Huawei SAP HANA Appliance Single Node
Installation Guide (RH2288H
V3+Broadwell+SLES11 SP4 For B1)
Issue
01
Date
2017-01-06
HUAWEI TECHNOLOGIES CO., LTD.

Advertisement

Table of Contents
loading

Related Manuals for Huawei FusionServer RH2288H V3

Summary of Contents for Huawei FusionServer RH2288H V3

  • Page 1 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) Issue Date 2017-01-06 HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...

  • Page 3: About This Document

    About This Document Purpose This document describes the software and hardware planning of the Huawei RH2288H V3 Broadwell SAP HANA appliance, how to install a redundant array of independent disks (RAID) controller card, SUSE for SAP OS, Peripheral Component Interconnect Express (PCIe) solid-state drive (SSD), and SAP HANA database, and how to verify the installation.

  • Page 4: Change History

    Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) About This Document Symbol Description injury. Calls attention to important information, best practices and tips. NOTE is used to address information not related to personal injury, equipment damage, and environment deterioration.

  • Page 5: Table Of Contents

    Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) Contents Contents About This Document ......................ii Contents ..........................iv 1 Installation Planning ......................1 1.1 Hardware Configuration Planning ............................1 1.2 Software Planning ................................. 1 1.3 Internal Disk Planning ................................1 1.4 Default Parameter .................................

  • Page 6: Installation Planning

    Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 1 Installation Planning Installation Planning 1.1 Hardware Configuration Planning RH2288H V3 SAP HANA Sizing Configuration table describes the hardware planning. Before installing the OS, depending on the HANA Sizing configuration planning storage space needed.

  • Page 7: Default Parameter

    Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 1 Installation Planning Table 1-2 Internal disk planning Devices Partition File System Partition Description Type Size /dev/sda Raid1 600GB Used to install the OS. /dev/sda1 ext3 50GB...

  • Page 8: Installation Process

    Username: root account/password password Password: Huawei12#$ 1.6 Installation Process Figure 1-1 shows the process for installing the Huawei RH2288H V3 Broadwell SAP HANA appliance. Issue 01 (2017-01-06) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 9 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 1 Installation Planning Figure 1-1 Installation process Issue 01 (2017-01-06) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 10: Configuring The Bios

    Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 2 Configuring the BIOS Configuring the BIOS This chapter describes how to configure the basic input/output system (BIOS) parameters of the server to meet performance requirements for SAP HANA operation.
  • Page 11 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 2 Configuring the BIOS Figure 2-1 iBMC login page Step 4 In the navigation tree on the left, choose Remote, and click Remote Virtual Console (shared mode) in the right pane, as shown in Figure 2-2.

  • Page 12: Configuring Bios Parameters

    Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 2 Configuring the BIOS Figure 2-3 KVM console ----End 2.2 Configuring BIOS Parameters Step 1 When the screen shown in Figure 2-4 is displayed during the server startup, press Delete to open the BIOS setup screen.
  • Page 13 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 2 Configuring the BIOS The BIOS default password is "Huawei12#$". If you have not configured any BIOS password, the BIOS screen is displayed, as shown in Figure 2-6.
  • Page 14 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 2 Configuring the BIOS Figure 2-7 Selecting Advanced Power Management Configuration Step 4 Turning off Power Policy Select: Select Custom, and press Enter, as shown in Figure 2-8.
  • Page 15 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 2 Configuring the BIOS Figure 2-9 Turing off P State Step 6 Turning off C-States: Press Esc to exit the CPU P State Control screen, select CPU C State Control using the downward arrow, and press Enter, as shown in Figure 2-10.
  • Page 16 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 2 Configuring the BIOS  Turning off CPU C6 State: Select CPU C6 report, and press Enter. Select Disable, and press Enter to turn off CPU C6 State.
  • Page 17 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 2 Configuring the BIOS The BIOS parameter configuration is complete. ----End Issue 01 (2017-01-06) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 18: Configuring Raid Parameters

    Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 3 Configuring RAID Parameters Configuring RAID Parameters 3.1 Preparations This document use the RH2288H V3 Broadwell SAP HANA Sizing 6T advanced version of the RAID configuration as an example.
  • Page 19 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 3 Configuring RAID Parameters Figure 3-2 VD Mgmt page If this RAID controller card has been configured (has been used in maintenance and OS reinstallation scenarios before). We need to Del the "old RAID configured", as shown in Figure 3-3.
  • Page 20 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 3 Configuring RAID Parameters Step 3 Press "F2", On the displayed page, select Create Virtual Drive, as shown in Figure 3-5. Figure 3-5 Selecting a Create VD Step 4 Users can perform RAID configuration according to the requirements specific parameter, as shown in Figure 3-6.
  • Page 21 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 3 Configuring RAID Parameters Drives: displays hard disk information available, on the left there is a "[ ]" indicates whether you select this hard drive to make RAID configuration. It can be selected through the "Enter"...
  • Page 22 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 3 Configuring RAID Parameters Figure 3-8 VD0 Advanced Configuration Parameter Items Caution: When you select "Initialize" item will prompt the need for initialization page, and prompts to initialize will delete all data, here select "OK", as shown in Figure 3-9 Figure 3-9 Initialization page Step 5 After configuring the "Advanced"...
  • Page 23 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 3 Configuring RAID Parameters Figure 3-10 VD Mgmt page Step 6 Create VD1:in the main administration page press the "F2" key to enter the selection menu, as show Figure 3-11, select "Creat Virtual Drive"...
  • Page 24 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 3 Configuring RAID Parameters Figure 3-12 VD1 Configuration page Step 8 Configure the VD1 Advanced RAID Parameter Item, and select the "OK" to complete the configuration, as show in Figure 3-13;...
  • Page 25 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 3 Configuring RAID Parameters Figure 3-14 VD1 Configuration Step 10 When you complete the all VD1 RAID Configuration Item, select "OK" and complete the VD1 configure, as show in Figure 3-15.
  • Page 26 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 3 Configuring RAID Parameters Figure 3-16 configuration result Step 12 Set the Boot device :Press Ctrl-N to Ctrl Mgmt Page Set VD0 as the Boot device; as shown in Figure 3-17,Then, select "Apply" press "Enter";...
  • Page 27 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 3 Configuring RAID Parameters Figure 3-18 Create CacheCade virtual Drive Step 14 When you select "Create CacheCade virtual Drive "item, enter the RAID configuration parameters page,this example, there are 4 SSD disks configured as RAID1; "Write Policy "parameter should be set to "Write Back";...
  • Page 28 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 3 Configuring RAID Parameters Figure 3-20 CacheCade Configuration Step 16 When you complete all VD configurations, you will view the VD0, VD1 and cachecade information in the main administration page, as show inFigure 3-21.
  • Page 29 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 3 Configuring RAID Parameters Figure 3-22 Restarting the system ----End Issue 01 (2017-01-06) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 30: Installing The Os And Related Software

    Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 4 Installing the OS and Related Software Installing the OS and Related Software 4.1 Preparing for Installation Step 1 Select an installation mode. You can install an OS using physical DVD-ROM drive or virtual media (virtual DVD-ROM drive) of the virtual console.
  • Page 31 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 4 Installing the OS and Related Software Restart the system. Open the BIOS setup screen by 2.2 Step 1 and 2.2 Step 2, as shown in Figure 4-2.
  • Page 32 After the BIOS is upgraded, the BIOS version may be changed, but entry word CDROM or DVD-ROM stays unchanged. Figure 4-4 Selecting HUAWEI DVD-ROM VM 1.1.0 225 Step 5 press F10 On the displayed screen shown in Figure 4-5, In the dialog box that is displayed, select Yes, and press Enter.And then the system will be restart automatically.

  • Page 33: Installing An Os

    Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 4 Installing the OS and Related Software 4.2 Installing an OS Step 1 On the installation page, select Install SLES11 SP4 B1, and press Enter, as shown in Figure 4-6.
  • Page 34 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 4 Installing the OS and Related Software Step 3 Choose Yes to confirm to format the selected disk, as shown in Figure 4-8. Caution All data is lost and you cannot abort your installation after the confirmation..
  • Page 35 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 4 Installing the OS and Related Software Figure 4-10 Comfirm the licenses screen Figure 4-11 Accept the SLES EULA Step 6 Select the keyboard layout according to your needs, as shown in Figure 4-12.
  • Page 36 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 4 Installing the OS and Related Software Figure 4-12 Keyboard Configuration Step 7 Enter the hostname and the domain name of the server, and choose Next, as shown in Figure 4-13.
  • Page 37 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 4 Installing the OS and Related Software Figure 4-14 Network Configuration Step 9 On the Overview tab, select the device eth0 and then choose Edit., as shown in Figure 4-15.
  • Page 38 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 4 Installing the OS and Related Software Figure 4-16 Settings page Step 11 On the Hostname/DNS tab, enter the hostname, domain name, and DNS servers, as shown in...
  • Page 39 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 4 Installing the OS and Related Software Figure 4-18 Routing Figure 4-19 Network Configuration II Step 13 Specify and confirm the password for the system administrator user root, and choose Next., as shown in Figure 4-20.
  • Page 40 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 4 Installing the OS and Related Software Figure 4-20 Enter password for root Step 14 Choose to register with the Novell Customer Center for updates later, and choose Next, as shown in Figure 4-21.
  • Page 41 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 4 Installing the OS and Related Software Figure 4-22 YaST2 Step 16 If you decide to create only SAP file systems and install SAP products manually later, the wizard automatically creates the SAP-related partitions and then displays the results, as shown in Figure 4-23.
  • Page 42 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 4 Installing the OS and Related Software Figure 4-24 Complete the system configuration Step 18 The page shown in Figure 4-25 is displayed, indicating that OS installation is complete.

  • Page 43: Network Configuration

    Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 4 Installing the OS and Related Software Figure 4-26 OS desktop ----End 4.3 Network Configuration Step 1 Open yast2 in Terminal as shown in Figure 4-27.Configure a network for the server, run the yast2 command, and press Enter, as shown in Figure 4-28.
  • Page 44 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 4 Installing the OS and Related Software Figure 4-28 Running the yast2 command Step 2 Run the ifconfig eth0 command, and press Enter. If the information similar to that in Figure 4-29 is displayed, the network is configured successfully.
  • Page 45 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 4 Installing the OS and Related Software Figure 4-30 Disabling the firewall Step 4 Connect a network cable to the first network port on the RH5885H /RH8100 V3 Broadwell.
  • Page 46 Huawei SAP HANA Appliance Single Node Installation Guide (RH2288H V3+Broadwell+SLES11 SP4 For B1) 4 Installing the OS and Related Software Figure 4-32 Connecting to the server Enter the user name and password, and press Enter, as shown in Figure 4-33.
