detection has elapsed • a label has been read •...
Page 256: Scanning Active Time
REFERENCES Scanning Active Time This setting specifies the amount of time that the reader stays in scan ON state once the state is entered. The range for this setting is from 1 to 255 seconds in 1-second incre- ments. Follow these instructions to set this feature: 1.
Page 257: Aiming Duration Time
SCANNING FEATURES Aiming Duration Time Specifies the frame of time the aiming pointer remains on after decoding a label, when in trigger single mode. The range for this setting is from 1 to 255 seconds in 1-second increments. Follow these instructions to set this feature: 1.
Page 258: Flash On Time
REFERENCES Flash On Time This feature specifies the ON time for the indicator LED while in Flash Mode. The select- able range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond incre- ments. Follow these instructions to set this feature. 1.
Page 259: Flash Off Time
SCANNING FEATURES Flash Off Time This feature specifies the OFF time for the indicator LED while in Flash Mode. The select- able range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond incre- ments. Follow these instructions to set this feature. 1.
Page 260: Led And Beeper Indicators
REFERENCES LED AND BEEPER INDICATORS Good Read LED Duration This feature specifies the amount of time that the Good Read LED remains on following a good read. The good read LED on time can be set within a range of 10 milliseconds to 2,550 milliseconds (0.001 to 2.55 seconds) in 100ms increments.
Page 261: Symbologies
SYMBOLOGIES SYMBOLOGIES Set Length Length Control allows you to select either variable length decoding or fixed length decoding for the specified symbology. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set. Set Length 1 This feature specifies one of the bar code lengths for a given symbology.
Page 262: Set Length 2
REFERENCES Set Length 2 This feature specifies one of the bar code lengths for a given symbology. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Reference the to view the selectable range (num- 1D Symbologies, starting on page 103 ber of characters) for the symbology being set.
Page 263: Appendix A. Technical Specifications
Blue Emission (Wavelength - 470nm) Ambient Light Up to 100,000 lux 0° - 360° Tilt Tolerance +/- 65° Pitch Tolerance +/- 65° Skew Tolerance 35° H x 22° V Field of View PCS (Datalogic Test minimum 15% Chart) PRODUCT REFERENCE GUIDE...
Page 264 1.8 m (6 ft) ESD Protection 16 KV Protection Class IP52 Cable Length Refer to www.datalogic.com PHYSICAL CHARACTERISTICS Black Color White Gun only (L/H/W): 10.9 x 16.6 x 6.8 cm (4.3" x 6.5" x 2.7") Dimensions In Stand: (L/H/W): 7.5 x 21 x 10.9 cm (2.9" x 8.2" x 4.2") Weight (without cable) QD2590 approx.
Page 265: Common Reading Characteristics
COMMON READING CHARACTERISTICS COMMON READING CHARACTERISTICS Table 22 Reading Characteristics DOF - DEPTH OF FIELD (TYPICAL) Symbology DOF range 5 mil: -0.5 - 25.0 cm (0.19" - 9.8") Code 39 10 mil: 0.5 - 38 cm (0.19" - 14.9") EAN13 13 mil: 0.5 - 41.0 cm (0.19"...
Page 266: Decoding Capabilities
Interleaved 2 of 5; Standard 2 of 5; Interleaved 2 of 5 CIP (HR); Interleaved 2 of 5 Febraban (for desk models only); Industrial 2 of 5; Discrete 2 of 5; Datalogic 2 of 5 (China Post Code/ Chinese 2 of 5); IATA 2 of 5 Air cargo code; Follet 2 of 5;...
Page 267: Led And Beeper Indications
LED AND BEEPER INDICATIONS LED AND BEEPER INDICATIONS The reader’s beeper sounds and its illumination flashes or changes color to indicate var- ious functions or errors on the reader. A “Green Spot” also lights to indicate a good read. The tables below list these indications. Table 23LED and Beeper Indications INDICATION BEEPER...
Page 268: Programming Mode
TECHNICAL SPECIFICATIONS PROGRAMMING MODE The following indications ONLY occur when the reader is in Programming Mode. INDICATION DESCRIPTION BEEPER Enter Programming A valid programming label LED blinks continu- Reader sounds four low fre- Mode has been scanned. ously quency beeps. Reader sounds three times at Rejection of Label Label has been rejected.
Page 269 TROUBLESHOOTING Figure 10 and Table 25 provide standard pinout information for the reader’s cable. Figure 10 Standard Cable Pinouts The signal descriptions in Table 25 apply to the connector on the reader and are for ref- erence only. Table 25 Standard Cable Pinouts — Reader Side RS232 RTS (out) CTS (in)
Page 270: Appendix Bstandard D Efaults
APPENDIX B STANDARD D EFAULTS The most common configuration settings are listed in the “Default” column of the table below. Page references are also provided for feature descriptions and programming bar codes for each parameter. A column has also been provided for recording of your pre- ferred default settings for these same configurable features.
Page 271 PARAMETERS DEFAULT YOUR SETTING PAGE NUMBER Indicate Transmission Failure Enable Disable Character ‘D’ Enable Character ‘E’ KEYBOARD WEDGE Setting Country Mode U.S. Keyboard Encoding Type Don't Use Encoding ALT Output Type ALT Unicode Caps Lock State Caps Lock OFF Numlock Numlock Key Unchanged Keyboard Numeric Keypad Standard Keys...
Page 272 STANDARD DEFAULTS PARAMETERS DEFAULT YOUR SETTING PAGE NUMBER Scan Mode Trigger Simple Scanning Active Time 5 seconds Flash On Time 10 = Flash is ON for 1 second Flash Off Time 06 = Flash is OFF for 600ms Double Read Timeout 0.6 second Stand /Base Detection Behavior Switch to Stand Mode/Object Detection...
Page 273 PARAMETERS DEFAULT YOUR SETTING PAGE NUMBER Multiple Labels per Frame Disable Multiple Labels Ordering by Code Random Order Symbology Multiple Labels Ordering by Code Disable Length CODE SELECTION - 1D SYMBOLOGIES Code EAN/UPC Coupon Control Enable only UPC/EAN UPC-A UPC-A Enable/Disable Enable UPC-A Check Character Transmis- Send...
Page 274 STANDARD DEFAULTS PARAMETERS DEFAULT YOUR SETTING PAGE NUMBER EAN-8 Enable/Disable Enable EAN-8 Check Character Transmis- Send sion Expand EAN-8 to EAN-13 Don’t Expand UPC/EAN Global Settings UPC/EAN Price Weight Check Disable UPC/EAN Quiet Zones Two Modules ADD-ONS Optional Add-ons Disable P2 and P5 Optional Add-On Timer 70 msec GS1 DATABAR™...
Page 275 PARAMETERS DEFAULT YOUR SETTING PAGE NUMBER Code 39 Quiet Zones Small Quiet Zones on two sides Code 39 Length Control Variable Code 39 Set Length 1 Code 39 Set Length 2 TRIOPTIC CODE Trioptic Code Enable/Disable Disable CODE 39 DANISH PPT Code 39 Danish PPT Enable/Disable Disable CODE 39 PZN...
Page 276 STANDARD DEFAULTS PARAMETERS DEFAULT YOUR SETTING PAGE NUMBER GS1-128 Enable Transmit in Code 128 Data Format INTERLEAVED 2 of 5 I 2 of 5 Enable/Disable Disable I 2 of 5 Check Character Calculation Disable I 2 of 5 Check Character Transmis- Send sion I 2 of 5 Length Control...
Page 277 Datalogic 2 of 5 Check Character Send Transmission Datalogic 2 of 5 Length Control Variable Length Datalogic 2 of 5 Set Length 1 6 characters Datalogic 2 of 5 Set Length 2 50 characters INDUSTRIAL 2 of 5 Industrial 2 of 5 Enable/Disable...
Page 278 STANDARD DEFAULTS PARAMETERS DEFAULT YOUR SETTING PAGE NUMBER Codabar Check Character Calcula- Disable tion Codabar Check Character Transmis- Send sion Codabar Start/Stop Character Transmit Transmission Codabar Start/Stop Character Set abcd/abcd Codabar Start/Stop Character Match Don’t Require Match Codabar Quiet Zones Quiet Zones on two sides Codabar Length Control Variable...
Page 279 PARAMETERS DEFAULT YOUR SETTING PAGE NUMBER CODE 93 Code 93 Enable/Disable Disable Code 93 Check Character Calculation Enable Check C and K Code 93 Check Character Transmis- Disable sion Code 93 Length Control Variable Code 93 Set Length 1 1 character Code 93 Set Length 2 50 characters Code 93 Quiet Zones...
Page 280 STANDARD DEFAULTS PARAMETERS DEFAULT YOUR SETTING PAGE NUMBER 2D Structured Append Disable 2D Normal/Inverse Symbol Control Normal AZTEC CODE Aztec Code Enable / Disable Enable Aztec Code Length Control Variable Aztec Code Set Length 1 1 character Aztec Code Set Length 2 3,832 characters CHINA SENSIBLE CODE China Sensible Code Enable / Dis-...
Page 281 PARAMETERS DEFAULT YOUR SETTING PAGE NUMBER PDF417 Enable / Disable Enable PDF417 Length Control Variable PDF417 Set Length 1 1 character PDF417 Set Length 2 2,710 characters MICRO PDF417 Micro PDF417 Enable / Disable Enable Micro PDF417 Code 128 GS1-128 Micro PDF AIM ID and label Emulation type...
Page 282: Default Exceptions
Code Standard 2/5 Label ID Character(s) Codabar Label ID Character(s) Code 128 Label ID Character(s) GS1-128 Label ID Character(s) Datalogic 2 of 5 Label ID Character(s) ISBT 128 Label ID Character(s) UPCE P2 Label ID Character(s) UPCE/P5 Label ID Character(s)
Page 283 DEFAULT EXCEPTIONS PARAMETER DEFAULT EXCEPTION GS1 DataBar 14 (Omnidirectional) Label ID Character(s) E GS1 DataBar Expanded Label ID Character(s) GS1 DataBar Limited Label ID Character(s) Character Conversion CR to ` Interface: RS232-OPOS Baud Rate 115200 Baud Transmission Label ID Code Prefix GS1-128 AIM ID Disable...
Page 284: Appendix C. Sample Barcodes
APPENDIX C SAMPLE BARCODES The sample bar codes in this appendix are typical representations for their symbology types. SAMPLE BARCODES 1D Barcodes UPC-A EAN-13 Code 39 Code 128 QUICKSCAN™ QD2590...
Page 285 SAMPLE BARCODES Interleaved 2 of 5 12345678901231 Code 32 Codabar Code 93 Code 11 PRODUCT REFERENCE GUIDE...
Page 286: Gs1 Databar™ (Rss)
SAMPLE BARCODES GS1 Databar™ (RSS) GS1 DataBar™ variants must be enabled to read the barcodes below (see " DataBar™ Omnidirectional" on page 119 GS1 DataBar™ Expanded Stacked 10293847560192837465019283746029478450366523 GS1 DataBar™ Expanded 1234890hjio9900mnb GS1 DataBar™ Limited 08672345650916 GS1 Databar™ (-14) GS1 DataBar™ Omnidirectional Truncated 55432198673467 GS1 DataBar™...
Page 287: 2D Barcodes
SAMPLE BARCODES 2D Barcodes Aztec Data Matrix China Sensible MaxiCode Test Message PDF417 ABCabc Micro PDF 417 BV17453 PRODUCT REFERENCE GUIDE...
Page 288 SAMPLE BARCODES QR Code 35900G9 2D Barcodes (continued) Micro QR Code 123456 UCC Composite QUICKSCAN™ QD2590...
Page 289: Appendix Dkeypad
APPENDIX D KEYPAD Use the bar codes in this appendix to enter numbers as you would select digits/charac- ters from a keypad. PRODUCT REFERENCE GUIDE...
Page 290 KEYPAD QUICKSCAN™ QD2590...
Page 291: Appendix E. Scancode Tables
APPENDIX E SCANCODE TABLES CONTROL CHARACTER EMULATION Control character emulation selects from different scancode tables as listed in this appendix. Each of the control character sets below are detailed by interface type in the tables. These apply to Wedge and USB Keyboard platforms. Control Character 00 : Characters from 00 to 0x1F are sent as control character Ctrl+Keys, special keys are located from 0x80 to 0xA1.
Page 292: Interface Type Pc At Ps/2, Usb-Keyboard Or Usb-Keyboard For Apple
SCANCODE TABLES QUICKSCAN™ QD2590...
Page 293: Interface Type Pc At Ps/2, Usb-Keyboard Or Usb-Keyboard For Apple (Continued)
INTERFACE TYPE PC AT PS/2, USB-KEYBOARD OR USB-KEYBOARD FOR APPLE (CONTINUED) PRODUCT REFERENCE GUIDE...
Page 294: Interface Type Pc At Ps/2 Alt Mode Or Usb-Keyboard Alt Mode
SCANCODE TABLES QUICKSCAN™ QD2590...
Page 295: Interface Type Pc At Ps/2 Alt Mode Or Usb-Keyboard Alt Mode (Continued)
INTERFACE TYPE PC AT PS/2 ALT MODE OR USB-KEYBOARD ALT MODE (CONTINUED) PRODUCT REFERENCE GUIDE...
Page 296: Digital Interface
SCANCODE TABLES QUICKSCAN™ QD2590...
Page 297: Ibm31Xx 102-Key
IBM31XX 102-KEY PRODUCT REFERENCE GUIDE...
Page 298 SCANCODE TABLES QUICKSCAN™ QD2590...
Page 299: Ibm Xt
IBM XT PRODUCT REFERENCE GUIDE...
Page 300 SCANCODE TABLES QUICKSCAN™ QD2590...
Page 301: Microsoft Windows Codepage 1252
MICROSOFT WINDOWS CODEPAGE 1252 MICROSOFT WINDOWS CODEPAGE 1252 Windows-1252 is a character encoding of the Latin alphabet, used by default in the leg- acy components of Microsoft Windows in English and some other Western languages. PRODUCT REFERENCE GUIDE...
Page 302: Appendix F. Ascii Chart
APPENDIX F ASCII CHART ASCII ASCII ASCII ASCII Char. Char. Char. Char. ‘ “ & ’ < > QUICKSCAN™ QD2590...
Page 303 © 2021 Datalogic S.p.A. and /or its affiliates • All rights reserved • Without limiting the rights under copyright, no part of this documentation may be reproduced, stored in or introduced into a retrieval system, or transmitted in any form or by any means, or for any purpose, without the express written permission of Datalogic S.p.A.

Datalogic QuickScan QD2590 Product Reference Manual

Preface

About this Manual

Overview

Technical Support

Chapter 1. Introduction

About the Reader

Using the Quickscan™ QD2590 Reader

Programming the Reader

Chapter 2. Setup

Unpacking

Setting up the Quickscan™ QD2590 Reader

Connect Host Interface

Stand Installation

Setting up the Quickscan™ QD2590 Reader

Reader and Leds Description

Using the Quickscan™ QD2590

Interface Selection

Configuring the Interface

Customizing Configuration Settings

Chapter 3. Configuration with Bar Codes

Configuration Parameters

Interface

Rs-232/Usb-Com Interfaces

Keyboard Interface

Setup on PC to Use ALT Universal

Usb-Oem Interface

Ibm 46Xx Interface

Data Format

Reading Parameters

Quick Links

Need help?

Questions and answers

Related Manuals for Datalogic QuickScan QD2590

Summary of Contents for Datalogic QuickScan QD2590
