FusionServer G5500 Server
User Guide
Prerequisites
l
l
l
l
Procedure
Step 1 Double-click PuTTY.exe.
The PuTTY Configuration window is displayed.
Step 2 In the navigation tree, choose Connection > Serial.
Step 3 Set the login parameters.
Example:
l
l
l
l
l
l
n in COMn indicates the number of a serial port, and its value is an integer.
Step 4 In the navigation tree, choose Session.
Step 5 Select Serial under Connection type, as shown in
Issue 02 (2017-12-15)
A PC is properly connected to the server using a multi-port serial cable.
The PuTTY is installed and its version is 0.60 or later.
You have obtained the user name and password for logging in to the management
module to be connected.
You have obtained the software package of the third-party free software PuTTY.
Serial Line to connect to: COMn
Speed (baud): 115200
Data bits: 8
Stop bits: 1
Parity: None
Flow control: None
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5 Configuring the G5500
Figure 5-3.
