Matrix Telecom SARVAM UMG Quick Start Manual page 52

ETERNITY GE CO16
L1 L2
Connector Color
RJ45-1
1
RJ45-
2
RJ45-
3
RJ45-
4
Matrix SARVAM UMG Quick Start
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
2 Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
3 Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
4 Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
Connection H/w Port Offset
CO 01
CO 02
CO 03
CO 04
CO 05
CO 06
CO 07
CO 08
CO 09
CO 10
CO 11
CO 12
CO 13
CO 14
CO 15
CO 16
