Summary of Contents for Datalogic QuickScan QD2590
- Page 1 QuickScan™ QD2590 QUICK REFERENCE GUIDE General Purpose Corded Handheld Area Imager Bar Code Reader...
- Page 2 Disclaimer Datalogic has taken reasonable measures to provide information in this manual that is complete and accurate, however, Datalogic shall not be liable for technical or editorial errors or omissions contained herein, nor for inci- dental or consequential damages resulting from the use of this material.
-
Page 3: Table Of Contents
TABLE OF CONTENTS END USER SOFTWARE LICENSE AGREEMENT....V Software Product Policy ............X QUICKSCAN™ QD2590 ......... 1 About the Scanner ............1 Omni-Directional Operating..........2 Decoding................2 Imaging.................. 2 Hands Free Stand/Holder ............. 3 Setting Up the Reader ............ 4 Connecting to the Host Interface.......... - Page 4 Contents Technical Features ............26 QuickScan™ QD2590 ............26 LED and Beeper Indications ......... 30 Troubleshooting ............31 Warranty..............32 Ergonomic Recommendations ........33 Cleaning Procedure ............. 34 Common Cleaning Solutions..........34 Cleaning enclosure and window surfaces ......34 Technical Support............35 Support Through the Website ..........
-
Page 5: End User Software License Agreement
Datalogic grants to End User, a personal, non-exclusive, non-transfer- able, non sub licensable, revocable, limited license to use the Soft- ware, solely on the Datalogic Product in which it is embedded or for which it is intended for use, in machine-readable form only, solely for End User's internal business purposes. - Page 6 End User to promptly pay all (additional) license fees due and any further damages, if any. 2. License Fee License fees shall be due by End User to Datalogic according to the terms provided for in the relevant contract for the purchase of the Datalogic Product.
- Page 7 IF ANY, WHETHER BASED UPON CONTRACT, TORT (INCLUDING NEGLI- GENCE), PRODUCT LIABILITY, STRICT LIABILITY, WARRANTY, OR ANY OTHER BASIS, EXCEED THE PRICE OR FEE PAID BY END USER FOR THE DATALOGIC PRODUCT. UNDER NO CIRCUMSTANCES SHALL DATALOGIC OR ITS LICEN-...
- Page 8 Datalogic IP Tech S.r.l., Legal & IP Department, Via San Vitalino 13, 40012 Calderara di Reno (Bolo- gna), Italy, or such other address as may be specified by Datalogic in writ- ing. 12. General Provisions. 12.1. Entire Agreement; Amendment. This document contains the entire...
- Page 9 State of Oregon located in either Multnomah or Lane counties shall have exclusive jurisdiction over all matters regarding this Agreement, except that Datalogic shall have the right, at its absolute discretion, to initi- ate proceedings in the courts of any other state, country, or territory in which End User resides, or in which any of End User's assets are located.
-
Page 10: Software Product Policy
EULA Software Product Policy Datalogic reserves the right to ship its products with the latest version of software/firmware available. This pro- vides our customers with the very latest in Datalogic soft- ware technology. The only exception to this policy is when the buyer has a... -
Page 11: Quickscan™ Qd2590
ABOUT THE SCANNER The QuickScan QD2590 product series represents the hand-held entry level corded scanner by Datalogic. It has been specifically created for small to medium size Retail- ers, such as groceries and convenience stores, operating in both food and non-food sectors. -
Page 12: Omni-Directional Operating
The QuickScan™ QD2590 is a powerful omni-directional reader, so the orientation of the symbol is not important. Datalogic's 'Green Spot' for good-read feedback helps to improve productivity in noisy environments or in situations where silence is required. -
Page 13: Hands Free Stand/Holder
About the Scanner Hands Free Stand/Holder An accessory is available which holds the reader (except those with integrated stand) at a convenient angle, allow- ing hands free scanning of items. It can also be used as a holder. The holder “cup” can be positioned in any of the three angles shown in the figure below. -
Page 14: Setting Up The Reader
Setting Up the Reader SETTING UP THE READER Follow the steps below to connect and get your reader up and communicating with its host. Connect the Cable to the reader and the Host as shown below. Configure the Interface (see page Program the Reader starting on page (optional, as needed). -
Page 15: Disconnecting The Cable
Setting Up the Reader Disconnecting the Cable To remove the interface cable from the reader, first locate the hole on the bottom of the handle. Next, take a paper clip and modify it as shown in the figure below. Insert the end of the paper clip into the hole and press it to push on the clip that holds the connector. -
Page 16: Using The Quickscan™ Qd2590
Using the QuickScan™ QD2590 USING THE QUICKSCAN™ QD2590 The QuickScan™ QD2590 normally functions by capturing and decoding codes. The reader is equipped with an inter- nal Motionix™ motion-sensing function which activates the aiming system on device motion. The intelligent aim- ing system indicates the field of view which should be positioned over the bar code: Aiming System... -
Page 17: Relative Size And Location Of Aiming System Pattern On Linear Bar Code
Using the QuickScan™ QD2590 Relative Size and Location of Aiming System Pattern on Linear bar code A red beam illuminates the label. The field of view indi- cated by the aiming system will be smaller when the reader is closer to the bar code and larger when it is far- ther from the code. -
Page 18: Parts Of The Reader
For interfaces other than those listed in this manual, see the QuickScan™ QD2590 Product Reference Guide (PRG), available online at www.datalogic.com. Interface Selection The reader will support all the following host interfaces: RS-232 STD •... -
Page 19: Configuring The Interface
Configuring the Interface tional information associated with each interface, proceed to the corresponding chapter in the QuickScan™ QD2590 PRG. CONFIGURING THE INTERFACE Scan the appropriate programming bar code to select the interface type for your system. NOTE: Unlike some other programming fea- tures and options, interface selections require that you scan only one programming bar code label. - Page 20 Configuring the Interface RS-232 RS-232 standard interface Select RS232-STD RS-232 Wincor-Nixdorf Select RS232-WN RS-232 for use with OPOS/UPOS/JavaPOS Select RS-232 OPOS USB Com to simulate RS-232 standard interface Select USB-COM-STD 1. Download the correct USB Com driver from www.datalogic.com QUICKSCAN™ QD2590...
- Page 21 Configuring the Interface USB-OEM USB -OEM (can be used for OPOS/UPOS/JavaPOS) Select USB-OEM USB-COMPOSITE USB -Composite Select USB-Composite IBM46XX IBM46xx Port 9b Select IBM46xx Port 9b QUICK REFERENCE GUIDE...
- Page 22 Configuring the Interface USB FOR TERMINALS USB HID POS Select USB HID POS USB Toshiba TEC Select USB Toshiba TEC USB FOR MAGELLAN SCANNERS USB for Magellans Select USB Magellan Scanners QUICKSCAN™ QD2590...
-
Page 23: Keyboard Interface
Configuring the Interface Keyboard Interface Use the programming bar codes to select options for USB Keyboard and Wedge Interfaces. KEYBOARD AT, PS/2 25-286, 50, 50Z, 60, 70, 80, 90 & 95 w/ Standard Key Encoding Select KBD-AT Keyboard Wedge for IBM AT PS2 with standard key encoding but without external keyboard Select KBD-AT-NK AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 &... -
Page 24: Scancode Tables
Configuring the Interface KEYBOARD (CONTINUED) USB Keyboard with standard key encoding ♦ Select USB Keyboard USB Keyboard with alternate key encoding Select USB Alternate Keyboard ♦ = Default value Scancode Tables Refer to QuickScan™ QD2590 PRG for information about control character emulation for keyboard interfaces. Country Mode This feature specifies the country/language supported by the keyboard. - Page 25 Configuring the Interface All other interfaces support ONLY the following Country Modes: U.S., Belgium, Britain, France, Germany, Italy, Spain, Sweden COUNTRY MODE ENTER/EXIT PROGRAMMING MODE ♦Country Mode = US Country Mode = Belgium Country Mode = Croatia* Country Mode = Czech Republic* ♦...
- Page 26 Configuring the Interface COUNTRY MODE (CONTINUED) Country Mode = Denmark* Country Mode = France Country Mode = French Canadian* Country Mode = Germany Country Mode = Hungary* Country Mode = Italy Supports only the interfaces listed in the Country Mode feature description.
- Page 27 Configuring the Interface COUNTRY MODE (CONTINUED) Country Mode = Japanese 106-Key* Country Mode = Lithuanian* Country Mode = Norway* Country Mode = Poland* Country Mode = Portugal* Country Mode = Romania* Supports only the interfaces listed in the Country Mode feature description.
-
Page 28: Programming
Programming COUNTRY MODE (CONTINUED) Country Mode = Spain Country Mode = Sweden Country Mode = Slovakia* Country Mode = Switzerland* Supports only the interfaces listed in the Country Mode feature description. PROGRAMMING The reader is factory-configured with a set of standard default features. -
Page 29: Configure Other Settings
Programming Using Programming Bar Codes This manual contains bar codes which allow you to recon- figure your reader. Some programming bar code labels, like the "Reset Default Settings" on page 19, require only the scan of that single label to enact the change. Other bar codes require the reader to be placed in Pro- gramming Mode prior to scanning them. -
Page 30: Numlock
Numlock NUMLOCK This option specifies the setting of the Numbers Lock (Numlock) key while in keyboard wedge interface. This only applies to alternate key encoding interfaces. It does not apply to USB keyboard. NUMLOCK ENTER/EXIT PROGRAMMING MODE Numlock = Numlock key unchanged Numlock = Numlock key toggled ♦... -
Page 31: Caps Lock State
Caps Lock State CAPS LOCK STATE This option specifies the format in which the reader sends character data. This applies to keyboard wedge interfaces. This does not apply when an alternate key encoding key- board is selected. CAPS LOCK STATE ENTER/EXIT PROGRAMMING MODE ♦... -
Page 32: Aiming System
Good Read Green Spot Duration The aiming system will briefly switch off after the acquisi- tion time, and if no code is decoded will switch on again before the next acquisition. The illuminator will remain on until the symbol is decoded. As you read code symbols, adjust the distance at which you are holding the reader. -
Page 33: Operating Modes
Operating Modes OPERATING MODES Scan Mode The imager can be set to operate in one of several scan- ning modes. See the PRG for more information and set- tings for any of the options: This mode is associated with Trigger Single (Default) — typical handheld reader operation. - Page 34 Operating Modes The scanner looks for changes within Object Detection — its field-of-view. The Aiming Pattern is always on to show the optimum reading area. If a predefined amount of movement is detected, the white illumination switches on. Scanning continues until a label is read or “maximum scan on time”...
-
Page 35: Pick Mode
Operating Modes Pick Mode Specifies the ability of the reader to decode labels only when they are close to the center of the aiming pattern, which is the area indicated by the red cross. Pick Mode is a Decoding and Transmission process where bar codes that are not within the configurable distance from the center of the aiming pattern are not acknowledged or transmit- ted to the host. -
Page 36: Technical Features
-40 °C to + 70 °C (-40 ° F to +158 °F) ture Humidity 95% non condensing IEC 68-2-32 Tested Drop Resistance 1.5 m (4.9 ft) Trigger Resistance 10 Mhits ESD Protection 16 KV Protection Class IP52 Cable Length Refer to www.datalogic.com QUICKSCAN™ QD2590... - Page 37 Aiming System Blue Emission (wavelength - 470nm) Ambient Light Up to 100,000 lux Tilt Tolerance 0° - 360° Pitch Tolerance ± 65° Skew Tolerance ± 65° Field of View 35° x 22° PCS (Datalogic Test minimum 15% Chart) QUICK REFERENCE GUIDE...
- Page 38 Technical Features DOF - DEPTH OF FIELD (TYPICAL) Symbology DOF range 5 mil: -0.5 - 25.0 cm (0.19" - 9.8") Code 39 10 mil: 0.5 - 38 cm (0.19" - 14.9") EAN13 13 mil: 0.5 - 41.0 cm (0.19" - 16.1") PDF417 6.7 mil: 0.5 - 21.0 cm (0.19"...
- Page 39 Technical Features DECODE CAPABILITY 1D Bar Codes UPC/EAN/JAN (A, E, 13, 8); UPC/EAN/JAN (including P2 /P5); UPC/EAN/JAN (including; ISBN / Bookland & ISSN); UPC/EAN Coupons; Code 39 (including full ASCII); Code 39 Trioptic; Code39 CIP (French Pharmaceutical); LOGMARS (Code 39 w/ standard check digit enabled); Danish PPT; Code 32 (Italian Pharmacode 39);...
-
Page 40: Led And Beeper Indications
LED and Beeper Indications LED AND BEEPER INDICATIONS The imager’s beeper sounds and its illumination flashes or changes color to indicate various functions or errors on the reader. A “Green Spot” also lights to indicate a good read. The tables below list these indications. Reference the PRG for a more detailed list. -
Page 41: Troubleshooting
Troubleshooting TROUBLESHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION Check system power. No power to the Ensure power supply is imager. Nothing happens connected. when the scan Ensure all cable button is pulled. Interface or power connections are cables are loose. secure. Ensure imager is programmed to read Imager not... -
Page 42: Warranty
Datalogic, unless otherwise agreed in an applicable writing by Datalogic. Datalogic will not be liable under the warranty if the Product has been exposed or subjected to any: (1) maintenance, repair, installation, han- dling, packaging, transportation, storage, operation or use that is improper or otherwise not in compliance with Datalogic’s instruction;... -
Page 43: Ergonomic Recommendations
Ergonomic Recommendations ERGONOMIC RECOMMENDATIONS CAUTION: In order to avoid or minimize the poten- tial risk of ergonomic injury follow the recommen- dations below. Consult with your local Health & Safety Manager to ensure that you are adhering to your company’s safety programs to prevent employee injury. -
Page 44: Cleaning Procedure
CAUTION: Be sure to turn off power and unplug the device from electrical outlet before cleaning. Common Cleaning Solutions The cleaners and disinfectants listed below are tested for use on Datalogic’s Quickscan QD2590 Enclosures: CLEANERS DISINFECTANTS Formula 409® Glass & Surface Cleaner Clorox® Bleach (diluted 10:1) -
Page 45: Technical Support
Technical Support. Reseller Technical Support An excellent source for technical assistance and information is an authorized Datalogic reseller. A reseller is acquainted with specific types of businesses, application software, and computer systems and can provide individualized assistance. QUICK REFERENCE GUIDE... - Page 48 ©2021 Datalogic S.p.A. and /or its affiliates. • All rights reserved • Without limiting the rights under copyright, no part of this documentation may be reproduced, stored in or introduced into a retrieval system, or transmitted in any form or by any means, or for any purpose, without the express written permission of Datalogic S.p.A.
