3.6 Removing a GP316

Context
To make full use of the space and prevent the GP316 from being removed forcibly, the upper
layer GP316 and the lower layer G530 V2 adopt dislocation design. Therefore, you must
remove the G530 V2 at the lower layer and then remove the GP316 at the upper layer.
Procedure
Step 1 Remove the G530 V2. For details, see
Step 2 Remove the GP316.
1.
2.
3.
4.
5.
Issue 02 (2017-12-15)
Press the unlock button on the GP316. See (1) in
Figure 3-9 Removing the GP316
Open the ejector levers on the GP316 completely. See (2) in
Pull the GP316 out of the chassis. See (3) in
Close the ejector lever on the GP316. See (4) in
Place the removed GP316 in an ESD bag.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3.5 Removing a G530
Figure
Figure 3-9.
Figure 3-9.
3 Basic Operations
V2.
3-9.
Figure 3-9.
41
